USER MANUAL

Tips: Please read this manual carefully before use and keep it properly.

Do not ride until you know the performance of this product.

Table of Contents

Need help?

Do you have a question about the Mantis P6 and is the answer not in the manual?

Questions and answers

Summary of Contents for PXID Mantis P6

Page 1 USER MANUAL Tips: Please read this manual carefully before use and keep it properly. Do not ride until you know the performance of this product.
Page 2 Welcome Thank you for choosing PXID Mantis P6 electric bike (hereinafter referred to as Mantis P6 ). This bicycle is a safe and fashionable transpor- tation tool. Enjoy free riding and speed control from now on! In order to ensure the safety, please read this manual carefully before riding to meet the relevant conditions.
Page 3: Table Of Contents
Content 1. Must read before assembling and riding ......................1 2. Unboxing and checklist ............................3 3. Installation instructions ............................5 4. Operating instructions ............................7 5. Moving and storage instructions ........................11 6. User Maintenance Instructions .......................... 17 7. Frame code & motor code ..........................21 8.
Page 4: Must Read Before Assembling And Riding
1. Must read before assembling and riding 1. Please read this manual throughout before assembling this e-bike or the rider’s ﬁrst time riding it. 2. Before unboxing, please check the shipping damages on the box and take the photo(s) to record it. 3.
Page 5 Minimum age/height for use 16 years old You can choose the appropriate version according to your own needs, and in the future Mantis P6 will launch various optional upgrade accessories and color style kits, please consult your dealer for details.
Page 6: Unboxing And Checklist
2. Unboxing and checklist 1. Take the bike and all items on the Checklist out of the box. 2. Remove all wrapping materials and put them back into the box. 3. Recycle the box and wrapping materials after 15 days or when you decide to keep the bike.
Page 7 Accessories Key*3 Gasket*2 Headlight*1 Pedal*2 Front fender*1 Press block assembly*1 Handlebar assembly*1 M8*25 13-15 Screw*2 wrench * 1 Charger*1 User manual Hexagon wrench * 3 User manual * 1 Bike body*1 If there are missing parts or shipping damages to be found, please contact us within 15 days from receipt of the bike.
Page 8: Installation Instructions
3. Installation instructions (INSTRUCTIONS D'INSTALLATION) 1.As shown in the ﬁgure, the four screws on the 2. Place the press assembly, handlebar assembly, 3. As shown in the ﬁgure, use the 5 Allen wrench to press block assembly are twisted. and screws as shown in the picture, align the holes unscrew the four screws from the press .
Page 9 7. Tighten the screws with the 4 Allen wrench, and 8. Place the gasket inside of the bracket. 9. Place the M8*25 screws in the holes on both the front fender installation is complete. sides of the headlight. 10.Use the 6 Allen wrench to tighten the screws, 11.Install the pedals, ﬁrst distinguish between 12.Turn the pedal in clockwise slowly with your and the headlight installation is complete.
Page 10: Operating Instructions
4. Operating instructions (INSTRUCTIONS D'UTILISATION) Cushion LED light Battery lock Front fender Shock absorber Battery pack Reflector Front fork Rear disc brake Front disc brake Kickstand...
Page 11 Dashboard Multi-function button Disc brake handle Power lock Electric horn Rear lamp Reflector Charge port Pedal Front tire Motor Rear tire...
Page 12 Display Error code Headlight Battery Total milage Trip mileage Max speed Mode Average speed Speed km/h Current speed Walk...
Page 13 Head combination switch Add speed button Info-switch button Headlight button Reduce speed button Power button Electric horn Throttle Long press to start working and power the controller. In the boot state, long press the button to turn Power button off the power supply. Short press key to switch the electric vehicle power gear to change the output power of the motor.
Page 14 Error code meaning sheet Error number Failure type Error number Failure type E001 Controller error E004 Throttle error E002 Communication error E005 Brake lever error E003 Motor hall error E006 Motor error...
Page 15: Moving And Storage Instructions
5. Moving and storage instructions (INSTRUCTIONS DE DÉPLACEMENT ET DE STOCKAGE) Check before riding To reduce the occurrence of accidental injuries, the following items should be checked before each ride: Check bike status, tire and brake effect, etc. Ensure that no parts including the handlebars, risers, tires, brake lines, brake handles, fenders, and screws show any signs of loosening or damage.
Page 16 caution. Before riding at night make sure that reflectors are installed on your e-bike. Riders should wear bright-colored clothing at night. Max weight The e-bike can safely carry a total weight of 310 lbs. The recommended loading is 300 lbs.Heavier loading than 310 lbs will affect the e-bike performance.
Page 17 Helmet Protective 1. Preparation:There is a risk of falling and injury, so wear a helmet and 2. Operating: ① Use the key to turn on the power lock.②Press protective gear all the time. on/off to unlock and power on; and check battery status, if the charge is too low, please charge it immediately.
Page 18 6. Turning: When turning, lean your center of 7. Warning: remind other pedestrians and 8. Get off: After riding, stop the bike on the gravity slightly and slowly turn your handle. vehicles to ensure driving safety. flat road and turn off the power, put down the Kickstand.
