JM Concept TELIS 9000 Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Operating manual
TELIS 9000
Version of  03/30/2023























Advertisement

Table of Contents
loading

Related Manuals for JM Concept TELIS 9000

Summary of Contents for JM Concept TELIS 9000

  • Page 1             Operating manual TELIS 9000                                   Version of  03/30/2023...

  • Page 2: Table Of Contents

    Operating manual TELIS 9000 2/ 86   Summary   Technical characteristics ..................................3 Safety precautions ....................................12 Dimensions and wiring ...................................14 Installation ......................................17 Programming and key functions................................21 Programming by PC ....................................23 Error messages......................................24 Main menu.......................................25 Measurements menu 1 input..................................27 Measurements menu 2 inputs ................................29 Measurements menu 2 inputs + calculation............................31...

  • Page 3: Technical Characteristics

    Operating manual TELIS 9000 3/ 86 Technical characteristics Universal input        ...
  • Page 4 Operating manual TELIS 9000 4/ 86 Presentation TELIS 9000 is a universal input transmitter with quadruple galvanic isolation, 24-bit conversion for inputs and 16-bit conversion for outputs, and accurate cold junction compensation at ± 1°C for thermocouple inputs.  TELIS 9000 is guaranteed for 5 years  ...
  • Page 5 Operating manual TELIS 9000 5/ 86       Factory settings Input Output 1 & 2 Relays (1 RT or 1T) 4-20mA 4-20mA Alarm: High Display: 0-100   Threshold: 50 Communication speed: 9600 bauds, Slave address: n°1 Other settings on demand...
  • Page 6 Operating manual TELIS 9000 6/ 86 Inputs - Outputs Input gauges Standard scales: 0-1mA ; 0-10mA ; 0-20mA ; 4-20mA ; ±1mA ; ±10mA ; ±20mA Current (continuous) Adjustable scales: from -22 to 22mA Standard scales: 0-100mV ; 0-1V ; 0-5V ; 1-5V ; 0-10V ; 2-10V ; ±100mV ; ±1V ; ±5V ; ±10V Standard scales: 0-50V ;...
  • Page 7 Operating manual TELIS 9000 7/ 86 Characteristics Display   Type Backlit LCD Color Blue Number of characters Numbers of lines Programming joystick 5 positions Input characteristics   Current input impedance 5.6Ω U<10V: >10MΩ Voltage input impedance U±10V ou >10V: 6MΩ...
  • Page 8 Operating manual TELIS 9000 8/ 86 General characteristics   Precision class Input analog / digital conversion 24 bits Output analog / digital conversion 16 bits Process input, Thermocouple, 2 wires resistor: <80ms Response time RTD potentiometer: <160ms Thermal drift <25ppm Residual ripple on current output <20μA...
  • Page 9 Operating manual TELIS 9000 9/ 86 Functions Display functions   LCD display Graphic display by LCD screen LED indicators 1 green LED on devices without display 5 positions joystick Allows you to configure the parameters displayed on the front panel screen...
  • Page 10 Operating manual TELIS 9000 10/ 86 Smart functions   Translates the sensor signal loss on: Sensor signal loss • the display, • each of the analog outputs,   • the digital output, • the status of the relays Filtering Integration of the measurement over the defined time (in seconds)
  • Page 11 Operating manual TELIS 9000 11/ 86 Links and communication   RS485 MODBUS RTU bidirectional digital link allowing to: RS485 MODBUS RTU • recover the measurements and transmit them in digital format • configure and control the device Access to the digital bus via the USB socket (when transmitters are used on the...

  • Page 12: Safety Precautions

    Operating manual TELIS 9000 12/ 86 Safety precautions Introduction   To ensure the conditions of quality, precision and safety, the user must carefully read and comply with the rules of assembly and operation indicated in this manual.   Safety Qualification of staff This manual must be read by qualified and authorized personnel in charge of installation, operation, maintenance and cleaning.
  • Page 13    • Never open the case • Repairs are only to be carried on JM Concept's premises.     Operating environment The product must be installed and used indoors, in an electrical box. It must not be exposed to temperatures outside the limits prescribed for ambient temperatures (-10°C ... +60°C).

  • Page 14: Dimensions And Wiring

    Operating manual TELIS 9000 14/ 86 Dimensions and wiring Dimensions Dimensions: Width : 22.5 or 45 mm - Height: 81 mm - Depth: 98 mm  BASELINE boards are to be ordered separately 22.5 mm Case: Reference BL01ALV  ; 45 mm Case: Reference BL02ALV...
  • Page 15 Operating manual TELIS 9000 15/ 86 Wiring TELIS 9000U0 TELIS 9000U1     TELIS 9100U0 TELIS 9000U2     TELIS9200U0 TELIS 9150U1     TELIS9200U2 TELIS 9200U1...
  • Page 16 Operating manual TELIS 9000 16/ 86 TELIS 9250U0 TELIS 9300U0     TELIS 9300U1 TELIS 9400U0     TELIS 9400U1 TELIS 9400U2...

