Summary of Contents for Safe S31IP

  • Page 1 Safe S31IP (mod.C313)
  • Page 2 About This Manual Thank you for choosing Safe S31IP mod.C313 indoor monitor. This manual is intended for end users, who need to use and configure the indoor monitor. It provides an overview of the most essential functions and features of the product, whose firmware version is 113.241.4.4.

  • Page 3: Table Of Contents

    Content 1. Product overview....................................... 1 1.1. Product Description....................................1 1.2. Power connection...................................... 2 2. Daily use..........................................3 2.1. Making a call.......................................3 2.1.1. Calling from digital keypad................................3 2.1.2. Calling from phonebook..................................4 2.1.3. Calling resident....................................4 2.1.4. Calling from call log..................................5 2.1.5.
  • Page 4 2.4.1. Basic Status....................................10 2.4.2. Network Status....................................11 2.4.3. Account Status....................................11 2.5. Live view........................................12 2.5.1. Door Phone....................................12 2.5.2. Web Camera....................................13 2.5.3. Onvif........................................ 13 2.6. Message(s)....................................... 14 2.6.1. Text Message....................................14 2.6.2. Create message.................................... 15 2.6.3. Maintenance....................................15 2.6.4. Capture Log....................................16 2.7.
  • Page 5 3.3. Time settings......................................22 3.4. DND(Do Not Disturb) Settings................................23 3.5. Language........................................24 3.6. Album.........................................24 3.7. Reboot........................................25 3.8. Screen clean......................................25 4. Advance Settings......................................26 4.1. Network Settings......................................26 4.2. SOS Settings......................................27 4.3. Account Settings...................................... 27 4.4. Direct IP........................................29 4.5. Zone settings......................................29 4.6.
  • Page 6 5.2. Account-Basic......................................36 5.2.1. SIP Account....................................36 5.2.2. SIP Sever 1....................................37 5.3. Account-Advanced....................................37 5.3.1. 5.3.1 SIP Account..................................37 5.3.2. Call........................................37 5.3.3. Audio Codecs....................................38 5.3.4. Video Codecs....................................38 5.3.5. Encryption.......................................38 5.3.6. NAT........................................38 5.4. Network-Basic......................................39 5.5. Phone-Time/Lang....................................39 5.5.1. Web Language....................................39 5.5.2.
  • Page 7 5.6.2. DND(Do Not Disturb)..................................43 5.6.3. Open Lobby....................................43 5.6.4. Open Local Door................................... 43 5.7. Phone-Key/Display....................................44 5.7.1. Display......................................44 5.8. Phone-Ringtones..................................... 44 5.8.1. All Ringtones....................................44 5.9. Phone-Intercom......................................45 5.9.1. SOS......................................... 45 5.10. Phone-Monitor......................................46 5.10.1. DoorPhone....................................46 5.10.2. Web Camera....................................47 5.11. Phone-Addressbook....................................48 5.11.1.
  • Page 8 5.12.1. Upgrade-Basic..................................... 50 5.13. Upgrade-Advanced....................................51 5.13.1. PNP Option....................................51 5.13.2. Manual Autop....................................51 5.13.3. Automatic AutoP..................................52 5.13.4. System Log....................................52 5.13.5. PCAP......................................53 5.13.6. Capture Log....................................53 5.13.7. Screenshots....................................54 5.13.8. Others......................................54 5.14. Arming-Zone Setting..................................... 54 5.14.1. Zone Setting....................................54 5.15.

  • Page 9: Product Overview

    IPC. Its finely-tuned Linux OS allows for better suit the habit of usage of local people. Powered by it, S31IP multiple ports, such as I/O and Bell ports, can be used to easily integrate external Arming systems, such as bell...

  • Page 10: Power Connection

    1.2. Power connection The S31IP is powered by simply connecting the two wires of the power adapter to the wiring interface on the back of the indoor monitor. S31IP also support POE(Power Over Ethernet). 11 PIN connector For power supply , RS485, Bell and Relay connector.

  • Page 11: Daily Use

    2. Daily use 2.1. Making a call There are two ways to make a call from the indoor monitor to other units, which can be another indoor monitor or an intercom app. 2.1.1. Calling from digital keypad ①Tap the icon to enter the call interface. ②Enter the number to call on the digital keypad, ③Choose a account for this outgoing call.

