Installing and Maintaining
BN Platforms
Part No. 109352-E Rev. A
December 1996

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BN Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bay Networks BN Series

Summary of Contents for Bay Networks BN Series

  • Page 1 Installing and Maintaining BN Platforms Part No. 109352-E Rev. A December 1996...
  • Page 2 In the interest of improving internal design, operational function, and/or reliability, Bay Networks, Inc. reserves the right to make changes to the products described in this document without notice. Bay Networks, Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3 EN 55 022 Declaration of Conformance This is to certify that the Bay Networks products in this book are shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022:1987 Class A (CISPR 22:1985/BS 6527:1988).
  • Page 4 Compliance with the applicable regulations is dependent upon the use of shielded cables. The user is responsible for procuring the appropriate cables. Read instructions for correct handling. Bay Networks, Inc. 4401 Great America Parkway, Santa Clara, CA 95054 8 Federal Street, Billerica, MA 01821...
  • Page 5 Attention: Les utilisateurs ne doivent pas procéder à ces raccordements eux-mêmes mais doivent plutôt faire appel aux pouvoirs de réglementation en cause ou à un électricien, selon le cas. Bay Networks, Inc. 4401 Great America Parkway, Santa Clara, CA 95054...
  • Page 6 Attention: Les utilisateurs ne doivent pas procéder à ces raccordements eux-mêmes mais doivent plutôt faire appel aux pouvoirs de réglementation en cause ou à un électricien, selon le cas. Bay Networks, Inc. 4401 Great America Parkway, Santa Clara, CA 95054...
  • Page 7 Concentrator Node, Feeder Node, Link Node) respecte les limites de bruits radioélectriques visant les appareils numériques de classe A prescrites dans le Réglement sur le brouillage radioélectrique du ministère des Communications du Canada. Bay Networks, Inc. 4401 Great America Parkway, Santa Clara, CA 95054 8 Federal Street, Billerica, MA 01821...
  • Page 8 file a complaint with the FCC. If you experience trouble with the CSU, please contact Bay Networks Technical Response Center in your area for service or repairs. Repairs should be performed only by service personnel authorized by Bay Networks, Inc.
  • Page 9 Use of the Software shall be limited to such Equipment and to such facility. Software which is licensed for use on hardware not offered by Bay Networks is not subject to restricted use on any Equipment, however, unless otherwise specified on the Documentation, each licensed copy of such Software may only be installed on one hardware item at any time.
  • Page 10 European Community, the Software Directive dated 14 May 1991 (as may be amended from time to time) shall apply for interoperability purposes. Licensee must notify Bay Networks in writing of any such intended examination of the Software and Bay Networks may provide review and assistance.] 10.

  • Page 11: Table Of Contents

    Contents About This Guide Audience ..........................xix Conventions ........................xx Acronyms .........................xxi Ordering Bay Networks Publications ................xxii Technical Support and Online Services Bay Networks Customer Service ...................xxiv Bay Networks Information Services ................xxv World Wide Web .......................xxv Customer Service FTP .....................xxv Support Source CD ....................xxvi CompuServe ......................xxvi...
  • Page 12 Powering On the BLN ....................1-12 LED Activation Sequence ..................1-13 Establishing a Local or Remote Connection to the BLN ..........1-14 Local Connection ....................1-14 Remote Connection ....................1-15 Chapter 2 Installing the Backbone Link Node-2 Backbone Link Node-2 Overview ...................2-2 Preparing for Installation ....................2-3 Shipment Contents ....................2-3 Cables ........................2-4 Additional Equipment ....................2-4...
  • Page 13 Environmental Requirements ................3-8 Setting Up the Backbone Concentrator Node ..............3-8 Attaching Angle Brackets ..................3-8 Installing the BCN ....................3-12 Powering On the BCN or BCN RLC ................3-15 LED Activation Sequence ..................3-17 Establishing a Local or Remote Connection to the BCN ..........3-20 Local Connection ....................3-20 Remote Connection ....................3-21 Chapter 4...
  • Page 14 Appendix A Dial-Up Services Modems Adtran DSU III AR ......................A-2 Codex 3260 ........................A-3 Codex 3261 Fast ......................A-4 Multi-Tech Multi-Modem ....................A-5 NEC N6450 Data Service Unit ..................A-6 NEC N963E Plus (RS232) ..................... A-7 Telebit T3000 ......................... A-8 Telebit T3000 (continued) ....................
  • Page 15 Figures Figure 1-1. Backbone Link Node (BLN) ..............1-2 Figure 1-2. Attaching Angle Brackets to Support the BLN .........1-9 Figure 1-3. Removing the Front Bezel from the BLN ..........1-10 Figure 1-4. Mounting the BLN to the Rack ...............1-11 Figure 1-5. BLN Front-Panel LEDs ................1-13 Figure 1-6.
  • Page 16 Figure 4-7. Inserting or Removing an Air Flow Module ..........4-10 Figure 4-8. Grasping the Air Flow Module ..............4-11 Figure 5-1. Removing a Flash or PCMCIA SRAM Memory Card ......5-4 Figure 5-2. Memory Card Read-Write Protect Switch ..........5-6 Figure 5-3. Link Modules and the SRM-L in a BLN ............5-9 Figure 5-4.
  • Page 17 Tables Table 1-1. BLN Shipment Contents ................1-3 Table 1-2. Tools and Equipment You Supply .............1-4 Table 1-3. Wall Receptacle Requirements ..............1-5 Table 1-4. BLN Dimensions ..................1-6 Table 1-5. BLN Thermal Output and Air Plenum Requirements .......1-6 Table 1-6. Total Space Required for BLN ..............1-6 Table 1-7.
  • Page 18 Table 6-1. Front-Panel LEDs ..................6-2 xviii 109352-E Rev. A...

  • Page 19: About This Guide

    About This Guide If you are responsible for installing and configuring Bay Networks Backbone Node hardware platforms, read this guide for installation instructions and user-serviceable hardware procedures for the Backbone Node family of ® ® high-speed hardware platforms (BLN , BLN-2, BCN, , and BCN RLC).

