  • Page 4: Function

    The number following the “WX” denotes the number of ST-15C Control Modules in the model. Each module is referred to as a “channel” and can monitor one sensor. Thus, an ST-15-240-WX10 can monitor 10 probes. The Scully part numbers for the various models are as follows: Model Part Number...
  • Page 5: Power Requirements

    Multi-Point Liquid-Level Detection System General Power Requirements The ST-15C-WX units consume less than 20 watts of line power per channel exclusive of controlled circuits and alarm devices. Models ST-15-115-WX operate from100-140 VAC, 50-60Hz mains power, Models ST-15-230-WX operate from 200-250 VAC, 50-60 Hz mains power.
  • Page 6: Installation

    ST-15-WX - Technical Manual Installation Mechanical Installation The ST-15-WX control unit must be installed in a NON-HAZARDOUS AREA. Normally the unit is installed in the control room of a storage tank arena. It may be installed outdoors in its weather proof enclosure. Conduit entries must be properly sealed to keep water out of the enclosure.
  • Page 7 Multi-Point Liquid-Level Detection System Installation 2.2.4.3 Probe Lead Wire Size The following table should be used to determine the appropriate wire size for ST-15-WX Control Module to sensor connections for distance between ST-15-WX and the sensor. Wire Size Feet (MM Maximum Run Length Feet (Meters) #16 (1.5) 400 (120)
  • Page 8: Operation

    ST-15-WX - Technical Manual Operation ST-15-WX control units are shipped with each channel set to provide high level alarming (alarm output when liquid touches a probe). If your application requires alarm when a sensor becomes “dry”, typical for low level sensing, consult the factory for wiring instructions. When system power is applied, all high-level alarm channels will produce alarm outputs (red lamp on and alarm buss energize) until their associated thermistor probes warm up.
  • Page 9: Maintenance

    LED. The modules must be removed as a unit and returned to the factory. Note: returns to the factory must be accompanied by an RMA number- The RMA number must be obtained from Scully Signal Company DO NOT ATTEMPT to service or adjust the ST-15-WX moduled without specific approval and instructions fro Scully Signal Company.
  • Page 10: Diagram Appendix

    ST-15-WX - Technical Manual Diagram Appendix DWG 21188 – Schematic ST-15-WX System Page 10.
  • Page 11: Dwg 61410 - Replacement Parts St-15-Wx3-12

    Multi-Point Liquid-Level Detection System Diagram Appendix DWG 61410 – Replacement Parts ST-15-WX3-12 61410 Rev A Page 11.
  • Page 12: Dwg 61413 - Field Wiring Diagram Models St-15-Wx3-4

    ST-15-WX - Technical Manual Diagram Appendix DWG 61413 – Field Wiring Diagram Models ST-15-WX3-4 Page 12.
  • Page 13: Dwg 61415 - Field Wiring Diagram Models St-15-Wx5-8

    Multi-Point Liquid-Level Detection System Diagram Appendix DWG 61415 – Field Wiring Diagram Models ST-15-WX5-8 61415 Rev B Page 13.
  • Page 14: Dwg 61419 - Field Wiring Diagram Models St-15-Wx9-12

    ST-15-WX - Technical Manual Diagram Appendix DWG 61419 – Field Wiring Diagram Models ST-15-WX9-12 61419 Rev B Page 14.
  • Page 15 Multi-Point Liquid-Level Detection System Notes Page 15.
  • Page 16 Scully is ISO certified and all of our products are 100% made in the U.S.A. In addition, we back up our products with the best service in the industry.
