- Page 1 Hydraulic Pump Installation Guide Drives covered: E12171 Constant Running Pump (Variable Flow) 12V E12172 Constant Running Pump (Variable Flow) 24V Document number: 87039-3 Date: 05-2018...
-
Page 3: Safety Notices
Failure to do so could result in poor product performance, personal injury and/or damage to your boat. Because correct performance of the boat’s steering is critical for safety, we STRONGLY RECOMMEND that an Authorized Raymarine Service Representative fits this product. WARNING... -
Page 4: Emc Installation Guidelines
EMC installation guidelines Raymarine equipment and accessories conform to the appropriate Electromagnetic Compatibility (EMC) regulations, to minimize electromagnetic interference between equipment and minimize the effect such interference could have on the performance of your system. -
Page 5: Connections To Other Equipment
D3548-2 Figure 1 Connections to other equipment If your Raymarine equipment is to be connected to other equipment using a cable not supplied by Raymarine, a suppression ferrite MUST always be attached to the cable near to the Raymarine unit. -
Page 6: Imo And Solas
Technical accuracy To the best of our knowledge, the information in this handbook was correct when it went to press. However, Raymarine cannot accept liability for any inaccuracies or omissions it may contain. In addition, our policy of continuous product improvement may change specifications without notice. As a result, Raymarine cannot accept liability for any differences between the product and the handbook. - Page 7 The Raymarine hydraulic pump (also known as the Raymarine constant runninng hydraulic pump) is intended to operate a vessel’s steering mechanism as part of a Raymarine autopilot system. It is primarily designed for use on vessels with an existing hydraulic steering system. Alternatively, you can use this pump on a vessel with mechanical steering in conjunction with a secondary steering ram.
- Page 8 Specifications Pump specifications Table 1-1: Pump specifications Performance E12171 (12 V) E12172 (24 V) (at nominal voltage) Ram compatability Single or double ended Ram capacity 1000-1500cc 1000-1500cc (min-max) (61.0 -91.5 in (61.0 -91.5 in Maximum intermittent 55 bar (800 psi)
-
Page 9: Pump Dimensions
Pump dimensions Figure 3 Installation instructions Parts required To install this drive you will need: • Parts supplied: • hydraulic pump • in BSP bonded rubber / metal seals (x2) • 3/8 in BSP bonded rubber / metal seals (x1) •... -
Page 10: Installation Steps
Installation steps WARNING Electrical safety Make sure you have switched off the power supply before you start installing this product. Follow these steps to install your hydraulic pump: Consult the EMC installation guidelines. page 4 Mount the pump. page 11 ... -
Page 11: Pump Mounting
2. Pump mounting Location requirements • pump is designed for below-deck installations only. • fit pump to a substantial structure to avoid vibration that could damage the pipes. • mount away from sources of heat and excessive vibration and fumes. •... -
Page 12: Hydraulic Connections
3. Hydraulic connections WARNING Pressurized systems Before disconnecting any pipes on pressurized systems, you MUST release the pressure at the reservoir by following the manufacturer’s instructions. CAUTION Pump connection Before you connect the autopilot pump to your hydraulic system we strongly recommend that you consult the steering gear manufacturer. -
Page 13: General Guidelines
General guidelines • The ports on the autopilot pump are in BSPP and 3/8 in BSPP parallel threaded. If you need to convert to in NPT, use the three BSPP to NPT adaptors (supplied). Use only bonded rubber / metal washers to seal the fit- tings. -
Page 14: Hydraulic Fluid
CAUTION Hydraulic fluid • Before running the pump for the first time, make sure the system contains sufficient hydraulic fluid. You will damage the pump if you let it run when ‘dry’. • Do NOT use “brake fluid”. Use only mineral-based good quality hydraulic fluid compatible with nitrile rubber hydraulic seals. - Page 15 Two line systems Figure 6 shows a typical two line steering system. Hydraulic fluid flows into the ram in either direction, depending on the direction the helm pump rotates. Connect the autopilot pump to the steering system as shown in Figure 6. Figure 6...
- Page 16 Two line pressurized systems Two line pressurized systems have an external pressurized reservoir. This reduces the possibility of introducing air into the system and reduces any steering ‘sponginess’ caused by pipe expansion. Connect the autopilot pump to the steering system as shown in Figure 7. Note: Refer to the manufacturer’s instructions for de-pressurizing and re-pressurizing the system.
- Page 17 Figure 8 Three line systems In a three line system, the hydraulic fluid flows in only one direction: • out of the helm pump to the ram • returning from the other side of the ram to the reservoir via a common return line The system will include a check valve block to direct all returned fluid from the ram back to the reservoir.
- Page 18 4. Connecting to the course computer or ACU WARNING Electrical safety Make sure you have switched off the power supply before you start installing this product. Note: To meet current EMC legislation, you must NOT untwist the pump cables. The CR pump has electrical connections for: •...
- Page 19 Make the following connections: Table 1-2: Recommended cable sizes Cable length (pump to Cable gauge Copper area Fuse rating course (AWG) (mm²) computer or ACU) 12V CR pumps 60 A up to 3m (10ft.) up to 7m (23 ft.) up to 16m (52 ft.) 12V CR pumps up to 3m (10ft.) up to 5m (16 ft.)
- Page 20 Mechanical steering systems If you are fitting the pump to a boat with mechanical steering you will need to connect it to a secondary steering ram, along with a solenoid-operated bypass valve. This bypass valve allows you to switch between autopilot course control and manual steering.
-
Page 21: Post-Installation Check
5. Post-installation check WARNING Steering systems Keep clear of moving steering systems at all times. Protect moving parts from access during normal use. Check the following points after installing the pump: Go to Next Page 1. Is the pump installed in such a way that hose lengths are kept to a minimum? 2. -
Page 22: Setting The Pump Speed
In addition to the manufacturer’s instructions for bleeding the steering system, follow these steps to bleed the autopilot pump once you have installed and set up the rest of the autopilot system: 1. With the system in auto mode, press the -10 button ten times: •... -
Page 23: Maintenance
• Raymarine equipment should be serviced only by authorized Raymarine service technicians. They will ensure that service procedures and replacement parts used will not affect performance. There are no user serviceable parts in any Raymarine product. • Some products generate high voltages: never handle the cables/connectors when power is being supplied to the equipment. -
Page 24: Troubleshooting
• Check the security of the mountings. Product support Raymarine products are supported by a worldwide network of distributors and Authorized Service Representatives. If you encounter any difficulties with this product, please contact either your national distributor, or your service representative, or the Raymarine Technical Support Call Center. -
Page 25: Owner Notes
Owner notes... - Page 26 Owner notes...
- Page 28 Raymarine Marine House, Cartwright Drive, Fareham, Hampshire. PO15 5RJ. United Kingdom. Tel: +44 (0)1329 246 700 www.raymarine.com a brand by...