  • Page 20: Conventions

    Example: Pin 7 > 19 > 20 Indicates data that appears on the screen. screen text Example: Set Bay Networks Trap Monitor Filters vertical line ( Indicates that you enter only one of the parts of the command. The vertical line separates choices. Do not type the vertical line when entering the command.

  • Page 21: Acronyms

    Acronyms ANSI American National Standards Institute ATM Routing Engine Asynchronous Transfer Mode Backbone Node Backbone Concentrator Node BCN RLC Backbone Concentrator Node with Redundant Line Cord Backbone Link Node BLN-2 Backbone Link Node-2 British thermal unit DRAM dynamic random-access memory electromagnetic compatibility Electronic Industry Association FDDI...

  • Page 22: Ordering Bay Networks Publications

    Bay Networks Press at the following telephone or fax numbers: • Telephone - U.S./Canada 1-888-4BAYPRESS • Telephone - International 1-510-490-4752 • Fax 1-510-498-2609 You can also use these numbers to request a free catalog of Bay Networks Press product publications. xxii...

  • Page 23: Technical Support And Online Services

    Technical Support and Online Services To ensure comprehensive network support to our customers and partners worldwide, Bay Networks Customer Service has Technical Response Centers in key locations around the globe: • Billerica, Massachusetts • Santa Clara, California • Sydney, Australia •...

  • Page 24: Bay Networks Customer Service

    -- within approximately 4 hours. To purchase any of the Bay Networks support programs, or if you have questions on program features, use the following numbers: Region...

  • Page 25: Bay Networks Information Services

    files and documentation from across the Bay Networks product suite, including switching products from our Centillion™ and Xylogics ® business units. Central management and sponsorship of this FTP site lets you quickly locate information on any of your Bay Networks products. 109352-E Rev. A...

  • Page 26: Support Source Cd

    You can run a single version on Macintosh Windows 3.1, Windows 95, Windows NT, DOS, or UNIX computing platforms. A Web links feature enables you to go directly from the CD to various Bay Networks Web pages. CompuServe For assistance with noncritical network support issues, Bay Networks Information Services maintain an active forum on CompuServe, a global bulletin-board system.

  • Page 27: Infofacts

    InfoFACTS is the Bay Networks free 24-hour fax-on-demand service. This automated system has libraries of technical and product documents designed to help you manage and troubleshoot your Bay Networks products. The system responds to a fax from the caller or to a third party within minutes of being accessed.

  • Page 29: Installing The Backbone Link Node

    Powering up the BLN and observing the hardware platform initialization sequence • Cabling a console or modem to the BLN to establish a Bay Networks Technician Interface session Danger: Due to high-energy hazards, only qualified service personnel with written authorization from Bay Networks are permitted to repair a BLN.

  • Page 30: Backbone Link Node Overview

    The BLN (Figure 1-1) uses a symmetric multiprocessor architecture with Fast ® Routing Engine (FRE and FRE-2) processor modules, or ATM Routing Engine (ARE) processor modules, along with the Bay Networks 1-Gb/s Parallel Packet ® Express (PPX ) processor interconnect. The BLN supports four routing engine modules and up to 16 LAN/WAN interfaces (up to four FDDI).

  • Page 31: Preparing For Installation

    Installing the Backbone Link Node Preparing for Installation To prepare for the BLN installation, verify the following: • Your BLN shipment arrived complete and undamaged • You have the proper tools and equipment • Your installation site meets all BLN site requirements •...

  • Page 32: Cables

    Tools and Equipment You Supply Item Quantity ANSI console or PC (to establish a Bay Networks Technician Interface session) Optional: 25-pin male to 9-pin female cable adaptor (needed only if you want to cable a PC directly to BLN to establish a local connection)

  • Page 33: Site Requirements

    Installing the Backbone Link Node Site Requirements To obtain satisfactory BLN performance, your site must meet all of the following electrical, space, and environmental requirements. Caution: Failure to adhere to these requirements may result in poor equipment performance. Electrical Requirements Your installation site must provide a power source that meets the electrical requirements listed below: •...

  • Page 34: Space Requirements

    Installing and Maintaining BN Platforms Space Requirements Make sure the installation site is large enough for the BLN and provides sufficient air plenum (a volume of free space surrounding the hardware platform for heat exhaust). Table 1-4 lists the dimensions of the BLN. Table 1-4.

  • Page 35: Environmental Requirements

    Installing the Backbone Link Node Environmental Requirements The installation site must meet the environmental requirements listed in Table 1-7. Table 1-7. Environmental Requirements Altitude Humidity Temperature 0 to 8000 ft 10% to 90% 0°C to 40°C (0 to 2400 m) noncondensing (32°...
  • Page 36 Installing and Maintaining BN Platforms If your rack does not have threaded holes, place cage nuts over the holes before you attach the angle brackets. Align the edge of the brackets to the rack as follows: -- If the interior of the rack contains horizontal bracket supports, align the angle bracket with the horizontal bracket support.

  • Page 37: Installing The Bln

    Installing the Backbone Link Node Height 8.75 in. (22.2 cm) Min. Depth 19.5 in. (49.5 cm) Min. Screw Rail (2 Places) Bracket (2 Places) Cage nut If rack rail is not threaded, attach cage nut. Figure 1-2. Attaching Angle Brackets to Support the BLN Installing the BLN This section describes how to install the BLN in an electronic enclosure rack.
  • Page 38 Installing and Maintaining BN Platforms Install the BLN in the rack as follows: Note: Before you place the BLN in the rack, ensure that the rack holes are threaded. If they are not threaded, place cage nuts over the front vertical support holes.
  • Page 39 Installing the Backbone Link Node Rail Cage nut Screw (4 Places) If rack rail is not threaded, attach cage nut. Figure 1-4. Mounting the BLN to the Rack Replace the front bezel as follows: Align the mounting retainers on the inside of the bezel with the holes on the front of the electromagnetic compatibility (EMC) shield.

