HHT Handheld
Quick Start Guide
Aarcomm's HHT Handheld Quick Start Guide provides
support for the following items, included in your HHT
remote control system:
•
HHT handheld
•
C220/C200 receiver
•
Antenna
•
Charging cradle
•
Wiring harness
POWERING ON THE HANDHELD
The HHT handheld requires a special sequence to turn on to
ensure all buttons are working correctly prior to start up, and
minimize any accidental powering up of the handheld.
To power up the HHT:
•
Press and hold the
RED BUTTON
•
Press and hold the
GREEN BUTTON
•
Release the
RED BUTTON
•
Release the
GREEN BUTTON
Regular flashing
GREEN
LED:
System turned on but no link.
Solid, or short flashes of
GREEN
System turned on and linked.
LED:
MATCHING INSTRUCTIONS
FIRST METHOD
1.
Turn off the HHT
2.
Apply power to the C220.
3.
Momentarily ("blip") the power off to the C220 six to seven
times (i.e. power off for 1/2 second, power on for one sec-
ond; six times). Leave the power on after the sixth blip.
4.
The LED on the C220 will light up
5.
Continue with steps five to eight below in second method.
DARK
BLUE.
Advertisement
Summary of Contents for AARCOMM HHT Handheld
- Page 1 • Wiring harness POWERING ON THE HANDHELD MATCHING INSTRUCTIONS The HHT handheld requires a special sequence to turn on to FIRST METHOD ensure all buttons are working correctly prior to start up, and Turn off the HHT minimize any accidental powering up of the handheld.
- Page 2 The mounting location should be chosen such that the C220 antenna has the best possible line of sight with the HHT handheld in order to maximize the operating range. The standard antenna mount provided is an NMO type. It requires a 3/4” hole.
