INSTALLATION, OPERATION
INSTALLATIONMANUAL
& MAINTENANCE MANUAL OF
ENERGYSTORAGESYSTEM(ESS)
STORION-SMILE-T10(INDOOR)
SMILE-G3-EVCT11
V01
Advertisement
Table of Contents
Summary of Contents for AlphaESS SMILE-G3-EVCT11
- Page 1 ENERGYSTORAGESYSTEM(ESS) Alpha ESS Co., Ltd. Alpha ESS Suzhou Co., Ltd. +86 513 8060 6891 +86 512 6828 7609 STORION-SMILE-T10(INDOOR) SMILE-G3-EVCT11 info@alpha-ess.com info@alpha-ess.com www.alphaess.com www.alphaess.com Building 10-A, Canal Town Industrial Park, 99 Taihu E Rd, Jiuhua Road 888, Nantong High-Tech Industrial...
-
Page 2: Table Of Contents
CONTENT Copyright Statement This manual is under the copyright of Alpha ESS Co., Ltd. with all rights reserved. Please keep INTRODUCTION the manual properly and operate in strict accordance with all safety and operating instructions 1.1 Safety and Warning in this manual. Please do not operate the system before read-ing through the manual. 1.2 Scope of Delivery 1.3 Liability Limitation 1.4 Product Overview... -
Page 3: Introduction
1.3 Liability Limitation operating instructions on the device and in the manual. Un-authorized AlphaESS will not assume any direct or indirect liability for any product damage or and non-professional service personnel should not re-move the cover of property loss caused by the following conditions: this device. -
Page 4: Product Overview
INTRODUCTION MOUNTING 1.4 Product Overview Mounting 2.1 Package Verification After receiving the charger, please unpack and check the following items: • Inspect the external appearance and notify the seller immediately if there is any damage. • Check the accessory type and quantity. If the quantity and/or type is incorrect, record 2.2 Installation Preparation 2.2.1 Tools Tool Name... -
Page 5: Ac Charger Mounting
MOUNTING MOUNTING 2.3 AC Charger Mounting 4. Secure the wall bracket to the wall with 4 M6x40 screws. (The EV Charger shall be mounted vertically.) 2.3.1 Mounting the EV Charger 5. Hang the EV charger on the wall bracket. 6. Secure the EV charger with 2 M4*10 screws and complete the installation. The steps to mount the AC Charger are listed below: 1. -
Page 6: Electrical Connection
The backup box does not support access to communication of ESS temporarily. 3.2 System Wiring Diagram 3.3 Overview of the Connection Area To combine with the AlphaESS energy storage system, the EV charger should be installed 3.3.1 EV Charger Appearance as the diagram below. -
Page 7: Ac Wiring
The communication between the EV Charger and EMS of the energy storage system is 1. Remove a length of 43mm of the cable jacket and strip the wire insulation to a length of 10mm. RS485. RJ45 PIN definition is as below: EV AC Charger – SMILE-G3-EVCT11 RJ45 PIN4 PIN5 RS485... - Page 8 SYSTEM CONFIGURATION AND OPERATION ELECTRICAL CONNECTION 3.5.2 Communication Connection with SMILE-G3 Series System Configuration and Operation 4.1 Configuration To integrate the EV charger with the energy storage system, please ask the installer to enter the serial number of the EV Charger on the server. Communication Cable (Self made) Communication port...
-
Page 9: System Configuration And Operation
SYSTEM CONFIGURATION AND OPERATION SYSTEM CONFIGURATION AND OPERATION 4.2 Setup on the AlphaCloud and App 4.2.1 Manual Setting After configuration, the end user can monitor and set up the EV charger on the AlphaCloud To charge the electric vehicle immediately, please click the “start” button or use the RFID and App. - Page 10 SYSTEM CONFIGURATION AND OPERATION SYSTEM CONFIGURATION AND OPERATION 4.2.4.1 Green Charge – Slow Charge The EV charging source is PV and batteries. If PV power is available, it will prioritize supplying other loads, then supply the EV charger and maximize the EV charging power, and then charge the batteries of the ESS. Any excess power will be fed back into the grid.
-
Page 11: Start And Stop Charging
SYSTEM CONFIGURATION AND OPERATION SYSTEM CONFIGURATION AND OPERATION 4.2.4.4 Specific Power Charge Mode 4.2.4.5 Mode Option Suggestion AC Output Power from AlphaESS Energy Storage <5kWp 5~10kWp >10kWp System & PV Inverter Grid Single Three Single Three Single Three On-Board Charger of Vehicle... -
Page 12: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING 5.2 Fault Code Troubleshooting Error Code Problems Possible Causes Solutions 5.1 Indicator State 1. Check the input voltage from the State Description LED Status backend. Input over The AC input volt-age OverVolt 2. If the voltage is over 276Vac for a voltage may be too high. - Page 13 TROUBLESHOOTING TROUBLESHOOTING Error Code Problems Possible Causes Solutions Error Code Problems Possible Causes Solutions 1. Check if the communication cable 1. Shut off the leakage current protection switch of the power connection is correct and firm. distribution cabinet immediately. Reverse Reverse connection 2.
-
Page 14: Specification Parameter
SPECIFICATION PARAMETER Specification Parameter Model SMILE-EVCT11 Basic Parameters Dimension (H x W x D) 340 x 250 x 142 mm Weight 3 kg Operating Temperature -30 ~ 50 °C Related Humility 15 ~ 90% Operating Altitude < 2000 m Warranty 2 Years Product Warranty Input AC Rated Voltage...
