Page 1 Warm Series Ultra-thin Fan Coil User Manual...
Page 2: Table Of Contents
1. Cleaning......................9 2. Maintenance....................10 3. Fault codes and descriptions..............10 Please read this manual carefully before using the unit, otherwise we will not be responsible for any loss, and please keep it properly for your reference. Applicable models：Warm Series BC-FCV-FP500.
Page 3: Product Features
I. Product Features 1. Support warm air in cold winter 2. Matching the decoration,the appearance is fashionable and exquisite 3. High coefficient and energy-saving. II. Instruction for use 1. Safety Warning(It may cause injures for people or damages for units if do not operate as following ) Heat pump fan coil The installation or...
Page 4: Operation Instruction Of Remote Controller
2. Operation instruction of remote controller 2.1.Remote controller diagram 2.2.Names and function of each key of the remote controller "ON/OFF" key  Press ON/OFF key to start/stop the heat pump fan coil. "Mode" key  Press mode key to select different modes in order:Cooling mode,dehumidification mode,air supply mode,heating mode...
Page 5 Press "sleep" key again to cancel the sleep function. Press "sleep" key in the air supply mode is invalid. When you press the "mode" and "Power" keys to exit the sleep function. "Timer" key  When the heat pump is turned on,press "Timer" key to set a time for shutdown;When the heat pump is shutdown,press "Timer"...
Page 6: Installation Instructions And Technical Parameters
III. Installation instructions and technical parameters 1. Technical parameters BC-FCV-FP500 Model Leakage protection Class Ⅰ Rated voltage/frequency 220V/50Hz 350m³/h Rated air volume 2350W Rated cooling capacity 3150W Rated heating capacity Rated input power Rated input current 0.14A 17Kg Net weight Noise ≤37dB(A) Maximum allowable pressure...
Page 7: Installation Guidelines And Piping Specifications
2. Installation guidelines and piping specifications 2.1.Reserved distance of air outlet 2.2.Installation guidelines and notes The unit shall be professionally installed.  In order to eliminate possible accidents caused by handling, the fan coil should be tested for  leakage(1.0mpa) before installation. Before the installation, check whether the preliminary preparation work is ready, such as water ...
Page 8: Unit Wiring Diagram And Wireless Water Pump Connection Instructions
When the power supply is connected, it must be equipped with a full-pole disconnection device  matching with the unit and at least 3mm² contact distance from the power supply and a leakage protection device. If the supply cord is damaged, it must be replaced by the manufacturer, its maintenance department or a similar professional in order to avoid danger.
Page 9 Waterway system diagram  3.2.Wireless water pump connection instructions Wireless communication pairing (a pair of water pump plates should be matched with an inner  plate) When the power is on, the LED3 of the power supply lamp is lit, and the pairing button (SW1) is...
Page 10: Daily Maintenance
pressed continuously for 6 times within 10 seconds. The wireless status LED1 flashes at a frequency of 0.5hz to enter the wireless pairing state. 100ms cycle sends the automatically generated synchronization code and address code of the internal unit (the configured number of internal units plus 1 is the sending address), no reply is received within 30 seconds, the wireless status light is off, and the pairing fails.
Page 11: Maintenance
2. Maintenance The unit shall be maintained by full-time personnel who shall carry out daily monitoring and regular  maintenance of the unit. To designate a strict post responsibility system and operating procedures, strengthen regular maintenance and repair. Coil tube should be cleaned regularly once or twice a month. Remove dirt and scale from the ...
Page 12 High temperature High temperature protection for protection for evaporate inner coil when heating coil Low temperature protection for Feedback fault of indoor inner coil when cooling DC fan Communication failure Failure of air inlet temperature between wire controller and sensor indoor main control board Wind - swing switch self - check fault...
Page 13 116-06-10-00165...
