Cleaning Instruction

During Season Care:

•
Before cleaning, be sure to turn off and unplug the unit.
•
Keep the fan clean. Carefully wipe the unit with a soft, damp cloth. Please be very cautious near the motor.
•
DO NOT immerse the fan in water and never allow water to drip into the Motor Housing.
•
Never use gasoline, benzene or thinner. This will damage the surface of the unit.
•
After cleaning, be sure to completely dry the unit with a cloth or towel.

After Season Care:

•
Your fan can be stored in the off-season.
•
Before putting the fan in storage, clean it thoroughly, cover it with a vinyl bag, and store it in a cool and dry place.
We recommend using the original (or appropriately sized) box.

SETTING UP

•
Carefully remove your fan from the box (please save the carton for off-season storage).
•
Make sure the unit is in the OFF position before plugging the unit into the outlet.
•
For shipping purposes, the fan is packed unassembled.

ASSEMBLY

1.
Remove the plastic set knob from the top of the large base tube.
2.
Place base cover over the large base tube (looks like a cup with 4 cut outs). This is to cover the screws, it is only
for aesthetic purposes; it is not necessary for the function of the fan.
3.
Pull the extension pole inside the large base tube up and replace the set knob on the top of the large base tube.
4.
Remove screws from cross base, put cross base underneath the large base tube and fasten base tube to base
with the screws. Lift the base cover if it is in the way.