  • Page 40: Powering On The Bln

    LEDs remain off, or if the DIAG LED does not turn on, turn the BLN power switch to the OFF position. Wait 1 minute and then turn the power switch to the ON position. If the problem persists, contact the Bay Networks Technical Response Center.

  • Page 41: Led Activation Sequence

    Installing the Backbone Link Node LED Activation Sequence The LEDs on the front panel of the BLN (Figure 1-5) activate while the BLN initializes and runs through its diagnostic test. Indicates power OK POWER Indicates router software is executing BOOT RESET Indicates one or more slots are booting DIAG...

  • Page 42: Establishing A Local Or Remote Connection To The Bln

    Installing and Maintaining BN Platforms The BLN indicates a successful start-up by turning off the BOOT LED. The POWER and RUN LEDs remain on. Refer to Chapter 6, “Switches and LEDs,” for a complete explanation of all Backbone Node LEDs. To activate the BLN on your IP network, refer to Quick-Starting Routers and BNX Platforms (router software), or to Configuring an Interface for Network Management (BayStream software).

  • Page 43: Remote Connection

    Installing the Backbone Link Node 100 - 240V~ 10.0A 50/60Hz Link Modules Console 1 SRM-L port ANSI console communications port Figure 1-6. Cabling the BLN to a Console Remote Connection This section describes how to cable your BLN to a modem for remote dial-in access.

  • Page 44: Table 1-9. Modem Operating Parameters

    Installing and Maintaining BN Platforms Table 1-9. Modem Operating Parameters (continued) Parameter Setting Data Terminal Ready (DTR) signal DTR signal fail-disconnect enabled (return to command mode, auto-answer off) Data Carrier Detect (DCD) signal DCD signal on while carrier present (the node uses DCD to detect modem disconnect) Local character echo...

  • Page 45: Installing The Backbone Link Node-2

    Powering up the BLN-2 and observing the hardware platform as it initializes • Cabling a console or modem to the BLN-2 to establish a Bay Networks Technician Interface session Note: This chapter describes how to install the AC version of the BLN-2. Only qualified service personnel are permitted to connect the DC version of the...

  • Page 46: Backbone Link Node-2 Overview

    Fast Routing Engine (FRE and FRE-2) processor modules, or ATM Routing Engine (ARE) processor modules, along with the Bay Networks 1-Gb/s Parallel Packet Express (PPX) processor interconnect. The BLN-2 supports four routing engine modules and up to 16 LAN/WAN interfaces (up to four FDDI).

  • Page 47: Preparing For Installation

    Installing the Backbone Link Node-2 Preparing for Installation To prepare for the BLN-2 installation, verify the following: • Your BLN-2 shipment arrived complete and undamaged • You have the proper tools and equipment • Your installation site meets all BLN-2 site requirements These requirements are described in detail in the next sections.

  • Page 48: Cables

    Tools and Equipment You Supply Item Quantity ANSI console or PC (for establishing a Bay Networks Technician Interface session) Optional: 25-pin male to 9-pin female cable adaptor (needed only if you want to cable a PC directly to BLN-2 to establish a local connection)

  • Page 49: Site Requirements

    Installing the Backbone Link Node-2 Site Requirements To obtain satisfactory BLN-2 performance, your site must meet all of the following electrical, space, and environmental requirements. Caution: Failure to adhere to these requirements may result in poor equipment performance. Electrical Requirements Your installation site must provide a power source that meets the electrical requirements listed below: •...

  • Page 50: Space Requirements

    Installing and Maintaining BN Platforms Space Requirements Make sure the installation site is large enough for the BLN-2 and provides sufficient air plenum (a volume of free space surrounding the BN for heat exhaust). Table 2-4 lists the dimensions of the BLN-2. Table 2-4.

  • Page 51: Environmental Requirements

    Installing the Backbone Link Node-2 Environmental Requirements The installation site must meet the environmental requirements listed in Table 2-7. Table 2-7. Environmental Requirements Altitude Humidity Temperature 0 to 8000 ft 10% to 90% 0°C to 40°C ∞ ∞ (0 to 2400 m) noncondensing F to 104 Setting Up the Backbone Link Node-2...
  • Page 52 Installing and Maintaining BN Platforms Locate the next two holes below this spot that have a 0.625-in. space between them. Note: The hole pattern shown in Figure 2-2 repeats on the rail. Mount the angle brackets in the area indicated by Figure 2-3. If your rack does not have threaded holes, place cage nuts over the holes before you attach the angle brackets.

  • Page 53: Figure 2-2. Locating The Mounting Holes

    Installing the Backbone Link Node-2 Router Flange Rack Post 1.4" 2.375" 1.750" Angle Bracket 1.125" Supporting Router 0.625" Mounted on Back of Rack Post Mounting Hole Locations Figure 2-2. Locating the Mounting Holes 109352-E Rev. A...

  • Page 54: Figure 2-3. Attaching Angle Brackets To Support The Bln-2

    Installing and Maintaining BN Platforms Height BLN-2 15.75 in. (40.0 cm) Minimum Depth BLN-2 23.9 in. (60.7 cm) Minimum Screw Rail (2 Places) Bracket (2 Places) Cage nut If rack rail is not threaded, attach cage nut. Figure 2-3. Attaching Angle Brackets to Support the BLN-2 2-10 109352-E Rev.

  • Page 55: Installing The Bln-2

    Installing the Backbone Link Node-2 Installing the BLN-2 Warning: The BLN-2 weighs approximately 125 lb. Do not attempt to lift it by yourself. Use a team of people or specialized lifting equipment. Before inserting the BLN-2 in the rack, ensure that all equipment already inside the rack is secure.
  • Page 56 Installing and Maintaining BN Platforms Insert the BLN-2 in the rack as shown in Figure 2-5. Make sure the BLN-2 rests squarely on the angle brackets. Insert and tighten the screws with a screwdriver until secure. Replace the front bezel as follows: Align the mounting retainers on the inside of the bezel with the holes on the front of the electromagnetic compatibility (EMC) shield.

