OPERATION MANUAL
SINGLE CHANNEL DATA LOGGER
(WITH MICRO-SD CARD INTERFACE)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VZ-70 and is the answer not in the manual?

Questions and answers

Summary of Contents for ASHE VZ-70

  • Page 1 OPERATION MANUAL SINGLE CHANNEL DATA LOGGER (WITH MICRO-SD CARD INTERFACE)
  • Page 2 MODEL: VZ-70 DESCRIPTION The VZ-70 is a micro-controller based Digital process Indicator with data logging feature, offered in a highly compact, rugged and reliable execution. The instrument has three keys on the front panel, with which the operator can set the parameters and configure the instrument as desired.
  • Page 3 OPERATION & SETTINGS The front panel of the Digital process Indicator Controller is as shown below: The Digital Indicator Controller has a four-digit display window on the front panel for indicating the process value. Further, MICRO-SD CARD socket to Insert and Remove Micro-SD Card CONTROL KEYS The instrument has three keys on the front panel, functions of which are described below...
  • Page 4 ) keys. CONTROL SETTINGS INITIAL ALTERNATING FUNCTION PRESSED DISPLAY DISPLAY (POWER ASHE (POWER iPLO CP-F If Input Signal is below 3.8mA or is not connected. /CP-P iPHi If Input Signal is above 20 mA. CP-F Indicates Copy FAILED CP-P indicates Copy PASS If sensor is connected and input is between 4-20 mA, 000.0...
  • Page 5 CALIBRATION   All settings to be done using Increment ( ) and Decrement ( ) keys. ALTERNATING DISPLAY FUNCTION PRESSED DISPLAY Long Press This is Z setting. ERO CALIBRATION Increment 4 mA 0750  Apply 4 mA and save the counts by using key.
  • Page 6 ALTERNATING DISPLAY FUNCTION PRESSED DISPLAY Press (process Momentarily shows current time and then process 11.05 Decrement value) value  ) key Clearing Log Memory   All settings to be done using Increment ( ) and Decrement ( ) keys. ALTERNATING DISPLAY FUNCTION...
  • Page 7 TECHNICAL SPECIFICATIONS Model VZ-70(Single Channel Data Logger) Type Microcontroller based Digital Process Indicator with Data Logging Input Signal 4 to 20 mA DC. Display Seven-segment, Red LED display. Indications Four-digit display. Scale Range -999 to 9999 [Fully configurable]. Calibration Range May be calibrated as required.