Page 19 Due to battery itself consumption during transportation and storage, it is normal for the battery to be low or no battery when used for the ﬁrst time. Please follow these charging steps to charge . You can choose two ways for charging: outside charging and whole scooter charging. Do not allow minors to use the charging equipment. Whole vehicle charging Find the charging port on the right side of the bike body, open the rubber plug of the charging port, connect the output end of the charger, then connect the power supply, and fasten the rubber plug after charging.
Page 20 External charging Take out the battery, open the rubber plug of the charging port, ﬁrst connect the output end of the charger to the charging port of the body, then turn on the power supply, and fasten the rubber plug after charging. Warning 1.
Page 21: User Maintenance Instructions
6. User Maintenance Instructions (INSTRUCTIONS DE MAINTENANCE DE L’UTILISATEUR) Users should obey the following tips to maintain electric bicycles: Clean Wipe the main frame clean with a soft damp cloth. For hard-to-clean stains, use a professional cleaner to scrub repeatedly, and then clean with a soft damp cloth.
Page 22 pressure, rain, moisture and violent collision are strictly prohibited. Battery Maintenance and Recycling A well-maintained battery will keep running well even after many miles of driving. Generally speaking, a fully charged battery will use up its stored power in120-180 days after it is turned off. If it has not been used for a long time, it should be charged every 30-60 days. Charge the battery after each driving.
Page 23 be cut off immediately; After the battery is fully charged,cut off the power supply of charger ﬁrst, then unplug the charger. • After the charger has cooled down, tidy up the power cord and charging cable and place them in a safe place. Other •...
Page 24 Speciﬁc maintenance rules and items and requirements Maintenance time (month) Maintenance project Maintenance 1000 3000 5000 7000 9000 9000 mileage (km) Adjust or replace front and rear brakes Check handlebar steering Check the tire pressure Check the disc brake system Tighten main component Lubrication of main parts Front and rear...
Page 25: Frame Code & Motor Code
7. Frame code & motor code Motor numbering rules The number is engraved on the end cover of the motor, as shown in the ﬁgure below: Details of serial number: 135RX.R750-4820 230404 00001 0001 AKM: Company initials; 230404: Order year, month, day; 00001: Fixed code unchanged;...
Page 26: Warranty Service
8. Warranty service Part Warranty Period Warranty Scope Motor Quality fault/break down/performance failure 12 Months Battery Quality fault/power capacityis tested lower than 50% ofthe rated capacity. Controller 6Months Performance failure Electronic control unit Charger Performance failure Sensor 3Months Performance failure Display/Dashboard Performance failure Frame...
Page 27 Non-warranty provision 1. Unauthorized maintenance, misuse, collision, negligence, abuse, liquid entry, accident, change, incorrect use of accessories other than this product, or tear, change or anti-counterfeit labels. 2. The warranty period has expired. 3. Damage caused by force majeure. 4. It does not meet the conditions of performance failure listed in the following “Electric Bike Performance Error Sheet". 5.
Page 28: Safety Instructions
9. Safety instructions 1. Electric bikes are a recreational product. In order to ensure the safety of cyclists, please read this manual carefully before using this product, practice and master the riding skills through the correct guidance. If the rider is inexperienced or does not use in accordance with this manual, the company will not bear any responsibility for any damage.
Page 29 3. Please do not ride in bad weather or poor visibility (e.g. at night). Riding precautions 1. Only one person is allowed to ride the electric bike. Overloading is strictly prohibited! 2. Please wear helmets and knee and elbow pads when riding. Please use a good quality bicycle helmet. 3.
Page 30 2. Do not drive the electric bike when the ambient temperature exceeds the operating temperature of the product (please refer to the “Product speciﬁcations"), because low/high temperature will lead to the limitation of the maximum power and the degradation of the product perfor- mance.
Page 31: Legal Statements
10. Legal statements Product legal Statement The more familiar you are with this product, the safer you will be when riding. Please pay more attention on the followings: 1. Read the product instructions carefully. If you cannot ride the product according to the instructions, please do not attempt to ride the product.
Page 32 11. Do not park the product in the safety exit, evacuation passage and other prohibited parking areas. Do not throw or drop the product. Do not place the product on open flame or under high temperature. 12. Use the original battery pack and charge the battery with the original charger. Otherwise, the charger or battery may be damaged or safety risks may occur.
Page 33 22. If the product does not belong to the scope of warranty services, you need to pay for maintenance and related services. 23. If this product and its parts need to be repaired or replaced during use, please keep the relevant after-sales service information after repair or replacement.