  • Page 57: Powering On The Bln-2

    BLN-2 to the OFF position. Wait 1 minute and then turn the power switch to the ON position. If the problem persists, contact the Bay Networks Technical Response Center. After you power on the BLN-2, each routing engine automatically initiates a diagnostic test to verify proper board function.

  • Page 58: Led Activation Sequence

    Installing and Maintaining BN Platforms LED Activation Sequence The LEDs on the front panel of the BLN-2 (Figure 2-6) activate while the BLN-2 initializes and runs through its diagnostic tests. Indicates power OK POWER Indicates router software is executing BOOT RESET Indicates one or more slots are booting DIAG...

  • Page 59: Establishing A Local Or Remote Connection To The Bln-2

    You can cable a BLN-2 to an ANSI console or a PC to establish a local Technician Interface session, or to a modem to establish a remote session. Note: Bay Networks offers the cables for console connection. To activate the BLN on your IP network refer to Quick-Starting Routers and BNX Platforms (router software), or to Configuring an Interface for Network Management...

  • Page 60: Remote Connection

    Installing and Maintaining BN Platforms Insert the female end of the cable into the ANSI console communications port. Console SRM-L port ANSI console communications port Figure 2-7. Cabling the BLN-2 to a Console Remote Connection Note: Before you replace the local console connection with a modem connection, you must use the Technician Interface to configure the BLN-2 initial IP network interface.
  • Page 61 Installing the Backbone Link Node-2 Table 2-9. Modem Operating Parameters (continued) Parameter Setting Data Terminal Ready (DTR) signal DTR signal fail-disconnect enabled (return to command mode, auto-answer off) Data Carrier Detect (DCD) signal DCD signal on while carrier present (the node uses DCD to detect modem disconnect) Local character echo...

  • Page 63: Installing The Bcn And Bcn Rlc

    Chapter 3 Installing the BCN and BCN RLC You install the Backbone Concentrator Node (BCN) by • Preparing for installation • Setting up the BCN • Powering up the BCN and observing the hardware platform as it initializes • Cabling a console or modem to the hardware platform for access to the Bay Networks Technician Interface Note: This chapter describes how to install the Single AC Source (BCN) and Dual AC Source (BCN RLC) versions.

  • Page 64: Backbone Concentrator Node Overview

    Caution: Inspect all items for any shipping damage. In particular, ensure that the ports on the rear panel are not damaged. If you detect any damaged or missing items, do not attempt to install the BCN. Contact the Bay Networks Technical Response Center.

  • Page 65: Preparing For Installation

    Installing the BCN and BCN RLC POWER BOOT RESET DIAG B A C K B O N E N O D E Figure 3-1. Backbone Concentrator Node (BCN) Preparing for Installation To prepare for the BCN installation, verify the following: •...

  • Page 66: Shipment Contents

    Installing and Maintaining BN Platforms Shipment Contents Verify that the items in the BCN shipment match the items on the packing list affixed to the shipping container (Table 3-1). Table 3-1. BCN Shipment Contents Item Quantity Backbone Concentrator Node Site Manager Application Software (diskettes or CD-ROM) System software memory card (installed in unit) Hardware package for attaching angle brackets to the electronic enclosure rack:...

  • Page 67: Additional Equipment

    Tools and Equipment You Supply Item Quantity ANSI console or PC (to establish a Bay Networks Technician Interface session) Optional: 25-pin male to 9-pin female cable adaptor (needed only if you want to cable a PC directly to the BCN to establish a local connection)

  • Page 68: Electrical Requirements

    Installing and Maintaining BN Platforms Electrical Requirements The installation site must provide a power source that meets the following electrical requirement: 200 to 240 VAC at a maximum of 13 A @ 230 VAC. The power required for the BCN RLC is 100 VAC to 240 VAC at a maximum of 8a @ 230 VAC and 16a @ 100 VAC.

  • Page 69: Space Requirements

    Installing the BCN and BCN RLC Space Requirements Make sure the installation site is large enough for the BCN and provides sufficient air plenum (a volume of free space surrounding the hardware platform for heat exhaust). Table 3-4 lists the dimensions of the BCN. Table 3-4.

  • Page 70: Environmental Requirements

    Installing and Maintaining BN Platforms Environmental Requirements The installation site must meet the environmental requirements listed in Table 3-7. Table 3-7. Environmental Requirements Altitude Humidity Temperature 0 to 8000 ft 10% to 90% 0°C to 40°C (0 to 2400 m) noncondensing (32°F to 104°F) Setting Up the Backbone Concentrator Node...
  • Page 71 Installing the BCN and BCN RLC Router Flange Rack Post 4" 2.375" 1.750" Angle Bracket 1.125" Supporting Router 0.625" Mounted on Back of Rack Post Mounting Hole Locations Figure 3-2. Locating the Mounting Holes Mount the angle brackets in the area indicated by Figure 3-3. If your rack does not have threaded holes, place cage nuts over the holes before you attach the angle brackets.
  • Page 72 Installing and Maintaining BN Platforms Align the edge of the brackets to the rack: -- If the interior of the rack contains horizontal bracket supports, align the angle bracket with the horizontal bracket support. -- If the interior of the rack does not contain horizontal bracket supports, brace the angle bracket between the side rails.

  • Page 73: Figure 3-3. Attaching Brackets To Support The Bcn

    Installing the BCN and BCN RLC Height 28 in. (71 cm) Minimum Depth 28 in. (71 cm) Minimum Screw Rail (2 Places) Bracket (2 Places) Cage nut If rack rail is not threaded, attach cage nut Figure 3-3. Attaching Brackets to Support the BCN 3-11 109352-E Rev.

  • Page 74: Installing The Bcn

    Installing and Maintaining BN Platforms Installing the BCN Warning: The BCN weighs approximately 214 lb (97.07 kg). Do not attempt to lift it by yourself. Use a team of people or specialized lifting equipment. Before placing the BCN in the rack, ensure that all equipment already inside the rack is secure.
  • Page 75 Installing the BCN and BCN RLC Lift and remove the BCN from its shipping platform and place it gently on the floor. Caution: You can damage the front bezel if you attempt to remove it while the BCN is positioned on its shipping platform. Using both hands, pull on the top of the front bezel and remove it from the chassis (Figure...
  • Page 76 Installing and Maintaining BN Platforms Install the BCN in the electronic enclosure rack as follows: Note: Before putting the BCN in the rack, ensure that the rack holes are threaded. If they are not threaded, place cage nuts over the front vertical support holes.