  • Page 12: Calling From Phonebook

    ⑥Or tap this icon to enter the phonebook. ⑦After choosing group,to search the list by number or alphabet. S31IP supports fuzzy matching query. ⑧Scroll up or down the pre-imported contact list. ⑨Tap the dial key next to the contact found.

  • Page 13: Calling From Call Log

    2.1.4. Calling from call log ④Press the icon to enter the call log interface. ⑤You can also choose the icon in intercom interface to check call log.⑥Choose a log. ⑦Choose audio or video call to dial out. ⑧Press the icon to delete the selected call log. ⑨Press the icon to delete all of the call log.

  • Page 14: Calling Doorphone

    2.1.5. Calling doorphone ①Press to make a call out, if you want to call doorphone unit. 2.2. Receiving a call 2.2.1. Receive a incoming call ①There will be a video preview in this window, when you receive a incoming call. ②Press this icon to pick up the incoming call as an audio call.

  • Page 15: Contact

    ②Press the icon to delete the groups you want to delete. ③Press the icon to modify the corresponding group. Notes: For cloud contact, it needs S31IP to work with Akuvox cloud server. Then cloud server will assign contacts automatically. For more information, please...

  • Page 16: Add A Group

    2.3.1.1. Add a group Enter the phone book interface, you can ①Press the icon to add a group. ②Type in the group name. ③Choose a ring tone for this group. ④Press this icon to save the group. ⑤Press the icon to cancel the operations. 2.3.1.2.

  • Page 17: Add A Contact

    2.3.1.3. Add a contact ①Select a group, to check the contacts in this group. ②Press the icon to add a contact. ③Type in the contact name. ④Type in the number 1, it must be a room number. ⑤Type in the number 2, it can be a SIP number or IP number. ⑥Select a specific ring tone for this contact.

  • Page 18: Status

    2.4. Status 2.4.1. Basic Status To check S31IP status by ①pressing this icon. After entering the status interface, it shows the basic status as default. You can check the Model, Hardware version, Firmware version, Mac Address and IP Address information and so on.

  • Page 19: Network Status

    2.4.2. Network Status ② Press the icon to check the network status.You can check the LAN type, LAN IP, subnet mask, gateway and DNS here. 2.4.3. Account Status ③ Press the icon to check the account status.You can check the account number and status here, registered means it works normally.

  • Page 20: Live View

    2.5. Live view ①Press the icon to receive the video from indoor IPC or community IPC any time. 2.5.1. Door Phone ②By entering the monitor interface, it is door phone list by default.You can receive video from predefined doorphone station which you set under the path"Setting-Advance- Door Station".

  • Page 21: Web Camera

    ⑦Press this icon, you can delete anyone ipc which you want to delete. 2.5.3. Onvif ①Press the icon to enter the Onvif list. S31IP will detect available web camera via ONVIF protocol automatically. ②Choose a URL to get the corresponding video. You need to enter the username and password for access.

  • Page 22: Message(S)

    2.6. Message(s) ① Press the icon to enter the message interface. There will be a notification here if there is any unread message.Or ② press this icon to enter the message interface. 2.6.1. Text Message By entering the message interface, it is text message list. You can check the message you received or what you sent here.

  • Page 23: Create Message

    2.6.2. Create message ①Press this icon to create a new message. ②This option is to set the destination. If you want to call community 1, building 1, unit 1, floor1, room 1, you need to enter 1.1.1.1.1. ③This option is to type in your message context. ④Press the icon to send the message to the predefined destination.

  • Page 24: Capture Log

    2.6.4. Capture Log ③Press this icon to enter capture log list. ④Press this icon to delete capture logs. ⑤Choose a log to check the capture. ⑥Press left/right key to check the previous/next capture. ⑦Press this icon to back to capture log list.

  • Page 25: Arming

    2.7. Arming ①Press the icon to enter the Arming interface. ②S31IP supports 4 mode, they are indoor mode, sleeping mode, outdoor mode and disarm mode. 2.7.1. Arming Mode ③Press this icon to enter the arming mode settings interface. ④You can see all of the 8 zones and corresponding sensor types (slide down to check more information) in this interface.

