Summary of Contents for MotoCrane RE.VOLT AC-3
- Page 1 Revolt, AC-3,DC-3 Operation Manual v1.0 JULY 2023...
-
Page 3: Safety Signal Words
To minimize risk of serious injury, death or damage, before using MotoCrane Revolt, AC-3, and DC-3, all operators must read this Operation Manual and all on-product labels. All practices and procedures stated herein are required for the proper and safe operation of Revolt, AC-3, and DC-3. -
Page 4: Table Of Contents
Contents Safety Signal Words Contents Before first use IMPORTANT PRODUCT AND SAFETY INSTRUCTIONS Safety IMPORTANT: Restricted Use Statement Disclaimer and Limitations of Liability Limited Warranty Intellectual Property System Overview Revolt AC-3 DC-3 Revolt Application Chart Examples of applications LIGHT MEDIUM HEAVY Setting up Revolt, AC-3, and DC-3 Revolt Setup &... -
Page 5: Before First Use
Do the following before using Revolt, AC-3, and DC-3 for the first time. 1. Read this Operation Manual completely 2. Read the Warranty in the Terms of Sale 3. Watch the Video Tutorials at https://motocrane.com/knowledge-base 4. Email MotoCrane with any questions about Intended Use... -
Page 6: Important Product And Safety Instructions
IMPORTANT PRODUCT AND SAFETY INSTRUCTIONS Safety MotoCrane Revolt, AC-3, and DC-3 are not toys and can cause serious injury, death or damage if not used properly. You must exercise caution during use of the Revolt, AC-3, and DC-3 to ensure a safe filming environment for everyone. -
Page 7: Limited Warranty
Terms and Conditions of Sale for your Revolt, AC-3, and DC-3 for a complete description of this limited warranty. This Limited Warranty is incorporated by reference into this Operation Manual. Intellectual Property MotoCrane™ and are trademarks of MotoCrane, LLC. You may not use the trademarks of MotoCrane, LLC without express written permission. All rights reserved. -
Page 8: System Overview
System Overview Revolt... - Page 9 AC-3 DC-3...
-
Page 10: Revolt Application Chart
Revolt Application Chart While Revolt makes the Ronin 2 compatible with a wide variety of power sources and cabling options, it’s important to make sure your desired power pathway is rated for your application! “Application” in this case means the LOAD, which is everything being powered by the Ronin 2 multiplied by the DUTY, which is how dynamic the load will be handled based on what’... -
Page 11: Examples Of Applications
A typical V-Mount/Gold Mount battery can discharge ~9 amps continuously. So, 12 volts x 9 amps = 108 Watts making it a suitable power source for “LIGHT” applications (requires MotoCrane DC-3). Due to the low power of this application, standard (low) capacity XLR Cables will likely not cause problems for this application. -
Page 12: Setting Up Revolt, Ac-3, And
“Revolt and TB50” below) Regulated power sources (such as a Block Battery, or MotoCrane AC-3/DC-3) provide a constant, fixed output voltage, so the Status LED will not change as its remaining battery life decreases. In this scenario, battery voltage must be monitored at the source, not by Revolt. -
Page 13: Ac-3 Setup & Use
Medium to Heavy applications , (or Light applications operating at long distances) should always use High Capacity 3-Pin XLR cables from MotoCrane. Inadequate cabling can result in excessive voltage drop, heat, and power failure. DC-3 Setup & Use 1. With the Output power switch turned “OFF”, connect a 12V or 48V power source to the correct input on the DC-3. - Page 14 Blinking Red Over voltage! (>29.0V) See troubleshooting Blue-Blue-Green Auto-ON Enabled Blue-Blue-Red Auto-ON Disabled If you are experiencing issues with your Revolt, or have questions about how to determine the Status of your Revolt please contact MotoCrane Technical Support at support@motocrane.com.
-
Page 15: Known Hazards
Known Hazards The following list represents a list of known hazards that exist when operating Revolt, AC-3, and DC-3. This is not exhaustive, but represents some common hazards to look for. ● AC-3 and DC-3 mounting. The AC-3 and DC-3 should not be subject to movement relative to the vehicle during operation. -
Page 16: Troubleshooting
Revolt status LED indicates Low quality (low capacity) We recommend using a low input voltage while 3-Pin XLR cable is being used MotoCrane High Capacity connected to a full battery, or to connect power to Revolt. 3-Pin XLR Power cable. -
Page 17: Maintenance
Maintenance None required - contact Customer Support if you believe the unit requires service or maintenance. Weather & Water Revolt carries the same IP52 ingress protection rating as the Ronin 2, and is NOT “water resistant.” Special attention must be paid to protect the Revolt from water. AC-3, and DC-3 are NOT water resistant or IP-rated! The AC-3 and DC-3 should be kept out of direct sunlight to avoid unnecessary heat buildup within the unit. -
Page 18: Revision History
This content is subject to change. Download the latest version of this Operation Manual from: www.motocrane.com/knowledge-base If you have any questions about this document, please contact MotoCrane, LLC by sending a message to contact@motocrane.com. ©2023 MotoCrane, LLC. All rights reserved.
