- Page 1 MANUAL / HANDLEIDING / MODE D’EMPLOI / ANLEITUNG / MANUAL...
- Page 2 1. IMPORTANT INFORMATION SAFARI Read the assembly manual thoroughly before use and keep it in a safe place, so you can onsult it later if necessary. You can also download the manual from our website. SAFETY AND DURABILITY » Tents are intended as temporary shelter.
- Page 3 1. PREPARATION SAFARI 1.1: PREPARING THE ALUMINIUM POLES If you are assembling the stretch tent using wooden poles, you can skip this step. You have poles of 110 cm and 50 cm in length. You can connect these poles using a coupling piece to achieve the desired height.
- Page 4 1.1.1: PREPARING THE STURDY ALUMINIUM POLES (Ø 60 MM): CARABINER + EYEBOLT & PRE-CUT THREADED ROD + 10 m: The pole sets for these tents by default consist of sturdy poles with a diamter of 60 mm. -10 m: The sturdy aluminium poles are also optionally available for these tents. In that case, they replace the standard poles with a diamter of 40 mm.
- Page 5 1.2: PREPARING THE WOODEN POLES If you are assembling the stretch tent using aluminium poles, you can skip this step. Each pole to which corner or side clamps are attached must be pre-drilled. To do this, use a 16 mm drill bit and drill a 7 cm deep hole as centrally as possible.
- Page 6 Corner clamp: Screw the two nuts and the connector nut on the bolt up to the head of the bolt. Then screw the bolt on the corner clamp until it’s firmly secured. Side clamp: The supplied cap nuts go onto the long bolt of the side clamps which are attached to a wooden pole.
- Page 7 1.2.2: RECOMMENDED FOR WOODEN POLES: CARABINER + EYEBOLT & THREADED ROD You can also place the poles outside the canvas and bring the canvas to tension using a carabiner which clicks fast in the side and corner clamp. » Drill a horizontal opening (Ø 10 mm) on the top of the pole. Do this five to ten cm from the top of the pole.
- Page 8 3. STEP-BY-STEP PLAN SAFARI The following step-by-step plan outlines how to assemble the tent in the safari design. Remove the tent from the box supplied along with all of the parts. It’s a good idea to keep the box for easy storage.
- Page 9 STEP 2: ASSEMBLING AND ATTACHING SIDE CLAMPS The edge of the Bonga stretch tent has reinforced zones every metre. Only place the side clamps on these reinforced zones! You can see and feel the reinforced zones when you look at the tent canvas closely.
- Page 10 STEP 3: ATTACHING TENSION STRAPS Attach the supplied tension straps to the corner and side clamps as follows. » Make a loop at the end of the tension strap. » Pull the loop through the hole in the clamp. » Pull both ends of the tension strap through the loop. There is one tension strap on each side clamp.
- Page 11 When the pegs are in the ground, knot the short tension strap with the tension clamp around the peg. Thread the long end of the tension strap which is hanging from the side clamp through the small clamp on the peg. Let the tension strap lie loose on the ground for a moment and don’t increase the tension on it yet.
- Page 12 » Now erect the side poles on the two other opposite sides. The side and corner poles are never fully perpendicular to the ground but are always slanted slightly outwards. STEP 6: ERECTING THE CENTRE POLE WITH POLE CAP Thanks to the large surface area of the pole cap (XL), the pressure on the canvas is better distributed and there are fewer remaining imprints of the pole cap in the canvas after use.
- Page 13 TIP - For tents starting from 10 x 10 m it is not easy to place the centre pole in the desired position right away. It’s best to initially place one pole in a random location so that the canvas is kept floating in order for the poles to be positioned in the correct locations.
- Page 14 tension strap move back forth centimetres perfect tension. TIP - Don’t overtighten the tension straps as this can damage your tent. Never use a ratchet for this. Carry out the following checks once the tent has been standing for half a day or so and carry them out regularly for long-term assemblies.
-
Page 15: Storage And Cleaning
For further support please contact your distributor. Bonga stretch tents offer a repair service and supply repair kits for carrying out minor repairs. In the event of repairs, the box supplied can be used to return the tent to us. - Page 16 Europalaan 83 sales@bongastretchtent.com 9800 Deinze...
