INSTALLATION AND MAINTENANCE MANUAL FOR
EXPLOSIONPROOF LIGHT FITTING
EXF450LED
1
Manual No.: I.EXF450LED.01
Release date: 28.09.2023
Edition: 1.0
Carefully
read
the
instructions
mounting the light fitting.
ATM Lighting sp. z o.o.,
ul. Maszynowa 30A,80-298 Gdańsk,
tel: +48 58 347 51 07, fax: +48 58 347 51 08
before
Advertisement
Table of Contents
Related Manuals for ATM Lighting EXF450LED
Summary of Contents for ATM Lighting EXF450LED
- Page 1 EXPLOSIONPROOF LIGHT FITTING EXF450LED Carefully read instructions before mounting the light fitting. Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08...
-
Page 2: Table Of Contents
TRANSPORT AND CONDITIOINS OF STORAGE ..............13 DISPOSAL OF WASTE EQUIPMENT..................14 WARRANTY ..........................14 Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08... -
Page 3: General Information
Ex marking: • For version EXF450LED - EY* - * - 24E - ** - ***** - ALU - GL - *** - **** - ** - *** II 2G Ex eb mb IIC T4…T5 Gb II 2D Ex tb IIIC T80°C…T115°C Db Manual No.: I.EXF450LED.01... - Page 4 IIIC combustible dusts and filaments belonging to explosion groups IIIA, IIIB, IIIC (all types of dusts). Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08...
- Page 5 EY4-1 -40°C … +55°C / -40°C … +45°C LED module risk group RG=1 Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08...
-
Page 6: Technical Information
50-60Hz; EXF450LED-EY3-2 198W module type EXF450LED-EY3-3 238W EXF450LED-EY4-1 207W VERSIONS Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08... - Page 7 Type EXF450LED-EY2 EXF450LED-EY3 EXF450LED-EY4 Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08...
-
Page 8: Photometrical Data
Failure to comply with rules of the installation and use can lead to personal injury or property • loses. ATM Lighting sp. z o.o. company takes no responsibility in such cases. Failure to comply with rules included in manual results with void of the manufacturer warranty. -
Page 9: Light Fitting Mounting
NECESSARY TOOLS 6. LIGHT FITTING MOUNTING The EXF450LED is shipped with mounting brackets designed to be mounted to the ceiling wall or pipe. VERSIONS OF MOUNTING Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023... -
Page 10: Electrical Connection
• check the effectiveness of grounding. Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08... - Page 11 If neutral line is damaged or voltage occurs in it, a floodlight or group of floodlights may start to work under larger than predicted load, witch in consequence may lead to damage of power delivery system. Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0...
-
Page 12: Conditions Of Safety Use
User must make inspection steps first. After opening: metal parts painting, condition of inner wiring and its mounting, insulating materials, cable glands gaskets, terminals. Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0... -
Page 13: Cleaning
All parts considered as a spare parts must be ordered at manufacturer of light fitting. Additionally, the replacement of the light source may be performed by ATM Lighting Sp. z o.o and specially trained personnel, using original components supplied by ATM Lighting Sp. z o.o. -
Page 14: Disposal Of Waste Equipment
All specific information can be found in document „General terms and conditions warranty ATM • Lighting sp. z o.o.” available at the website www.atmlighting.pl/en/ Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08... - Page 15 Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0 tel: +48 58 347 51 07, fax: +48 58 347 51 08...
- Page 16 ADDRESS: ATM Lighting sp. z o.o. ul. Maszynowa 30A 80-298 Gdańsk tel: +48 58 347 51 07 fax: +48 58 347 51 08 office@atmlighting.pl Manual No.: I.EXF450LED.01 ATM Lighting sp. z o.o., Release date: 28.09.2023 ul. Maszynowa 30A,80-298 Gdańsk, Edition: 1.0...
