- Page 2 Safety Instructions & Warnings Important Safety Instructions FCC Warnings • Read these Instructions. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: • Keep these Instructions. 1) This device may not cause harmful interference, and •...
- Page 3 Battery Warnings WARNING: To reduce the risk of electric CAUTION RISK OF ELECTRIC SHOCK shock, do not remove cover (or back). No DO NOT OPEN • WARNING: Do not ingest the battery, Chemical Burn user-serviceable parts inside. Refer servicing ATTENTION Hazard.
-
Page 4: Table Of Contents
Table of Contents Setup � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5 Features Includes Power... -
Page 5: Setup
Setup Features Includes • Bluetooth Wireless - range 60 ft. • AC/DC power adapter • EQ presets • USB input - up to 128GB, support MP3 • Microphone input (1/4") • Guitar input (1/4") • Headphone Jack (1/4") • Aux In (3.5mm audio input) •... -
Page 6: Overview
Overview Controls... - Page 7 Overview Controls 1. LCD Display Screen 8. Headphone Volume Turn to adjust volume of connected headphones. 2. Power/EQ 9. Master Volume Press to power ON. Press and Hold to power OFF. Turn to adjust volume of the speaker system. After power on, press to choose equalizer setting: 10.
-
Page 8: Top View
Overview Top View Headphone Jack Microphone Input (1/4" Jack) (1/4" Jack) BT Indicator - Receiver Guitar Input (1/4" Jack) Aux In (3�5mm audio input) RCA Stereo Output Phone/Tablet Slot DC Power Input USB Port Display Sound Effects (1-8) Sound Effect Jog Wheel Echo Effect Jog Wheel 1. -
Page 9: Connecting To Other Devices
Connecting to Other Devices Connect External Speakers Requires speaker wire (not included). Note: Connected speaker must have low impedance (between 4–8ohms) 1. Connect speaker wires to the External Speaker Ports on the unit by pressing down the red (positive terminal) and black (negative terminal) clips and inserting the speaker wire. -
Page 10: Pairing To A Bluetooth Device And Playing Audio Wirelessly
Connecting to Other Devices Pairing to a Bluetooth Device and Playing Audio Wirelessly After initial pairing to a Bluetooth device, the unit will stay paired unless unpaired manually by the user, or erased due to a reset of the device. If your device should become unpaired or you find it is unable to connect, repeat these steps. Audio played through Bluetooth will play in USB Modes. -
Page 11: Using The Aux In
Using the Aux In Audio played through the Aux In will play in USB Modes. 3.5 mm audio input cable not included. 1. Using a 3.5 mm audio input cable, connect the Aux In on the unit and the audio output/headphone jack on a smartphone, tablet, or other audio source. -
Page 12: Customer Support
Customer Support Contact Information Made Website: www.iLiveElectronics.com Email Support: prodinfo@dpiinc.com Green Email Parts: partsinfo@dpiinc.com Phone Support: 1-888-999-4215 Warranty For Warranty Information and the most up-to-date version of this User’s Guide, go to: www�iLiveElectronics�com International Support Protect for Today Sustain for Tomorrow To download this User’s Guide in English, Spanish, and French, or to get answers to frequently asked questions, visit the support section at: www�iLiveElectronics�com...
