PRESSURE GAUGE FOR RESISTANCE WELDING MACHINE

Thank you very much for purchasing the Miyachi Force Gauge MM-601B for

resistance welding machines.

This manual describes the operating procedure and precautions for the

MM-601B.

Please read this manual thoroughly to ensure proper operation of the

device. Keep the manual handy for future reference.

MM-601B

OPERATION MANUAL

HOLD

ZERO

PRESSURE GAUGE

MODEL MM

SENS OR

POWER

OFF

601B

R09M0835E-08

Table of Contents

Need help?

Do you have a question about the MM-601B and is the answer not in the manual?

Questions and answers

Summary of Contents for Miyachi MM-601B

Page 1 ZERO PRESSURE GAUGE MODEL MM 601B Thank you very much for purchasing the Miyachi Force Gauge MM-601B for resistance welding machines. This manual describes the operating procedure and precautions for the MM-601B. Please read this manual thoroughly to ensure proper operation of the device.
Page 2: Table Of Contents
MM-601B Contents 1. Special Notes ....................1-1 (1) Safety Precautions ......................1-1 (2) Precautions for Handling.....................1-4 (3) Before Use ..........................1-6 2. Features......................2-1 3. Packing List ......................3-1 (1) Main Body and Accessories....................3-1 (2) Options..........................3-1 4. Names and Functions of Each Part ..............4-1 5. Measurement Method..................5-1 6.
Page 3: Special Notes
MM-601B 1. Special Notes (1) Safety Precautions CAUTION Prior to use, read these “Safety Indicates operations and practices that may Precautions” carefully to gain a full result in personal injury or damage to the understanding of the proper method of equipment if not correctly followed.
Page 4 Do not use a damaged connecting cable or plug. A damaged cable or a plug can cause electric shock, short circuits and fire. If any part needs to be repaired or replaced, consult Miyachi or your distributor. Stop the operation if any trouble occurs.
Page 5 MM-601B CAUTION Remove any dust on the AC adapter and connect it securely. Dust and improper connection of the AC adapter may result in heat generation and fire. Hold the plug when plugging or unplugging the AC adapter. Do NOT pull on the power cord, as this may damage it, resulting in electric shock or fire.
Page 6: Precautions For Handling
MM-601B (2) Precautions for Handling • Do not install the device in the following locations: Damp areas (where the humidity is above 90%), areas exposed to large amounts of vibration or shock, dusty areas, areas near a high noise source,...
Page 7 MM-601B • Use only the included or specified chargers. • Do not charge for more than 48 hours. • Do not short-circuit the plug while the charger is connected to an outlet. • Do not short-circuit the connector of the charger using a screwdriver, etc.
Page 8: Before Use
MM-601B • Do not use the accessory charger for any unit other than the MM-601B. • Remove the charger from the outlet when it is not in use. (3) Before Use Install the attached ferrite core near the connector of the weld-force sensor (optional).
Page 9: Features
MM-601B 2. Features Model MM-601B is a device for measuring the pressure of the electrodes of resistance welding machines that use a load cell (Load converter). With the optional special sensor, this device can easily measure welding force over a wide range (0.2 kg –...
Page 10: Packing List
1023719 UB band UB-100 1040159 Operation manual M0835E 1006875 * The MM-601B-00-03 does not come with a charger. Use a charger with the following specifications. Output: 7 V±10%, 100 mA minimum Polarity: Negative Center (2) Options Item Model Item No.
Page 11: Names And Functions Of Each Part
MM-601B 4. Names and Functions of Each Part Front panel Side (1)Connector for pressure sensor (2)Liquid crystal SENSOR (8)Rear cover display (3)Power ON switch (4)Power OFF switch POWER ZERO HOLD (5)HOLD switch (6)ZERO switch PRESSURE GAUGE MODEL MM 601B (9)AC adapter...
Page 12 MM-601B (4) Power OFF switch When this switch is pressed, the power for this device is turned off. (5) HOLD switch To set or cancel the hold mode Pressing this switch places the LCD display in hold mode, fixing the measured-value display to the value when the switch is pressed.
Page 13 MM-601B (11) Connector for analog output This terminal is provided primarily to connect a measuring instrument such as an oscilloscope in order to monitor the applied force. When a force is applied to the force sensor, a voltage output is provided by the supplied analog output cable.
Page 14: Measurement Method
MM-601B 5. Measurement Method Caution • Prior to using the tester for the first time, be sure to charge the batteries, which may not be sufficiently charged immediately after purchase. Refer to “Chapter 6, (1) Charging” for the battery-changing procedure.
Page 15 MM-601B Welding Perform welding as slowly as possible so that no significant impact is applied to the weld-force sensor. Caution If “OVER!!” is indicated and the buzzer sounds intermittently at this time, stop welding immediately, as this indicates excessive weld force.
Page 16: Built-In Batteries
If this message appears, follow the steps described below to charge the batteries. In addition, keep in mind that you must fully charge the batteries prior to using the MM-601B for the first time. Note that this gauge can be used during charging.
Page 17: Replacement
MM-601B (2) Replacement The built-in batteries will last three to five years under normal usage conditions, and can be charged approximately 500 times for repeated use. (The service life varies depending on the frequency of use. The battery life will be shortened if stored for extended periods without being used.)
Page 18: Specifications
500 g (including leather case) Accessory charger* Input 100 V to 240 V AC, 50/60 Hz (MM-601B-00-00/01) * The MM-601B-00-03 does not come with a charger. Use a charger with the following specifications. Output: 7 V±10%, 100 mA minimum Polarity: Negative Center...
Page 19: Outline Drawing
MM-601B 8. Outline Drawing (Unit: mm) 8. Outline Drawing...
Page 20: Calibration
To maintain the performance of the MM-601B, it is necessary to calibrate it periodically. The calibration is carried out at our factory. Send us your weld-force sensor with the MM-601B for calibration. Because the conditions of degradation of the MM-601B differ depending on the operation environment, it is necessary to calibrate the MM-601B and the weld-force sensor together.
