(800)856-4445
INSTALLATION AND
INSTALLATION AND
OWNER'S INSTRUCTIONS
OWNER'S INSTRUCTIONS
TABLE OF CONTENTS
Table of C
Table of Contents
Safety Instructions ...................................................................... 2
Goal Specifi cations ...................................................................... 3
Determine Installation Specifi cations .......................................... 3
Ground Anchor Installation ......................................................... 4
Pole Assembly ............................................................................. 5
Extension Arm Attachments ........................................................ 6
Jack Attachment ......................................................................... 7
Backboard Attachment ............................................................... 8
Goal Alignment ........................................................................... 9
Rim Attachment ........................................................................ 10
Height Indicator Adjustment ..................................................... 11
Ready to Play ............................................................................ 12
Warranties ................................................................................ 13
LTP PRO Series
Adjustable Height
Goal System
• LTP672
Advertisement
Table of Contents
Summary of Contents for Leisure Time Products LTP PRO Series
-
Page 1: Table Of Contents
INSTALLATION AND INSTALLATION AND OWNER’S INSTRUCTIONS OWNER’S INSTRUCTIONS LTP PRO Series Adjustable Height Goal System • LTP672 TABLE OF CONTENTS Table of Contents Table of C Safety Instructions ..............2 Goal Specifi cations ..............3 Determine Installation Specifi cations .......... 3 Ground Anchor Installation ............ -
Page 2: Safety Instructions
Your goal may have product improvements and options • With rim set at 7’-0” playing height, the minimum operational height is 6’-4” not yet contained in this manual. Leisure Time Products reserves the right to (1.93 m) to the bottom of the backboard. -
Page 3: Goal Specifi Cations
Goal Specifi cations LTP672 Pole Size: 6”x6” Backboard Size: 42”x72” Weight w/Acrylic: 475 lbs. Weight w/Glass: 535 lbs. (A) Height Range: 6’8”-10’ (B) Extension Distance: at 10’ 42” at 8’ 48” at 7’ 46” (C) Maximum Overhang: 73” (D) Distance Rim to Backboard: 25”... -
Page 4: Ground Anchor Installation
Ground Anchor Installation Step 1: Locate and unpack a 6” ground anchor (Item TIME OUT TIP: The arrow on the decal G2660). Remove plastic plugs from bolt holes and ensure the threads are MUST be pointing toward the playing surface. in good condition. -
Page 5: Pole Assembly
Pole Assembly Step 2: Unpack pole and jack. Jack comes packaged with the pole. IMPORTANT Jack will be used in Jack Attachment instructions. • Allow 48 hours for concrete to cure before beginning. • Check to see that no concrete or debris obstructs threads in ground Step 3: Align pole hinge with anchor plate hinge, then anchor bolt holes by threading anchor bolts in &... -
Page 6: Extension Arm Attachments
Extension Arm Attachments WARNING Step 3: Align and attach upper extension arm pivot Two or three people in good physical condition and capable of lifting at holes with upper bushing on pole following the same least 90-100 lbs. (40-45 kg) each are recommended for safe installation hardware and procedure as in Step 2. -
Page 7: Jack Attachment
Jack Attachment Step 3: Extend jack by turning jack handle counter- WARNING clockwise until upper jack bracket is aligned with holes in lower Two or three people in good physical condition and capable of lifting at extension arm. least 90-100 lbs. (40-45 kg) each are recommended for safe installation and assembly. -
Page 8: Backboard Attachment
Step 2. TIME OUT TIP: Lay the unopened box with Leisure Time Products logo upside down AND let the lid open up and fold away from the goal system. Step 1: Open lid of box containing backboard and slide the backboard face down under lower extension arm, with rim mounting plate facing towards goal system. -
Page 9: Goal Alignment
The bolts must pass all the way through the ground anchor plate. If they do not pass through the ground anchor plate when fully tightened, STOP TOOLS: installation, contact Leisure Time Products and DO NOT allow play. ” Socket, Level, ” Drive Torque Wrench... -
Page 10: Rim Attachment
If missing, Step 6: Position cover plate and attach with cover contact Leisure Time Products or dealer. plate screws. DO NOT install rim without bushings. If the bushings are not in place, glass backboards can shatter and acrylic backboards Step 7: Attach net to rim. -
Page 11: Height Indicator Adjustment
Height Indicator Attachment Step 1: Position top of rim 7’ above playing surface by turning crank handle. Step 2: Draw a mark on inner tube at edge of outer jack tube. Step 3: Extend jack approximately ½”. Peel ½” of backing off the top of the decal (by the 7’... -
Page 12: Ready To Play
• Contact Leisure Time Products for replacement parts. Only use parts provided by Leisure Time Products Use of other parts (a) may cause the goal system to fail, (b) could result in death, serious injury or property damage, and (c) will void the warranty. -
Page 13: Warranties
Leisure Time Products to be defective and covered Time Products warrants to the original retail purchaser that all structural by the warranty. Leisure Time Products will not be liable for any other components of Leisure Time Products LT PRO Series basketball systems are damages or expenses. - Page 14 Leisure Time Products needs your warranty item returned. Leisure Time Products will notify you if we determine that the item cannot be claimed under warranty. Leisure Time Products is not responsible for any charges for labor to install or repair defective product without prior authorization.
- Page 15 Notes...
- Page 16 Phone 800-856-4445 1/2015...
