Congratulations on your purchase of a new Dial-A-Watt Lumatek electronic ballast!
The Dial-A-Watt technology inside your ballast gives you the following four advantages :
1. Multi-Wattage - Now you can power different wattage lamps on the same ballast.Depending on
which model Dial-A-Watt Lumatek ballast you have, you can use up to three different wattages of lamps.
The list below details which wattage lamps can be used on each model:
FOR SUPERIOR RESULTS USE LUMATEK LAMPS WITH LUMATEK BALLASTS
LK2S0
LK400
LK600
LK6240T
LK6240
LK7240
LK1000
LKHH240
1SOWI17SW/2S0W MH/HPS
2S0W/400W MH/HPS
400W/600W MH/HPS
400W/600W MH/HPS
400W/600W MH/HPS
600W17S0W (the 7S0W setting can only power a HPS lamp)
600W17S0W/1000W MH/HPS
600W17S0W/1000W MH/HPS
2. Dimmable - Dial-A-Watt Lumatek ballasts are capable of being dimmed. Dimming can be a great way
to deal with heat issues in your garden. When dimming a lamp,it is important to remember that you can
only go down in wattage. For example, a 1,OOOWlamp can be dimmed to 7SOW, but you cannot
increase the power of a 7S0W lamp to 1,000W. Do not run your lamps higher than their rated wattage.
Doing so could severely damage your lamp.
3. Super Lumens - Up to 10% more light at the turn of a dial.The Super Lumens feature can only be used
with the highest rated wattage lamp for your ballast. For example, if you have a 1,000W Dial-A-Watt
Lumatek, the Super Lumens setting can only be used with a 1,OOOWlamp. Using the Super Lumens
setting with a lower wattage lamp could damage your lamp.On the 400W Dial-A-Watt Lumatek there
are two Super Lumens settings; one for a 2S0W lamp and one for a 400W lamp.
4. Go Green - With each setting on your Dial-A-Watt Lumatek ballast,
both the input and output power
change.
This is a great feature if you want to save energy when your plants are young and you need less
light. A 1,OOOWDial-A-Watt Lumatek ballast at the 7S0W setting uses 2S% less electricity than it would
at 1,000W.
For questions or support please
call 1.866.369.8943
