1/4"
S.Z2091 Medium Shroud AF25 29
1/4"
S.Z2093 Large Shroud AF25 32
NOTE: CAST PARTS SUPPLIED WITH AF25 STOVE
CALIFORNIA PROPOSITION 65
WARNING: This product can expose you to chemicals including
benzene, which is known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information:
www.P65Warnings.ca.gov
OPERATION & INSTALLATION MANUAL
Manufactured By
Valley Comfort Systems Inc., 1290 Commercial Way, Penticton, BC, V2A 3H5, Canada
Phone: 250-493-7444 - Fax: 250-493-5833 - www.blazeking.com - info@blazeking.com
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
180-Z2091_Z2093 v1.03
October 17, 2018
Advertisement
Related Manuals for Blaze King S.Z2091
Summary of Contents for Blaze King S.Z2091
- Page 1 1/4” S.Z2091 Medium Shroud AF25 29 1/4” S.Z2093 Large Shroud AF25 32 NOTE: CAST PARTS SUPPLIED WITH AF25 STOVE CALIFORNIA PROPOSITION 65 WARNING: This product can expose you to chemicals including benzene, which is known to the State of California to cause cancer and birth defects or other reproductive harm.
- Page 2 1/4” 1/4” S.Z2091 Medium Shroud AF25 29 or S.Z2093 Large Shroud AF25 32 2091 (MEDIUM) or 2093 (LARGE) SHROUD TOP (supplied with kit) 2092(MEDIUM) or 2094(LARGE) SHROUD SIDE (supplied with kit) ITEM PART DESCRIPTION QTY. NUMBER 110.2016 AF25 CAST SHROUD TRIM TOP 110.2017...
- Page 3 1/4” 1/4” S.Z2091 Medium Shroud AF25 29 or S.Z2093 Large Shroud AF25 32 1. Fasten shroud top panel to stove using three 10x1/2” black screws. (FIG.1) FIG.1 2. Fasten shroud sides to stove using two 10x1/2” black screws per side.
-
Page 4: Handle Bracket
1/4” 1/4” S.Z2091 Medium Shroud AF25 29 or S.Z2093 Large Shroud AF25 32 3. Partially thread thirteen 10-24x1/4” machine screws with washers into the top, left, and right cast trim pieces. Leave at least a 1/16” gap between the washers and the cast face. - Page 5 1/4” 1/4” S.Z2091 Medium Shroud AF25 29 or S.Z2093 Large Shroud AF25 32 180-Z2091_Z2093 v1.03 October 17, 2018...
