No-Light receiver
LED receiver
NOOSA SMART CONTROL KIT
No-Light Models:
205481 – 40" & 46" No-Light models
205482 – 52" No-Light models
205483 – 60" No-Light models
LED Models:
205484 – 40" & 46" LED models
205485 – 52" LED models
205486 – 60" LED models
NOOSA Smart Control Kit
Advertisement
Table of Contents
Related Manuals for Eglo NOOSA 205481
Summary of Contents for Eglo NOOSA 205481
- Page 1 No-Light receiver LED receiver NOOSA SMART CONTROL KIT No-Light Models: 205481 – 40” & 46” No-Light models 205482 – 52” No-Light models 205483 – 60” No-Light models LED Models: Installation Manual 205484 – 40” & 46” LED models 205485 – 52” LED models Use &...
- Page 2 EGLO Lighting has a policy of continual product improvement and development, dimensions, hardware and designs may change to reflect this policy. EGLO reserves the right to discontinue or change product specifications & designs at any time without notice and without incurring obligations.
-
Page 3: Table Of Contents
WARRANTY Smart control kit. Thank you for purchasing your new EGLO Smart Control Kit. To ensure a safe and successful installation, please make sure to read this manual, ensure it is on hand for your installer to refer to, and keep in a safe place for future reference. -
Page 4: For Your Safety
8. All EGLO products are warranted to be free from defects in workmanship and materials provided the products are used with a voltage supply within the range the product is designed to operate. 9. EGLO ligh�ng will not be liable for any advice given to the consumer from any 3rd par�es including suppliers, retailers & electricians. -
Page 5: Installation
INSTALLATION: Fig. 1 1. Lower the canopy ring; gently pry the ring away from the canopy and let rest on motor housing. Refer Fig. 1. Loosen the 2 screws on the underside of the canopy. Refer Fig. 1, Twist the canopy an�-clockwise, and lower than canopy. Fig. -
Page 6: Wiring Connections
WIRING CONNECTIONS: WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST ONLY BE UNDERTAKEN BY A QUALIFIED AND LICENSED ELECTRICIAN. WARNING: For safe use of the fan, an all-pole disconnec�on MUST be incorporated into the fixed wiring in accordance with the wiring rules. As outlined in clause 7.12.2 of AS/NZS 60335-1 for mee�ng the minimum electrical safety of this standard. -
Page 7: Setting Up The Smart Control Kit
SETTING UP THE SMART CONTROL KIT: NETWORK AND ROUTER SETTING: Ensure you have a WiFi network, name and password that operates at 2.4Ghz to be compa�ble with my control products. Your IOS/Android device will need to be connected to this network when pairing or controlling your My Control device. -
Page 8: Operating Light Functions
OPERATING YOUR APP CONTROL KIT: Opera�ng Light Func�ons: Refer Fig. 13. Fig 13 Lamp Switch: Turns light On / Off Brightness: Set brightness from 10% to 100% Temperature: Switch between Warm White (3000k) Neutral White (4000k) Cool White (5000k) Countdown Off: (Light Timer) Set desired period un�l light turns off... -
Page 9: Warranty Claims On Installed Products
Subject to “Your Consumer Rights“ outlined above, but otherwise to the maximum extent permitted by law, EGLO will not be liable for any consequential or indirect loss or damage suffered or incurred by you in relation to an EGLO product, including but not limited to loss of use, loss or damage for business interruption, or profits. -
Page 10: Commercial Use
HOW TO MAKE A WARRANTY CLAIM: Please return the faulty EGLO product together with a copy of the proof of purchase, and if required, a certificate of compliance for the installation of the product by the licensed electrician who installed the product, to the authorised EGLO retailer where the product was purchased. -
Page 11: Warranty Claim Form
WARRANTY CLAIM FORM Warranty Claim No.: (EGLO Office Use Only) To help us assist you with your claim, please complete the enclosed warranty form in full. CUSTOMER DETAILS Name: Day�me Phone/Mobile: Email: ADDRESS WHERE PRODUCT IS INSTALLED Address: Suburb/Town: State:... - Page 12 EGLO LIGHTING AUSTRALIA 5/339 Archerfield Road Richlands Queensland 4077 www.eglo.com.au NOOSA Smart Control Kit...