  • Page 26: Disarm Code

    under the selected mode. ⑧Press save icon to save the modification. 2.7.2. Disarm Code ①Press this icon to enter the disarm code settings interface. You can modify the disarm code here. ②Enter the old disarm code first, it is 0000 as default. ③Enter the new disarm code ④Enter the new disarm code again for confirming.

  • Page 27: Alarm Log

    2.7.3. Alarm Log ①Press this icon to enter the alarm log interface.You can see the alarm log here including location, zone, zone type and alarm time. ②Press this icon to delete the selected alarm log. ③Press this icon to delete all alarm log. 2.7.4.

  • Page 28: Settings

    3. Settings ①Press the icon to enter the basic settings interface. 3.1. Display settings ②Press this icon to enter display settings interface. ③ To adjust the brightness here, it is 5 level as default. There are 10 levels totally, the bigger value means the lighter screen. ④To select whether to enable the screen saver.

  • Page 29: Sound Settings

    3.2. Sound settings ①Press this icon to enter the sound settings interface. ②You can set Ring Tones for incoming call, even to set a special Ring Tone for door unit, or set the Ring Volume, Talk Volume and MIC Volume. You can also choose whether to enable the Touch Sounds here.

  • Page 30: Time Settings

    3.3. Time settings ①By pressing this icon to enter the time settings interface. ②NTP(Network Time Protocol) is enabled as default. S31IP will get the Date and Time automatically. And users can also setup NTP server. Setup a suitable Time Zone, Time format and Date Format.

  • Page 31: Dnd(Do Not Disturb) Settings

    3.4. DND(Do Not Disturb) Settings This function is used to prevent the phone from disturbing. Go to Setting-DND. if open DND, external phone call is unable to call in, turned off by default. ①By pressing this icon to enter the DND settings interface. ②Enable/Disable DND function.

  • Page 32: Language

    3.5. Language ①Press this icon to enter language setting interface. ② To select a suitable language. It only supports English on this firmware. ③Press this icon to go back to settings interface. 3.6. Album ④Press this icon to enter album interface. ⑤Press these 2 icon to check previous/next picture.

  • Page 33: Reboot

    3.7. Reboot ① Press the icon to reboot S31IP, click Confirm when you see the prompt. The phone will reboot. 3.8. Screen clean ②Press the icon to clean the S31IP 's screen, it will keep you from misusing for 30 seconds.

  • Page 34: Advance Settings

    Enter the advance settings interface, click Network icon to enter the network setting page. S31IP use DHCP mode to get IP address by default. ①To select Static IP or DHCP network of S31IP If selected Static IP Network. Enter the IP address parameters in the corresponding area: IP Address/Subnet Mask/Gateway/DNS1/DNS2.

  • Page 35: Sos Settings

    4.2. SOS Settings Enter the advance settings interface, click SOS icon to enter the SOS setting page. S31IP can call out for up to three predefined numbers in a loop, each number will be called for 60 seconds (by default) when end user presses SOS icon.
  • Page 36 Name/Register Name/User name/Password/Sip Server/Sip Port. Slide down to check more account information. ⑤Enable/disable the auto answer of this account. If enabled, when this account receives the incoming call, S31IP will answer the call automatically. ⑥ Enable/disable the no answer forward feature of this account. If enabled, the incoming calls of this account will be forwarded to the specified sip account when the ringtone is time out without answering.

  • Page 37: Direct Ip

    IP call setting page. ① Enable/disable the auto answer feature of the Direct IP calls. If enabled, when there is a direct IP incoming call, S31IP will answer the call automatically. ②Enable/disable the no answer forward feature. If enabled, the direct ip incoming calls will be forwarded to the specified ip address when the ringtone is time out without answering.
  • Page 38 ①To choose a zone to set corresponding parameters. S31IP support up to 8 zones, you can connect up to 8 alarm sensors to S31IP ②Setup location of the alarm sensor, including Gate, Door, Bedroom, Guest room, Hall, Window, Balcony, Kitchen, Study and Bathroom.

  • Page 39: Password Setting

    screen, until the alarm sensor device can not detect the triggered source. ⑥Save icon to save the modification. 4.6. Password setting Enter the advance settings interface, click Password Setting icon to enter the password setting of Setting-Advanced page. ① Click the Old Password to input the password of entering advance settings interface.It is 123456 as default.
  • Page 40 ②Click the Device Name to set the Akuvox door phone name. ③ Click the URL to set the video url of Akuvox door phone, input the door phone ip address here. ④Click the Sip Account to set the sip extension of the Akuvox door phone.