  • Page 77: Powering On The Bcn Or Bcn Rlc

    Installing the BCN and BCN RLC Insert and tighten the screws with a screwdriver until secure. Replace the front bezel as follows: Align the mounting retainers on the inside of the bezel with the holes on the front of the electromagnetic compatibility (EMC) shield. Push the sides of the bezel into place.
  • Page 78 Installing and Maintaining BN Platforms BCN RLC Power supply Power supply S R M L 7 6 5 4 3 2 1 1 0 9 8 S R M L 7 6 5 4 3 2 1 Source Power supply Power supply Power supply Power supply...

  • Page 79: Led Activation Sequence

    BCN to the OFF position. Wait 1 minute and then turn the power switch(es) to the ON position. If the problem persists, contact the Bay Networks Technical Response Center. After you power on the BCN, each routing engine automatically initiates a diagnostic test to verify proper board function.

  • Page 80: Figure 3-9. Bcn Front-Panel Leds

    Installing and Maintaining BN Platforms Indicates power OK POWER Indicates router software is executing BOOT RESET Indicates one or more slots are booting DIAG Indicates diagnostic test execution or node failure Initializes (boots) the system Figure 3-9. BCN Front-Panel LEDs The LEDs typically activate in the following order (the sequence may vary slightly or overlap): The POWER and DIAG LEDs turn on.
  • Page 81 Installing the BCN and BCN RLC The BCN indicates a successful start-up by turning off the BOOT LED. The POWER and RUN LEDs remain on. Refer to Chapter 6, “Switches and LEDs,” for a complete explanation of all Backbone Node LEDs. To activate the BCN on your IP network, refer to Quick-Starting Routers and BNX Platforms (router software), or Configuring an Interface for Network Management (BayStream software).

  • Page 82: Establishing A Local Or Remote Connection To The Bcn

    You can cable a BCN to an ANSI console or a PC to establish a local Technician Interface session, or to a modem to establish a remote session. Note: Bay Networks offers the cables for console connection. If you plan to build your own cables, or if you want to order additional cables, refer to Cable Guide for Routers and BNX Platforms (router software) or Cable Guide (BayStream software).

  • Page 83: Remote Connection

    Installing the BCN and BCN RLC SRM-L (Slot 7) ANSI console SRML communications port Console port Figure 3-10. Cabling the BCN to a Console Remote Connection Note: Before you replace the local console connection with a modem connection, you must use the Technician Interface to configure the BCN initial IP network interface.

  • Page 84: Table 3-9. Modem Operating Parameters

    Installing and Maintaining BN Platforms Table 3-9. Modem Operating Parameters Parameter Setting Baud rate 9600 or less Auto answer Set on n rings with DTR active ( n must be greater than 0) Clear to Send (CTS) signal Always ON Data Terminal Ready (DTR) signal DTR signal fail-disconnect enabled (return to command mode, auto-answer off)

  • Page 85: Accessing The Interior

    Accessing the Interior Experienced network operators can safely perform the user-serviceable procedures that are described in Chapter 5. Only authorized Bay Networks service technicians can perform other procedures, not described in this book. Before you can perform user-serviceable procedures, you must access the interior of your Backbone Node hardware platform, as follows: •...

  • Page 86: Removing And Replacing The Front Bezel

    Installing and Maintaining BN Platforms Removing and Replacing the Front Bezel You must remove the front bezel (front cover) of BLN, BLN-2, and BCN routers to access their interiors. Note: Keep the front bezel on during normal operation to comply with air flow requirements.
  • Page 87 Accessing the Interior POWER BOOT RESET DIAG B A C K B O N E N O D E Pull Bottom Figure 4-2. Removing the BLN-2 Front Bezel Remove the front bezel from the BCN (Figure 4-3) as follows: Using both hands, pull the top of the front bezel forward. Remove the bezel from the chassis.

  • Page 88: Figure 4-3. Removing The Front Bezel From The Bcn

    Installing and Maintaining BN Platforms Pull Top POWER BOOT RESET DIAG B A C K B O N E N O D E Figure 4-3. Removing the Front Bezel from the BCN 109352-E Rev. A...

  • Page 89: Attaching The Antistatic Wrist Strap

    Accessing the Interior Attaching the Antistatic Wrist Strap Each BLN, BLN-2, BCN, and BCN RLC ships with an antistatic wrist strap. You must wear an antistatic strap whenever you • Remove, install, and handle memory cards • Remove, install, configure, and handle hardware modules, including Fast Routing Engine (FRE or FRE-2) modules, the SRM-F (System Resource Module-Front), or any link modules •...

  • Page 90: Removing And Replacing The Emc Shield

    Installing and Maintaining BN Platforms Figure 4-4. Connecting the Wrist Strap Jack to the Antistatic Receptacle Removing and Replacing the EMC Shield You must remove the electromagnetic compatibility (EMC) shield to access the memory cards and FRE or FRE-2 modules in the Backbone Node routers. Caution: Do not operate a hardware platform with the EMC shield removed for more than 5 minutes.
  • Page 91 Accessing the Interior Remove the EMC shield (Figure 4-5) as follows: Remove the front bezel. (Refer to “Removing and Replacing the Front Bezel” earlier in this chapter for instructions.) Loosen the captive thumbscrews that fasten the EMC shield to the chassis.

  • Page 92: Figure 4-5. Bln And Bcn Emc Shields

    Installing and Maintaining BN Platforms POWER WARNING VORSICHT! RESET BOOT HIGH ENERGY PRESENT HOCHSPANNUNG! B A C K B O N E N O D E DIAG Power unit OFF and disconnect power cord VOR jeglicher Intervention Gerat BEFORE accessing this product. ABSTELLEN und Netzstecker herauszuziehen! Refer to your installation/service manual for instructions Anleitungen in Installations-/Instandhaltungshandbuch beachten!

