PLUG THE MACHINE IN / TESTING THE MACHINE
NOTE: If a machine does not have the green light on, than that means that a fuse has blown on the machine which is a good indication the
ceramic plates need to be changed or the machine needs to be cleaned. If it is close to the 6-12 month period for maintenance, than you need
to order your maintenance kits. Note: The machine will not blow out ozone when the plates are worn out. It will only blow out air.
WARNING:
MAKE SURE MACHINES ARE UNPLUGGED WHEN PUTTING PARTS IN, (FUSES, PLATES, FILTERS, ETC...) ALWAYS RUN
MACHINES IN UNOCCUPIED SPACE ONLY. Prolonged exposure to ozone could be harmful to your health.
Maintenance Kit – Part #CLN2500
efficiency until the next time service is needed. The kit contains the following items: (2) AF4- Air Filters, (4) GPC 46- Ceramic
Generator Plates, (2) FUS200- High Voltages Fuses & (1) Alcohol Wipe Pak.
Mounting Bracket - Part # MB2AB
perfect installation of the PA2500. Please inform us as to what kind of material (marble, drywall, wood, etc...) these brackets will
attach to so th at we can assure proper installation.
Plug the machine in and press the timer manual button to "ON" and make sure that the
machine come on. If so, immediately press the manual button back to "AUTO".
indicate "AUTO" at all times if you are running a program.
If the machine does not have either one of the two
(Note: The green lights are indication lights.
means the machine is not functioning properly. There are 2 lights, and each one is an indicator. One for the left
side and the other is an indicator for the right side of the machine.
contains all the necessary components to keep your Zontec™ PA2500 operating at peak
is an optional heavy steel ceiling or wall mounted bracket kit. This heavy duty kit assures
MODEL PA2500
OPERATING DIRECTIONS
green lights
"Green"
means that the machine is functioning properly, "Unlit"
green lights
on, refer to the troubleshooting section of this manual.
in front of the
Your timer should
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for zontec PA2500
- Page 1 This heavy duty kit assures perfect installation of the PA2500. Please inform us as to what kind of material (marble, drywall, wood, etc…) these brackets will attach to so th at we can assure proper installation.
- Page 2 CHECK THE CORONA DISCHARGE Check for the “corona discharge” in the front of the machine. When the 2 green lights on the front (face) of the PA2500 are lit, this indicates that the electrical output is constant. To verify that you are getting the maximum output of ozone, GREEN periodically examine the front of the machine.
- Page 3 Replace only the fuse that is currently blown out at this time. GREEN LIGHTS LIT BUT OUTPUT DOESN’T SEEM AS STRONG When the 2 green lights on the front (face) of the PA2500 are lit, this indicates that the electrical FUSES ON REAR...
- Page 4 Ozone reverts back to oxygen after it is used. Zontec™ eliminates odors and controls insects by producing continuous, controllable levels of Ozone. The Ozone is created electronically by converting Oxygen (O2) into Ozone (O3). The Ozone will revert to Oxygen within a short period of time while creating the desired effect.
- Page 5 Only Zontec Ozone Generators and/or their designated repair center are authorized to provide Warranty repairs. At the time of a warranty request, a copy of the original invoice indicating the date of purchase, unit model must be presented. All units sent to Zontec Ozone Generators must service a return authorization number, clearly marked on the container, or the unit will not be accepted.
