- Page 1 Signature Faucets [ E N D T H E O R D I N A R Y . ] IMPERIUM TOUCH SENSE Single Handle Pull-Out Sprayer Kitchen Faucet I N S T A L L A T I O N M A N U A L signaturefaucets.com...
-
Page 2: Quick Links
California: 1.8 GPM max (6.8L/min) @ 60psi THANK YOU FOR CHOOSING SIGNATURE FAUCETS We appreciate the trust and confidence you have placed in us. Our products are manufactured to the highest standards of quality and workmanship. However, if you are not satisfied with this product, please do not hesitate to contact us at info@signaturefaucets.com or scan the QR code... -
Page 3: Prior To Installation
To ensure a smooth installation process, kindly read all instructions prior to installation! Failure to do so could result in personal injury, property damage, or product failure. Please note that Signature Faucets will not be held responsible for any labor charges, damages incurred during installation, repair, or replacement, or any indirect, incidental, or consequential damages, losses, injury, or costs of any nature related to this faucet. -
Page 4: Diagram & Parts List
INSTALLATION MANUAL DIAGRAM & PARTS LIST Faucet Shank Upper Washer O-ring Seal Rubber Washer Bottom Washer Rubber Washer Metal Washer Mounting Nut Mounting Screws x2 Cold Flexible Supply Hose Spray Hose Mixer Pipe Hot Flexible Supply Hose Touch Sense Sensor Battery Box Gravity Ball Battery Box Mounting Kit... - Page 5 INSTALLATION MANUAL Remove Mounting Hardware Remove any mounting hardware (B - I) from the faucet shank (A) if installed. Mount Faucet to Deck Mount Faucet to Deck Install the upper washer (B) and O-ring seal (C) on the faucet shank. Thread faucet tubes and shank through the surface mounting hole.
-
Page 6: Quick Connector
INSTALLATION MANUAL Install Touch Sense Sensor Connect the sensor (N) to the mixer pipe (L), and tighten the hexagonal nut firmly. Then, attach the spray hose (K) to the quick connector of the sensor (N). CAUTION To avoid any damage, please ensure that you only rotate the hexagonal nut of the sensor and not the sensor itself. -
Page 7: Connect Water Line
INSTALLATION MANUAL Connect Water Line Connect the hot and cold flexible supply hose (J , M) to their respective water outlets. Flush Out Debris Grab the spray head hose, unscrew the spray head, and remove it along with the rubber washer. -
Page 8: Check For Leaks
INSTALLATION MANUAL Check for Leaks Check connections at arrows for leaks, and retighten if needed. If still leaking, inspect the seals for damage. Pull the spray head from the spout and use the trigger to switch between aerator and spray. Quick Tips for your Touch Sense Kitchen Faucet Simply turn the handle on and tap anywhere on the faucet body to operate.
