RXC52-SP&TP / RXC52-SG&TP Instruction Manual
Thank you for choosing MXO-RACING brand products, please read this document carefully
before use!
The RXC52-SP&TP is a miniature antennaless version surface receiver integrated with
Transponder.
The RXC52-SG&TP is a miniature antennaless version surface receiver that integrates both
Transponder and Mul_Gyro.
The RXC52-SP&TP / RXC52-SG&TP is a Futaba SFHSS compatible miniature high-speed surface
receiver for 1:24/1:28 or MINIZ. Its output speed is as high as 3.4ms, which is much higher than other
receivers of the same protocol. In order to ensure its working distance and response speed, we added
a high-gain LNA to the hardware, and optimized the automatic control logic of the LNA in software
to ensure that the receiver can work effectively at both close and long distances.
With its compact size and reliable performance, the RXC52-SP&TP / RXC52-SG&TP is the
perfect choice for hobbyists and enthusiasts looking for a high-quality surface receiver for their
mini-rc car projects using Futaba transmitter.
Features：
*
 Size:19.6 12.0*7.0 mm;
Weight: 1.35g；

Working voltage: 3.3~8.5V；

Compatible with Futaba SFHSS protocol;

Built-in LNA;

with built-in editable personal
Transponder

Personal ID range: 1~16777215;

Parallel high-speed output;

Adaptive output speed ( 5.5ms at DX4S, 8.25ms at DX5C);

Built-in Mul_Gyro (Note 1);

Support online firmware upgrade.

Note 1: This feature is only
Interface
(Figure 1):
supported
in the RXC52-SG&TP version;
ID number;