  • Page 93: Removing And Installing An Air Flow Module

    Accessing the Interior Removing and Installing an Air Flow Module Bay Networks ships an air flow module in each empty FRE/FRE-2 slot in the front of all Backbone Node routers. Each air flow module redirects cool air to the adjacent FRE or FRE-2 module.

  • Page 94: Figure 4-7. Inserting Or Removing An Air Flow Module

    Installing and Maintaining BN Platforms Remove the bracket. Pull the front of the air flow module forward to remove it (Figure 4-7.) Insert an air flow module as follows: Grasp the sides of the air flow module (Figure 4-8). Correctly position the back edge of the air flow module to accommodate the slot power connector and locating pin.

  • Page 95: Figure 4-8. Grasping The Air Flow Module

    Accessing the Interior This Edge Up for BLN Front Edge This Edge Up for BCN Space for Power Connector Space for Locating Pin Back Edge of Air Flow Module Figure 4-8. Grasping the Air Flow Module 4-11 109352-E Rev. A...

  • Page 97: Hot-Swapping Hardware Components

    Chapter 5 Hot-Swapping Hardware Components Depending on your hardware platform, you can replace the following user-serviceable hardware components: • Memory cards • Hardware modules -- Link modules -- Routing Engine (FRE/FRE-2/ARE) modules -- System Resource Module-Link (SRM-L) -- System Resource Module-Front (SRM-F) •...

  • Page 98: Replacing Flash And Pcmcia Sram Memory Cards

    Installing and Maintaining BN Platforms Table 5-1. User-Serviceable Components (continued) BLN-2 (Backbone (Backbone (Backbone Component Link Node) Link Node-2) Concentrator Node) SRM-F Modules Power Supplies Fans Depending on your model, you will need a Phillips screwdriver, a standard screwdriver, or both to replace hardware components. Replacing Flash and PCMCIA SRAM Memory Cards This section describes how to remove and replace a Flash memory card or a PCMCIA SRAM memory card (Order No.
  • Page 99 Hot-Swapping Hardware Components Memory Card Read-Write Protect Switch Memory cards are read-write protected. To change the protection on a memory card, you must physically remove the card from the BayStream hardware, change the protection, and reinsert the card. Failure to adhere to this sequence can cause unpredictable and undesirable consequences.

  • Page 100: Figure 5-1. Removing A Flash Or Pcmcia Sram Memory Card

    Replace the EMC shield. Replace the front bezel. If the memory card is new, and you did not obtain it from Bay Networks, you must format the card before attempting to write to it. Use Site Manager or the Technician Interface to format the memory card.

  • Page 101: Protecting Memory Card Files

    Hot-Swapping Hardware Components Protecting Memory Card Files Bay Networks ships each memory card with its Read-Write Protect switch in the unprotected position (Figure 5-2). After successfully loading the configuration file and saving your configuration, you may want to write-protect the memory card for backup purposes.

  • Page 102: Replacing Pcmcia Sram Memory Card Batteries

    Installing and Maintaining BN Platforms Unprotected Protected Figure 5-2. Memory Card Read-Write Protect Switch Reinsert the memory card into the card receptacle. Position the card with the label facing up and the INSERT arrow pointing toward the card receptacle. Insert the card into the card receptacle. Gently push the card in until it fits snugly into place.

  • Page 103: Replacing A Link Module Or Srm-L

    Hot-Swapping Hardware Components Caution: While the PCMCIA SRAM card is installed in a BayStream hardware platform, there is no drain on the 3-V lithium battery. Battery drain occurs only when the PCMCIA SRAM card is removed from the BayStream platform. To ensure data integrity, we recommend that the battery be replaced yearly.
  • Page 104 Installing and Maintaining BN Platforms When removing or installing a link module, keep the following in mind: • If you replace a link module with another of a different type (that is, you replace an Ethernet link module with an FDDI link module), you must first undo the configuration of all circuits on the old slot before the hardware platform software can properly configure the new module.

  • Page 105: Figure 5-3. Link Modules And The Srm-L In A Bln

    Hot-Swapping Hardware Components To Antistatic Receptacle In Front ( 100 - 240V~ 10.0A 50/60Hz Link Modules SRM-L Captive Screws Figure 5-3. Link Modules and the SRM-L in a BLN Remove a link module or SRM-L as follows: Disconnect any exterior cables from the module. Loosen the two captive screws on each end of the module.

  • Page 106: Figure 5-4. Link Modules And The Srm-L In A Bln-2

    Installing and Maintaining BN Platforms Captive Screws Link To Antistatic Modules Receptacle In Front ( ) SRM-L Figure 5-4. Link Modules and the SRM-L in a BLN-2 5-10 109352-E Rev. A...
  • Page 107 Hot-Swapping Hardware Components To Antistatic Receptacle In Front ( SRM-L (Slot 7) Link Modules Link Modules SRML Captive Screws Figure 5-5. Link Modules and the SRM-L in a BCN Install a link module or SRM-L as follows: Slide the module into the desired slot using the slot card guides. Insert the board until its connector panel touches the hardware platform rear panel.

  • Page 108: Replacing A Routing Engine Module Or Srm-F

    Connect the desired cables to the module. Note: We recommend that you issue the diags command to the associated slot, using the Bay Networks Technician Interface, immediately after you insert a link module. (Refer to Using Technician Interface Software.) Otherwise, the link module FAIL LED will remain lit, indicating diagnostics have not run on the ILI.

  • Page 109: Figure 5-6. Routing Engine Modules And The Srm-F In A Bln

    Hot-Swapping Hardware Components • Before removing or installing a module, you must first access the interior of your hardware platform. (Refer to Chapter 4, “Accessing the Interior,” for instructions.) Caution: Electrostatic discharge can damage hardware. Use the antistatic wrist strap when handling any hardware platform components. The procedures for replacing a routing engine processor module or an SRM-F are the same for the BLN, BLN-2, and BCN with one exception: you must first remove a board retainer bracket from the BLN or BLN-2 in order to gain access to...
  • Page 110 Installing and Maintaining BN Platforms FRE/FRE-2/ARE Processor Modules (Slots 2-5) POWER RESET BOOT DIAG B A C K B O N E N O D E To Antistatic Receptacle In Front ( ) SRM-F (Slot 1) Board Retainer Bracket Extractor (1 Screw) Figure 5-7.

