- Page 1 WHST│ │ Product Introduction - 1 - STA79-6-A Door opening obstacle avoidance radar PRODUCT MANUAL WHST CO., LTD. Factory 1, Wanchun High-tech Innovation Park, East Dist of Economic & Technological Development Zone, 241000 Wuhu, Anhui, China 2023.04...
-
Page 2: Table Of Contents
WHST│ │ Product Introduction - 2 - Directory 1. Product Introduction ................ - 4 - 2. Product description ................- 5 - 2.1 Technical index ................ - 5 - 3. Interface description ................ - 7 - 4. Radar installation method and size ..........- 8 -... - Page 3 WHST│ │ Product Introduction - 3 - Revision record Date Version Description Author 2023-4-26 V1.0 Initial version Yu Xuze...
-
Page 4: Product Introduction
STA79-6 Door Open Obstacle Avoidance Radar is an automotive radar product with ultra-high precision based on 79GHz millimeter wave technology independently developed by WHST Co., Ltd. The operating frequency of the radar is 77GHz-81GHz, and the frequency sweep bandwidth is as high as 4GHz. In addition to accurately detecting the... -
Page 5: Product Description
│ Product Introduction - 5 - 2. Product description 2.1 Technical index See Table 1 for the technical indicators of STA79-6-A type vehicle radar products. Table 1. STA79-6-A radar product technical indicators Product Features Door opening obstacle avoidance radar Frequency Range... - Page 6 WHST│ │ Product Introduction - 6 - Installation height 0.2m~0.5m 33.67 dBm RF output power Antenna gain 6 dBi...
-
Page 7: Interface Description
WHST│ │ Product Introduction - 7 - 3. Interface description Radar equipment terminal connector and wiring harness terminal connector are shown in Figure 2, and the wiring definition is shown in Table 2 Device side Figure 2 Schematic diagram of wiring... -
Page 8: Radar Installation Method And Size
WHST│ │ Product Introduction - 8 - 4. Radar installation method and size As shown in the radar size diagram in Figure 7, the product size is 106×97.8×27.3mm, and it is directly installed on the car body using reserved three-leg holes to ensure the installation strength. - Page 9 WHST│ │ Product Introduction - 9 - FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