  • Page 41: Reset

    4.8. Reset Enter the advance settings interface, click Reset icon to reset S31IP to factory. And press confirm when you see the prompt. It will reset to factory automatically.

  • Page 42: Website

    Web user interface (we will used Web UI for short in the following context) which is used for user or administrator to check or change S31IP settings. Click Status icon on desktop to check the Phone’s IP address. Type the IP address on browser, input default User Name and...

  • Page 43: Status-Basic

    5.1. Status-Basic 5.1.1. Product Information To display the device’s information such as Model name, MAC address (IP device’s physical address), Firmware version and Hardware firmware. 5.1.2. Network Information To display the device’s Networking status(LAN Port),such as Port Type(which could be DHCP/Static/PPPoE), Link Status, IP Address, Subnet Mask, Gateway, Primary DNS server, Secondary DNS server, Primary NTP server and Secondary NTP server(NTP server is used to synchronize time from INTERNET automatically).

  • Page 44: Account Information

    5.1.3. Account Information To display device’s Account information and Registration status (account username, registered server’s address, Register result). 5.2. Account-Basic 5.2.1. SIP Account To display and configure the specific Account settings. Status: to display the register result. Display Label: Which is displayed on the phone’s LCD screen. Display Name: Which is sent to the other call party for displaying.

  • Page 45: Sip Sever 1

    Server IP: SIP server address, it could be an URL or IP address. 5.3. Account-Advanced 5.3.1. 5.3.1 SIP Account Account: S31IP support dual SIP account, you can choose which one to be configured here. 5.3.2. Call Auto Answer: Enable this feature, S31IP will pick up the incoming...

  • Page 46: Audio Codecs

    Familiar codecs PCMU(G711U), PCMA(G711A), G722(wide-bandth codecs), G729 and so on. 5.3.4. Video Codecs S31IP support H264 video codec. 5.3.5. Encryption Voice Encryption(SRTP): If enabled, all audio signal (technically speaking it’s RTP streams) will be encrypted for more security. 5.3.6. NAT...

  • Page 47: Network-Basic

    SIP message for designated account. 5.4. Network-Basic To display and configure LAN Port settings. DHCP: If selected, IP phone will get IP address, Subnet Mask, Default Gateway and DNS server address from DHCP server automatically. Static IP: If selected, you have to set IP address, Subnet Mask, Default Gateway and DNS server manually.

  • Page 48: Lcd Language

    5.5.2. LCD Language To choose the device language.(Only English supported now) 5.5.3. Format Setting Time Format: Determine what format to display on Phone UI(12 hour/24 hour). Date Format: Determine what format to display on Phone UI for Date. 5.5.4. Type To select how to configure time, it could be set by manually or get from Internet automatically via NTP server.

  • Page 49: Ntp

    Primary Server: To configure primary NTP server address. Secondary Sever:This is for redundancy, if getting time from Primary NTP server fails, the S31IP will go to Secondary NTP server for getting time. Update Interval:Set the period of synchronization with the server.

  • Page 50: Phone-Call Feature

    To display and configure Forward setting. Always Forward: Any incoming call will be forwarded in any situation. Busy Forward: Any incoming call will be forwarded if S31IP phone is busy. No answer Forward: Any incoming call will be forwarded if it ’ s no...

  • Page 51: Dnd(Do Not Disturb)

    5.6.3. Open Lobby DTMF: To set the DTMF code which be sent when you press the open door icon during call on S31IP screen. 5.6.4. Open Local Door DTMF: To set the DTMF code which can trigger the local relay.

  • Page 52: Phone-Key/Display

    5.7. Phone-Key/Display 5.7.1. Display Backlight Intensity: Adjust the screen backlight Intensity. From 1-10. Backlight Time: Adjust Backlight time. After the configured time, the phone will enter standby mode. Click again to wake up. 5.8. Phone-Ringtones 5.8.1. All Ringtones Upload: Upload the customized ringtone you need, click submit to save.

