ORIGINAL OPERATING INSTRUCTIONS
Thank you for buying a WORKPRO 20V cordless drill driver set. Your new cordless drill driver has been engineered
and manufactured to WORKPRO's high standard for dependability, ease of operation, and operator safety. Properly
cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual.
SAVE THIS MANUAL FOR FUTURE REFERENCE
CORDLESS DRILL DRIVER
20V
LI-ION
2.0Ah
W009152A
W009153A
Distributed by
Hangzhou GreatStar Industrial Co., Ltd.
No.35 Jiuhuan Road, Jiubao Town,
Hangzhou 310019, China
www.greatstartools.com
Advertisement
Table of Contents
Summary of Contents for Work Pro W009152A
- Page 1 W009152A W009153A ORIGINAL OPERATING INSTRUCTIONS CORDLESS DRILL DRIVER LI-ION 2.0Ah Thank you for buying a WORKPRO 20V cordless drill driver set. Your new cordless drill driver has been engineered and manufactured to WORKPRO's high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Caution Environmental protection Disposal of an exhausted battery pack Description of symbols General safety rules Additional safety instructions Additional safety instructions for the charger Additional safety instructions related to the battery pack and battery safety When to charge the battery Component list and specifications Operating instructions 8-10... -
Page 3: Caution
CAUTION! Carefully read through this entire Instruction Manual before using your new Workpro Power Tool. Take special care to heed the Cautions and Warnings. Your Workpro power tool has many features that will make your job faster and easier. Safety, performance, and dependability have given top priority in the development of this tool, making it easy to maintain and operate. -
Page 4: General Safety Rules
reduce personal injuries. GENERAL SAFETY RULES c. Prevent unintentional starting. Ensure the switch is WARNING. Read all safety warnings and all in the off-position before connecting to power instructions. Failure to follow the warnings and source and/or battery pack, picking up or carrying instructions may result in electric shock, fire and/or the tool. -
Page 5: Additional Safety Instructions
g. Use the power tool, and accessories in accordance Keep your hands away from under the workpiece. with these instructions, taking into account the Never use your hands to remove sawdust, chips or working conditions and the work to be performed. waste close by the blade. -
Page 6: Additional Safety Instructions Related To The Battery Pack And Battery Safety
Never charge your lithium ion battery below or battery pack. above temperatures recommended otherwise fire Do not use the charger if it has been subjected to a or serious damage to the battery pack may occur. heavy knock, dropped or otherwise damaged in anyway. -
Page 7: When To Charge The Battery
open or cracks, immediately discontinue its use and do pack, repair or modify any part of the battery pack not recharge it. Ensure the battery pack clip is in assembly. good condition and will not allow the pack to fall ... -
Page 8: Component List And Specifications
COMPONENT LIST SPECIFICATIONS Charger:...........100-120V~50/60Hz 3/8"(10mm) Keyless Chuck Battery:..............2.0Ah Torque Adjustment Ring Charging Time:............1H Two-speed Gear Control Drill No Load Speed:....... 0-360/0-1300/min Forward/Reverse Rotation Control Torque Settings: .............18+1 Belt Clip Torque: ............. 25 N.M. Battery Pack Drill Chuck Capacity: ......3/8"(10mm) keyless Battery Pack Release Button Max Drilling Capacity Steel / Wood: ....... -
Page 9: Operating Instructions
OPERATING INSTRUCTIONS Fig. A WARNING! Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of California to cause cancer . Avoid inhaling wood dust or use a dust mask or other safeguards for personal protection. - Page 10 3. Reversible (Fig. C1, C2) Fig. D For drilling and screw driving use forward rotation (4) marked “ ” (lever is moved to the left). Only use reverse rotation marked “ ” (lever is moved to the right) to remove screws or release a jammed drill bit. WARNING: Never change the direction of rotation when the chuck is rotating, wait until it has stopped!
-
Page 11: Problem Solution
PROBLEM SOLUTION Fig.H 1. Why Does The Drill Not Turn On When You Press The Switch? The forward/reverse rotation control, which is on top of the trigger, is positioned in the lock function. Unlock the forward/reverse rotation control by putting it into the required rotation position. -
Page 12: Maintenance
MAINTENANCE BATTERY CAPACITY INDICATOR Battery capacity indicator Clean the drill driver using a soft, damp cloth. Do Press the battery capacity indicator switch.The battery not use detergents or flam mable products which capacity indicator shows the charge status of the may damage the tool.
