Metra Electronics Saddle Tramp INFKP2SPKSYS Installation Instructions Manual

WHAT'S IN THE BOX
Harley-Davidson
Street Glide and Road Glide 2014-2022
Infinity and Saddle Tramp two speaker kit
Visit metraonllne.c om to view the available installation parts and Motorcycle
accessories. Not compatible with the Rockford Fosgate OE system.
KIT FEATURES
• Kappa Perfect 6.5" speakers
• All installation equipment provided
• For 2014-2022 Harley Davidson Street and Road Glide
motorcycle fairings
• A) One 4 Channel Kappa Perfect Amplifier• B) One pair of Kappa Perfect 600x • C) Saddle Tramp DSP/lnterface
• D) Street and Road Glide Amplifier brackets • E) Plug-n-Play Harnessing • F) Dual Amplifier power harness
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver• Allen wrenches (5/32" and 3/16") • Torx sockets (T25, T27, T40)
• Socket set
(7
/16" short and deep well)
le
Worlfs IMst •• •
~
TABLE OF CONTENTS
Fairing disassembly
Street Glide ................................................... 2-4
Road Glide ..................................................... 5-6
Fuel tank removal... ........................................... 7-8
Speaker pod assembly
Street Glide ....................................................... 9
Road Glide ....................................................... 10
Harness routing and installation ......................... 11
Amplifier mount
Street Glide ................................................. 12-13
Road Glide ....................................................... 14
Wire routing ..................................................... 15-18
Amp bypass installation plugs ........................... 19
Attention! With the key out of the ignition,
disconnect the negative battery terminal
before Installing this product. Ensure that all
lnstallatlon connections are secure before
cycling the ignition to test this product.