  • Page 111: Figure 5-8. Routing Engine Modules And The Srm-F In A Bcn

    Hot-Swapping Hardware Components FRE/FRE-2/ARE Processor Modules SRM-F FRE/FRE-2/ARE Processor Modules POWER RESET BOOT DIAG B A C K B O N E N O D E Extractor 9 10 11 12 13 14 Figure 5-8. Routing Engine Modules and the SRM-F in a BCN 5-15 109352-E Rev.

  • Page 112: Figure 5-9. Location Of Power Switch On Fre/Fre-2 Module And Srm-F

    Installing and Maintaining BN Platforms Remove a routing engine module or SRM-F as follows: Gently pull the inside of the board extractors at the end of the module toward you. The extractors swing open, pushing the module out of the backplane connectors.
  • Page 113 When you insert a FRE/FRE-2 module, the DIAG LED turns on during diagnostics and then turns off if diagnostics determine that the FRE/FRE-2 is functional. Note: Contact the Bay Networks Technical Response Center if the DIAG LED does not turn off. •...

  • Page 114: Replacing A Power Module

    Installing and Maintaining BN Platforms Replace the EMC shield and front bezel. (Refer to Chapter 4, “Accessing the Interior,” for instructions.) Replacing a Power Module The BLN-2 supports two and the BCN supports four 620-watt power modules that are hot-swappable. You can easily access these power modules from the back of the hardware platform.
  • Page 115 Hot-Swapping Hardware Components Note: For the BCN RLC, note that only the two bottom power supplies are powered by Source A, and only the two top power supplies are powered by Source B. To keep the BCN RLC powered up while you turn off a power switch or remove a power cord for a power source, ensure that the other power source has two working power supplies.

  • Page 116: Replacing The Bln-2 Power Module

    Installing and Maintaining BN Platforms If you end up with a negative number, the power supplies cannot support the ILI configuration. Note: BCN Power - 3 power supplies support up to 13 ILIs. The fourth power supply will provide power supply redundancy (3+1). BCN RLC Power - 4 power supplies support up to 10 ILIs (maximum loading = output of 2 power supplies).

  • Page 117: Figure 5-10. Removing A Power Module From A Bln-2

    Hot-Swapping Hardware Components Figure 5-10. Removing a Power Module from a BLN-2 5-21 109352-E Rev. A...

  • Page 118: Replacing The Bcn Power Module

    Turn the captive screw no more than an additional 1/4 turn. Do not overtighten the screw. If the Power OK LED does not turn on, contact the Bay Networks Technical Response Center. Replacing the BCN Power Module You can remove and replace a power module in a BCN with the power on or off.

  • Page 119: Figure 5-11. Removing A Power Module From A Bcn

    Hot-Swapping Hardware Components Screw Figure 5-11. Removing a Power Module from a BCN Insert a BCN power module as follows: Grasp the handle and guide the module into the desired slot along the side guides and gently insert the module. Note: Stop when you feel resistance.

  • Page 120: Replacing A Fan Tray In A Bln-2

    Installing and Maintaining BN Platforms If the Power OK LED does not turn on, contact the Bay Networks Technical response Center. Replacing a Fan Tray in a BLN-2 The BLN-2 contains three fan trays — one double-fan tray under the front bezel and two single-fan trays in the rear of the unit.
  • Page 121 Hot-Swapping Hardware Components BLN-2 Fan Unit POWER BOOT RESET DIAG B A C K B O N E N O D E Fan Screw Figure 5-12. Double-Fan Tray in the BLN-2 Remove a single-fan tray from the rear of the BLN-2 as follows (Figure 5-13): Caution: Electrostatic discharge can damage hardware.

  • Page 122: Figure 5-13. Single-Fan Trays In The Bln-2

    Installing and Maintaining BN Platforms BLN-2 Fan Unit Fan Screws (2 Places) Figure 5-13. Single-Fan Trays in the BLN-2 Insert a fan tray as follows: Grasp the bottom of the fan tray and guide it into the slot until the connectors at the rear of the fan tray engage.
  • Page 124 Installing and Maintaining BN Platforms 5-28 109352-E Rev. A...

  • Page 125: Switches And Leds

    Chapter 6 Switches and LEDs Read this chapter for a description of the switches and LEDs on the front-panel of each Backbone Node hardware platform. This chapter also describes the LED on the 620-watt BLN-2, BCN, and BCN RLC power module. For a description of the LEDs on a link or processor module, refer to the installation guide for that module.

  • Page 126: Reset Switch

    Installing and Maintaining BN Platforms Reset Switch The Reset switch warm-starts the hardware platform. A warm-start is equivalent to issuing the command from Site Manager or the Technician Interface. boot Refer to Using Technician Interface Software (router software) or Administration Guide (BayStream software) for a description of the warm-start procedure.

  • Page 127: 620-Watt Power Module Led

    Switches and LEDs Table 6-1. Front-Panel LEDs Function BOOT Indicates software initialization and loading are taking place on one or more modules. The hardware platform indicates a successful startup by turning off the BOOT LED. DIAG Indicates diagnostic testing is taking place on one or more modules. Diagnostic testing occurs when you cold-start the hardware platform.

  • Page 128: Figure 6-2. 620-Watt Power Module Power Ok Led

    Installing and Maintaining BN Platforms Figure 6-2. 620-Watt Power Module Power OK LED The Power OK LED indicates that the hardware platform is powered on and that the power module is fully engaged and operational. 109352-E Rev. A...

