FEATURES:
•
Acrylic display
•
Adjustable thermostat
•
Temperatures from 80°F to above 150°F
•
Stainless steel corners and base
•
Single-door Option - Operator Serve
Power Cord on Control/Door Side
•
2-door Pass-through Option
Recommended for Self/Customer Serve
•
Total height of available shelf space: 23"
• Unit comes with 4 shelves
AVAILABLE ACCESSORIES:
#10034
Additional Shelf
301 Meuse Argonne Hicksville, OH 43526
Visit us at www.nemcofoodequip.com for more information
GS1400-25
USER MANUAL
ELECTRICAL DATA:
VOLTS:
120
AMPS:
•
Best when operated on an individual branch circuit
• ' power cord length
6
DIMENSIONS:
• 18"W ×
18 D × 34"H
"
SHIPPING INFORMATION:
•
SHIPPING DIMENSIONS
: 26"W × 26"D × 45"H
•
SHIPPING WEIGHT
: 63 lbs.
• MUST SHIP VIA FREIGHT TRUCK
• P:800.782.6761 • F:419.542.6690
5.3
WATTS:
640
FP140208 REV: ORIG
Advertisement
Related Manuals for Global Solutions GS1400-25
Summary of Contents for Global Solutions GS1400-25
- Page 1 GS1400-25 USER MANUAL ELECTRICAL DATA: FEATURES: • Acrylic display VOLTS: AMPS: WATTS: • Adjustable thermostat • Temperatures from 80°F to above 150°F • Best when operated on an individual branch circuit • Stainless steel corners and base • ’ power cord length •...
-
Page 2: Equipment Setup
IMPORTANT: Read the following safety and operation instructions to avoid injury and to avoid damage to equipment or property. Plug unit into a properly grounded electrical outlet of the correct voltage, size, and plug configuration for this unit. We recommend usage on an individual branch circuit of at least 15 amps for best results. Failure to do so may result in decreased performance of the warmer. -
Page 3: Operation
OPERATION: This warmer is designed to maintain food product at or above the optimum temperature. It is not designed or intended to heat up or cook food to the serving temperature. Product is to be prepared to a temperature of above 160 ° F before placing in the warmer. Do not place product on its side as this will affect the internal holding temperatures of the product. - Page 4 TROUBLESHOOTING: Unplug unit from power source, and allow to cool completely before performing any maintenance or cleaning. Unit not working: • Check power switch position, power cord, and/or electrical circuit Display light not working • Tighten or replace bulb Loud noise coming from unit: •...
- Page 5 GS1400-25 Exploded View Controls Detailed Vi ew Controls Detailed Vi ew Rev. Date: 05/24/2012...
- Page 6 GS1400-25 Wiring Diagram Rev. Date: 05/24/2012...
- Page 7 PARTS LIST: GS1400-25 ITEM # PART # DESCRIPTION 10098 BLACK CANOPY 10164 CUP WASHERS 47634 HOOD SCREWS 10040 TUFFSKIN INCANDESCENT LAMP 10027 LIGHT SOCKET ASSY 10032 RACK HOLDER 10066 10-32 X 3/8 BRASS THUMB SCREW 10033 SIDE PANEL 10110 STRAIN RELIEF...
- Page 8 Nemco also warrants its food preparation products (other than blades) to be free of mechanical defects in material and workmanship under normal use for two (2) years from the date placed in service by the original user. In addition, Nemco warrants its Global Solutions food preparation and electrical products (other than blades) to be free of mechanical defects in material and workmanship under normal use for one (1) year from the date placed in service by the original user.
-
Page 9: Electrical Data
GS1400-16 USER MANUAL ELECTRICAL DATA: FEATURES: • Acrylic display VOLTS: AMPS: WATTS: • Adjustable thermostat • Temperatures from 80°F to above 150°F • Best when operated on an individual branch circuit • Stainless steel corners and base • ’ power cord length •... - Page 10 IMPORTANT: Read the following safety and operation instructions to avoid injury and to avoid damage to equipment or property. Plug unit into a properly grounded electrical outlet of the correct voltage, size, and plug configuration for this unit. We recommend usage on an individual branch circuit of at least 15 amps for best results. Failure to do so may result in decreased performance of the warmer.
- Page 11 OPERATION: This warmer is designed to maintain food product at or above the optimum temperature. It is not designed or intended to heat up or cook food to the serving temperature. Product is to be prepared to a temperature of above 160 ° F before placing in the warmer. Do not place product on its side as this will affect the internal holding temperatures of the product.
- Page 12 TROUBLESHOOTING: Unplug unit from power source, and allow to cool completely before performing any maintenance or cleaning. Unit not working: • Check power switch position, power cord, and/or electrical circuit Display light not working • Tighten or replace bulb Loud noise coming from unit: •...
- Page 13 GS1400-16 Exploded View Controls Detailed Vi ew Controls Detailed Vi ew Rev. Date: 05/24/2012...
- Page 14 GS1400-16 Wiring Diagram Rev. Date: 05/24/2012...
- Page 15 PARTS LIST: GS1400-16 ITEM # PART # DESCRIPTION 10098 BLACK CANOPY 10164 CUP WASHERS 47634 HOOD SCREWS 10040 TUFFSKIN INCANDESCENT LAMP 10027 LIGHT SOCKET ASSY 10030 RACK HOLDER 10066 10-32 X 3/8 BRASS THUMB SCREW 10031 SIDE PANEL 10010 STRAIN RELIEF 10005 POWER SWITCH 10024...
- Page 16 Nemco also warrants its food preparation products (other than blades) to be free of mechanical defects in material and workmanship under normal use for two (2) years from the date placed in service by the original user. In addition, Nemco warrants its Global Solutions food preparation and electrical products (other than blades) to be free of mechanical defects in material and workmanship under normal use for one (1) year from the date placed in service by the original user.
