Summary of Contents for ATD Tools SPI-77945
- Page 1 SPI-77945 User’s Manual UNIVERSAL MULTIMEDIA ADAPTER CARPLAY/ANDROID AUTO/ MIRRORING...
-
Page 2: Table Of Contents
CONTENTS FEATURES........................4 SPECIFICATIONS ......................5 PACKAGE COMPONENTS ....................6 CONNECTION DIAGRAM ....................7 MAIN MENU UI ......................8 HOW TO CONNECT BLUETOOTH ..................9 APPLE CARPLAY ......................10 ANDROID AUTO ......................11 SCREEN MIRRORING ....................12 iOS ......................... 12 Android ........................ - Page 3 WARNING In order to protect the driving safety and avoid break the traffic law; please DO NOT operate the interface while driving. The reversing surveillance function just is used in reversing assistance. Please check the entire surroundings while reversing. All steps of installation should be done by the well-trained specialist. During installation, the ignition key should be taken off and after all installation finished, connect power cable last.
-
Page 4: Features
FEATURES Integrated 3 in 1 module supports wireless CarPlay, wired Android Auto, and USB cable screen mirroring (iOS & Android) Support USB HD video (up to 1080P) and lossless music (APE, WAV, FLAC, MP3, WMA, etc) playback CVBS and HDMI (480P/720P) output Support AHD cameras input Automatic enable CarPlay/Android Auto when connecting an iPhone/Android phone... -
Page 5: Specifications
SPECIFICATIONS Inputs RCA*2 (1 rear camera & 1 external video in, support AHD cameras) 3.5mm AUX*1 (microphone) USB*2 Outputs RCA*3 (CVBS & audio L/R outputs) HDMI*1 Output resolution CVBS: 720*480, NTSC HDMI: 800*480 (default), 1280*720 (optional, upgrade via software) Input voltage 9-16V Consumed power Working temperature... -
Page 6: Package Components
PACKAGE COMPONENTS Main Unit Power Cable Touch/Video Cable Microphone Knob Controller Resistive Touch Sticker for Knob WiFi/BT Antenna Connection Board Controller... -
Page 7: Connection Diagram
CONNECTION DIAGRAM Connect resistive touch panel (sold separately) USB port for USB music & video Ext. video in (support AHD) Backup camera in (support AHD) Reverse detec t KEY 1 & KEY 2 for SWC learning HDMI out UNIVERSAL SWC learning: Steering ADAPTER Wheel Control learning. -
Page 8: Main Menu Ui
MAIN MENU UI Status bar Apple Android Screen Bluetooth CarPlay Auto Mirroring Home Back USB Storage USB Storage External Settings Music Video Video in... -
Page 9: How To Connect Bluetooth
HOW TO CONNECT BLUETOOTH Device name: Car.Audio_xxxx 1. Turn on the mobile phone's Bluetooth, search and pair BT device Car.Audio_xxxx. 2. Tap "Pair" on the pop-up pairing request notification. 3. Tap "Allow" for sync contacts and favourites. Tick Auto Connect: mobile phone connects Bluetooth automatically after starting the adapter... -
Page 10: Apple Carplay
APPLE CARPLAY 1. Turn on the iPhone's WiFi and Bluetooth, search and pair BT device Car.Audio_xxxx. 2. Tap "Pair", "Allow", "Use CarPlay" on the next 3 pop-up notifications. -
Page 11: Android Auto
• Hang up • Accept calling • Next track • Previous track Homepage Back • Rotate: moving cursor • Press once: confirm • Press and hold for 3s to activate Siri ANDROID AUTO 1. Install Android Auto app on your Android smartphone. 2. -
Page 12: Screen Mirroring
3. Select and enter "ANDROID AUTO" icon of adapter. 4. Plug in the smartphone with USB cable (connect to the USB port of power cable). Accept calling Hang up • Move cursor to Apps home button • Back • Rotate: moving cursor •... -
Page 13: Android
2. Plug in the iOS device with USB cable (connect to the USB port of power cable). 3. Open iOS Control Center, tap "Screen Mirroring" icon, then tap Mirroring. Android 1. Enable "USB debugging" on Android phone's developer options. 2. Connect to universal adapter's Bluetooth. 3. -
Page 14: Usb Storage Music & Video
USB STORAGE MUSIC & VIDEO Play mode Previous Pause/Play Next EQ setting Open file Previous track Next track Home: music & video Exit: music & video stop continue to play in the playing background... -
Page 15: Settings
SETTINGS START CARPLAY/ANDROID AUTO AUTOMATICALLY Select " Settings " on main menu and tick " Auto start phone link app ”. Then CarPlay and Android Auto will start automatically after connecting your iPhone or Android smartphone. CAR SETTING AMP function is not available, turn it off by default. -
Page 16: Touch Calibration
TOUCH CALIBRATION After installing a resistive touch panel, press and hold the panel more than 10s, it will enter touch calibration. -
Page 17: Display
DISPLAY SOUND... -
Page 18: Language
LANGUAGE WALLPAPER...