  • Page 129: Appendix A Dial-Up Services Modems

    Appendix A Dial-Up Services Modems This appendix lists some modems that support Version 7 Dial-Up Services and provides configuration guidelines for specific setups. For additional information on configuring a specific modem, refer to the modem user documentation. 109352-E Rev. A...

  • Page 130: Adtran Dsu Iii Ar

    Installing and Maintaining BN Platforms Adtran DSU III AR V.35 connection and V.25bis setup: # from front panel to get menu 3 Config 1 Local Network Options Network Type = US Sprint SW56 Clock Source = Master DTE Options Connector Type = V.35 Data Format = Synchronous DTE Command Option = V.25 Sync CS Options = Follow RS...

  • Page 131: Codex 3260

    Dial-Up Services Modems Codex 3260 RS-232 connection using Raise DTR setup: ACU Options AT Form: DTR Dial (originating side), Sync Data (answering side) Default Dial #3 (originating side) = Off (answering side) Answer = Ring #1 (answering side) Select Options Originating side = 3 Answering side = 2 Dial From #3...

  • Page 132: Codex 3261 Fast

    Installing and Maintaining BN Platforms Codex 3261 Fast V.25bis setup: ACU Options Terminal Options ACU Select = v25b DTE Rate = 9600 AT form = ASYNC Flow = Tx Clk V25 form = Bitsync TPDly Min = Rx Clk NoAcuForm = Sync Speed Cover = On DefaultDial = 1 DTR = 108.2...

  • Page 133: Multi-Tech Multi-Modem

    Dial-Up Services Modems Multi-Tech Multi-Modem V.25bis setup: DIP Switches 1 : up 2 : up 3 : down 4 : up 5 : up 6 : down 7 : up 8 : down 9 : down 10 : up 11 : down 12 : up 109352-E Rev.

  • Page 134: Nec N6450 Data Service Unit

    Installing and Maintaining BN Platforms NEC N6450 Data Service Unit V.25bis setup: DTE Command Set = V.25 Sync V.35 TX Clock = Norm DTR = Go Idle with DTR DCD = Off when RX idle CTS = On with RTS only, CTS Delay short DSR = Off when Out of Service (OOS) only Sync or Async = Sync Auto Ans: Answer all the time...

  • Page 135: Nec N963E Plus (Rs232

    Dial-Up Services Modems NEC N963E Plus (RS232) V.25bis setup: Jumpers 1 : OFF 2 : ON V.25bis 3 : ON hdlc 4 : OFF speed 5 : OFF speed 6 : OFF ascii 7 : OFF 8 : OFF Raise DTR setup: Jumpers 1 : ON 2 : OFF sync...

  • Page 136: Telebit T3000 (Continued

    Installing and Maintaining BN Platforms Telebit T3000 When configuring the modem, place the A/B switch in the A position. Configuration A is the default terminal emulation. V.25bis setup: at&f16 – preset configuration att – enables dial tone at&w1 – save config to configuration B If the hardware platform is reporting AB errors, set ats64 = 1 Raise DTR setup: Originating Side...
  • Page 137 Dial-Up Services Modems Telebit T3000 (continued) Raise DTR setup (continued): Answering Side at&f16 – preset configuration att – enables dial tone ats104 = 4 – Raise DTR at~N1 = 5411 (telephone number) – B config uses phone #2 at~L – list phone numbers ats100 = 0 ats253 = 0 at&w1 - save config to configuration B...

  • Page 138: Tylink Sns 4000 (V.35 Isdn Pri Dsu

    Installing and Maintaining BN Platforms Tylink SNS 4000 (V.35 ISDN PRI DSU) - Tested in back-to-back IMUX mode - Tested with V.25bis only A-10 109352-E Rev. A...

  • Page 139: Index

    3-1 to 3-3 BLN-2, 2-16 Backbone Link Node (BLN) overview, 1-1 to 1-2 closing the router, 4-2 to 4-8 Backbone Link Node 2 (BLN-2) overview, 2-1 to CompuServe, Bay Networks forum on, xxvi console baud rate baud rate console BCN, 3-20...
  • Page 140 Installing and Maintaining BN Platforms BLN, 1-14 dimensions BLN-2, 2-15 BCN, 3-7 operating parameters BLN, 1-6 BCN, 3-20 BLN-2, 2-6 BLN, 1-14 BLN-2, 2-15 Customer Service FTP, xxv electrical requirements customer support. getting help BCN, 3-6 BLN, 1-5 BLN-2, 2-5 electronic enclosure rack data carrier detect installing in...
  • Page 141 LEDs BOOT, 6-3 DIAG, 6-3 GAME operating system, 6-3 front-panel, 6-1 getting help lighting sequence from a Bay Networks Technical Response BCN, 3-18 Center, xxvii BLN, 1-13 from the Support Source CD, xxvi BLN-2, 2-14 through CompuServe, xxvi POWER, 6-2...
  • Page 142 Installing and Maintaining BN Platforms operating parameters removal and replacement, 5-20 BCN, 3-22 Power OK LED. See power LED BLN, 1-15 power supply. See power module BLN-2, 2-16 powering on BCN, 3-15 BLN, 1-12 BLN-2, 2-13 opening the router, 4-2 to 4-8 failure and resetting operating parameters BCN, 3-17...
  • Page 143 Index requirements hot swapping, 5-12 to 5-18 air plenum removal and replacement, 5-12 to 5-18 BCN, 3-7 RUN LED BLN, 1-6 BCN, 3-18 BLN-2, 2-6 BLN, 1-13 altitude BLN-2, 2-14 BCN, 3-8 defined, 6-2 BLN, 1-7 BLN-2, 2-7 electrical BCN, 3-6 safety messages BLN, 1-5 BCN, 3-12...
  • Page 144 5-1 tools required for, 5-2 voltage requirements BCN, 3-6 BLN, 1-5 BLN-2, 2-5 wall receptacle BCN, 3-6 BLN, 1-5 BLN-2, 2-5 weight BCN, 3-12 BLN-2, 2-11 World Wide Web, Bay Networks home page on, Index-6 109352-E Rev. A...

This manual is also suitable for:

BlnBln-2BcnBcn rlc

Table of Contents
