Summary of Contents for RESISTANCE SRS-G60-15V3-4K
- Page 1 User Manual SRS-G60-15V3-4K...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Notice Notice ...................... 2 Preface ....................5 The information in this user’s manual is protected by copyright laws, all parts of this manual, including the products and software described in it, can not be reproduced, transmitted, transcribed, 1.1 Regulations Information.............. -
Page 3: Preface
4.1 About BIOS Setup ................32 4.1.1 When to Use BIOS Setup ? ............32 4.1.2 How to Run BIOS Setup ? ............32 4.2 BIOS Setup Menu................33 4.2.1 Main Menu ..................34 Chapter 1 4.2.2 Advanced Menu ................36 Preface 4.2.3 Security Menu................ -
Page 4: Regulations Information
1.2 Safety Instructions 1.1 Regulations Information CE compliance ¤ This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU(equals A2 : 2013) , - R&TTE Directive 1999/5/EC... -
Page 5: Conventions For This Manual
1.3 Conventions for this Manual 1.4 Release History Version Date Revision CAUTION : This message contains important information that must be followed for safe operation. Initial release 09/2017 NOTE : This message contains information for special situations. Notebook Manual Notebook Manual English English English... -
Page 6: Getting To Know The Basics
2.1 Product Specification This User’s Manual provides technical information of instructions and illustrations on how to operate this notebook for the customer. Please read this manual carefully before using this notebook. ・Physical Characteristic Chapter 2 Dimension Getting to know the basics 374.6*260*29.5 (28.25Thermal )mm 2.5kg ・CPU... - Page 7 ・I/O Port ・Input DC-in Keyboard USB 3.0 X2 *15.6" KB with 4 Zone backlight support, full KB size w/ numeric keys USB 2.0 X 2 *Full ME 15.6" KB (with numeric keys) with RGB backlight support USB 2.0 X 2 (Left side,option) USB 3.0 X 1 (Type C no Audio and Video support) Pointing Device ...
-
Page 8: Preparing Your Computer
2.2 Preparing your Computer ・Power Connect the AC adaptor DC output plug to the DC IN jack. AC Adapter Automatic Voltage adjustment between 100 and 240VAC 50/60Hz, 150 Watts (19V/7.89A), 3 Pins 180 Watts (19.5V/9.23A), 3 Pins Battery Li-polymer Battery (Power), 46.74WH (3S1P) The display panel can be opened to a wide range of angles for... -
Page 9: Product Overview
Webcam 2.3 Product Overview A device that allows you to record video or take photographs with your Please become familiar with each component before you operate computer. the computer. Camera Status LED Top-Open View The Camera Status LED shows the Camera status. NOTE: The product’s color, I/O port, indicator location, and specification will Microphone depend upon the actually shipping product. - Page 10 Left Side View Bottom Side View NOTE : The product’s thermal vent will depend upon the actually shipping product. USB Ports X2 (Option) Right Side View 2 in 1 Card Reader Insert Memory Card. USB Ports Vents Connects an USB device. The thermal vents are designed to cool the internal components and avoid overheating.
- Page 11 HDD / RAM / SSD / WLAN Compartment View Front Side View (Optional) Subwoofer Stereo speakers Produce stereo sound. WLAN BATTERY SSD SSD by2 by4 Projection light Default: Red Power ON: ON Suspend Mode: Blinking Red slowly FAN full speed: Blinking Red fast Power off (S4/S5): OFF;...
-
Page 12: Getting Started
Back Side View Chapter 3 Vents Getting started The thermal vents are designed to cool the internal components and avoid overheating. Power Connector Connect the AC adapter into this connector. HDMI port Supports high-definition digital video connections. Network Jack Connect an Ethernet cable to this port. USB Port USB Port Connects an USB device (such as USB drive, keyboard or... -
Page 13: Ac Adapter
3.2 Knowing the Keyboard 3.1 AC Adapter Please be noted that it is strongly recommended to connect the The following defines the colored hot keys on the Keyboard. AC adapter and use the AC power while using this notebook for the first time. -
Page 14: For Keyboard Users
Function Keys 3.2.1 For keyboard users To activate these functions, press the hot key associated with the desired Keypad Function Description function as below : Keyboard Press this key combination (Fn+F6) Function Keys Brightness Keyboard to decrease brightness of down: Keypad Function Description Keyboard... -
Page 15: Using The Touchpad / Clickpad
Function Keys 3.3 Using the touchpad / clickpad The touchpad / clickpad is a rectangular electronic panel Keypad Function Description located just below your keyboard. You can use the static- sensitive panel of the touchpad / clickpad and slide it to move Search: Press this key combination (Windows the cursor. -
Page 16: Bios Setup
3.3.1 Touchpad Usage Touch Pad Gesture Modern touchpad gesture: A modern touchpad should support the core touch gestures described in the following table. Chapter 4 BIOS setup Item Gesture name Gesture left click/double click one finger move cursor tap+slide scroll/pan two finger pinch/zoom three finger... -
Page 17: About Bios Setup
4.1 About BIOS Setup 4.2 BIOS Setup Menu 4.1.1 When to Use BIOS Setup Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Suggested only for advanced users. You may need to run BIOS setup when: Main Menu ・... -
Page 18: Main Menu
4.2.1 Main Menu Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) to 12 Month (Month) (December). Date (Date) The date from 01 to 31. Year (Year) The year can be adjusted by users. ・Total Memory This allows you to see the total amount of memory. -
Page 19: Advanced Menu
4.2.2 Advanced Menu ・NVMe Device It will show NVMe Device info. ・Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. ・RAID mode reminder Please update strip size in BIOS to 128K in order for RAID to optimize performance. -
Page 20: Security Menu
4.2.3 Security Menu Select Change User Password to give or to clear password setting same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any change. -
Page 21: Boot Menu
4.2.4 Boot Menu 4.2.5 Exit Menu ・Boot Configuration ・Save Changes and Reset Configure Settings during System Boot. Exit system setup after saving the changes. F4 key can be used for this operation. ・LAN Remote Boot [Disable]: Boot from LAN or not. ・Discard Changes and Exit ・Set Boot Priority (1st/2nd/3rd/..