  • Page 53: Phone-Intercom

    5.9. Phone-Intercom 5.9.1. SOS SOS function is used to call out the emergency numbers in loop time when someone needs help. Call Number: setup 3 SOS numbers. Once users press SOS key, the phone will call out the number in order. Call Timeout: Setup the timeout for each number.

  • Page 54: Phone-Monitor

    Account: Number of Safe IP doorphone. Device Name: To set a name for Safe IP doorphone. Destination URL: To set the ip address of Safe IP doorphone. User Name: For monitor authentication. Password: For monitor authentication. To monitor doorphone camera,...

  • Page 55: Web Camera

    5.10.2. Web Camera Device Name: To set the device name for web camera. Destination URL: To set the URL of web camera. Please connect with IPC vendor for URL format. After setup, click Add to add the camera information. Then you can check or edit the web camera from the list.

  • Page 56: Phone-Addressbook

    5.11. Phone-Addressbook 5.11.1. Contact Select a group to manage corresponding contacts. 5.11.2. Search To search a special contact. 5.11.3. Contact Setting To add a new contact. Name: To set a name for the new contact. Number1: To set the number for the new contact, this number must be room number, when connected to SDMC, you will assign a room number.

  • Page 57: Group

    Group: You can set a group for the new contact. Ring: To select a special ring tone for the new contact. Account: To select which account to dial out to the new contact. 5.11.4. Group To manage the group. 5.11.5. Group Setting To add a new group or modify existing group.

  • Page 58: Upgrade-Basic

    5.12. Upgrade-Basic 5.12.1. Upgrade-Basic Firmware Version: To display the current firmware version. Hardware Version: To display the current hardware version. Upgrade: To select upgrading rom file from your PC manually, then click the submit to begin update. Notes:Please make sure it is right file format for right model. Reset To Factory setting: To enable you to reset IP phone’s setting to factory settings.

  • Page 59: Upgrade-Advanced

    5.13. Upgrade-Advanced 5.13.1. PNP Option To display and configure PNP setting for Auto Provisioning. PNP: Plug and Play, once PNP is enabled, the phone will send SIP subscription message to PNP server automatically to get Auto Provisioning server’s address. By default, this SIP message is sent to multicast address 224.0.1.75(PNP server address by standard).

  • Page 60: Automatic Autop

    left blank. Common AES Key: Used for IP phone to decipher common Auto Provisioning configuration file. AES Key (MAC): Used for IP phone to decipher MAC-oriented auto Notes: AES is one of many encryption, it should be configured only when configure file is provisioning configuration file(for example, file name could be ciphered with AES, otherwise left blank.

  • Page 61: Pcap

    1M(mega bytes), and will top capturing once reaching this 5.13.6. Capture Log maximum size. To export the capture log from S31IP URL: input the address to export the capture log. User Name/Password: the authentication of the server...

  • Page 62: Screenshots

    Users can connect S31IP to some sensors like infrared sensor, gas sensor, smoke sensor and so on. S31IP support up to 8 alarm zone, you can manage these zone here. And then you can design 3 different modes for the arming zone under the path “Arming-Arming mode”.

  • Page 63: Arming-Arming Mode

    24H status means it cannot be disabled. Enable status means it depends on arming mode. 5.15. Arming-Arming Mode 5.15.1. Arming Mode To choose arming mode for S31IP different arming modes meet different requirements. It can be Indoor mode, Outdoor...

  • Page 64: Home/Sleeping/Away

    mode, Sleeping Mode and Disarm Mode.We will take Indoor for an example. 5.15.2. Home/Sleeping/Away Location: To display location information of 8 zone. Zone Type: T display the sensor type of 8 zone. Defence Delay: To set defence delay time, it means when you change to the arming mode from other modes, there will be 30 seconds delay time by default.

  • Page 65: Arming-Disarm Code

    5.16. Arming-Disarm Code 5.16.1. Disarm Code To modify the disarm code. Current Password: To type in the current disarm code for authentication. New Password: To set a new disarm code. Confirm Password: To type in new disarm code again for confirmation. 5.17.

  • Page 66: Session Time Out

    Current Password: To type in the current password for authentication. New Password: To set a new password. Confirm Password: To type in new password again for confirmation. 5.17.2. Session Time Out Session Time Out Value: To modify the session time out value, it is 300 by default.