  • Page 17: Installation

    Operating manual TELIS 9000 17/ 86 Installation   Prerequisite Necessary equipment: • DIN rail • Screwdriver • Copper wire of section 2.5 mm² max • Cutting pliers • Circuit breaker or equivalent   Mounting of the Baseline on the DIN rail The baseline shall be mounted vertically on a DIN rail, placed horizontally.
  • Page 18 Operating manual TELIS 9000 18/ 86 Setting up the transmitter on the baseline The connection of the 22.5mm device is done by means of screw terminals distributed in 2 rows of 3 terminals marked from 1 to 6, at the top; and 2 rows of 3 terminals marked from 7 to 12, at the bottom.
  • Page 19 Operating manual TELIS 9000 19/ 86 When the connection of the power supply, outputs and inputs is made, the transmitter module can be installed on its baseline. Check that the transmitter module is in the right direction and matches the "UP" indication on the baseline.
  • Page 20 Operating manual TELIS 9000 20/ 86 Power Supply   The product has its own power supply. The power supply conditions of the product (voltage, frequency, consumption) are available in the following sections "Technical characteristics" → "Characteristics" → "Auxiliary source" → "Power Supply voltage", and "Technical characteristics" →...

  • Page 21: Programming And Key Functions

    Operating manual TELIS 9000 21/ 86 Programming and key functions Introduction   The principle of programming is that of drop-down menus in which it is enough to scroll through the available functions until the display of the one sought, and to validate this choice to proceed to the next step.
  • Page 22 Operating manual TELIS 9000 22/ 86 Use of the function keys in measurement mode Graphical Element representation in Function the manual Pressing the button allows: • to switch to programming mode Joystick button • to reset the min / max and access the tare function •...

  • Page 23: Programming By Pc

    Connecting cable You need a USB cable between the USB socket on the front of the JM Concept transmitter module and the USB of the PC. JM Concept transmitters can be programmed easily with our IXLOG software. Once the transmitter is programmed, it is also possible to connect and configure it via an Ethernet cable (Modbus TCP) or via the RS485 bus (depending on the product reference).

  • Page 24: Error Messages

    Operating manual TELIS 9000 24/ 86 Error messages Message displayed Description ---- ---- Overfl Overfl (OverFLow) message is shown flashing for an input signal higher than the selected gauge. In the event of a sensor failure, the ruPtr message is shown flashing.

  • Page 25: Main Menu

    Operating manual TELIS 9000 25/ 86 Main menu Diagram This menu allows you to enter the programming mode and configure the input, analog outputs, and relays.   *Menus available according to product reference...
  • Page 26 Operating manual TELIS 9000 26/ 86 Lexicon of screens Menus Screen Value Description MENUS   Main menu   Infos Access to the product information   Confg Access to the configuration   Param Access to the settings menu   Simul Access to the simulation function  ...

  • Page 27: Measurements Menu 1 Input

    Operating manual TELIS 9000 27/ 86 Measurements menu 1 input Diagram By default, the device is in measurement mode. Value resets and tare values are accessible in this mode. *Menus available according to product reference...
  • Page 28 Operating manual TELIS 9000 28/ 86 Lexicon of screens Input Screen Value Description Screen Value Description Main screen   RESET VALUE   Choice of reset   Input Display of the input value   Yes/No     Inφ   Display of the physical measurement INPUT TARE  ...

  • Page 29: Measurements Menu 2 Inputs

    Operating manual TELIS 9000 29/ 86 Measurements menu 2 inputs Diagram The 2 inputs is only available for current inputs. *Menu available according to product reference...
  • Page 30 Operating manual TELIS 9000 30/ 86 Lexicon of screens Input Screen Value Description Screen Value Description Main screen   RESET VALUE   Choice of reset   Inputx Display of the input value   Yes/No     Inφx  Display of the physical measurement INPUT TARE  ...

  • Page 31: Measurements Menu 2 Inputs + Calculation

    Operating manual TELIS 9000 31/ 86 Measurements menu 2 inputs + calculation Diagram The 2 inputs + calculation mode is only available for current inputs. *Menus available according to product reference...
  • Page 32 Operating manual TELIS 9000 32/ 86 Lexicon of screens Input Screen Value Description Screen Value Description Main screen   Main screen     Inputx Display of the input value MaxiInpuCL Display of the max calculated value   Inφx Display of the physical measurement MiniInpuCL Display of the min calculated value  ...

  • Page 33: Simulation Function

    Operating manual TELIS 9000 33/ 86 Simulation function Operating the simulation function This function allows you to vary the simulation value (with the up/down arrows from the SIMUL screen) to change the analog output value and relays statuses.   The measurement screens of the 1 input and 2 inputs measurements menus are available when simulation is activated.
  • Page 34 Operating manual TELIS 9000 34/ 86 Lexicon of screens Configuration Screen Value Description INPUT SIMUL       RtMes Access to the preferences for returning to the measurement mode   Start Starting the simulation mode. Back to the main screen in simulation mode  ...

  • Page 35: Input Menu

    Operating manual TELIS 9000 35/ 86 Input menu Diagram *Menu available if 1Chan mode selected...
  • Page 36 Operating manual TELIS 9000 36/ 86 Lexicon of screens Configuration Screen Value Description INPUT SELECT   Inputs Selection   Mode Access to the choice of input mode   Type Access to the choice of input type    Confg Access to the configuration of the chosen input  ...

  • Page 37: Calculated Input Configuration

    Operating manual TELIS 9000 37/ 86 Calculated input configuration Diagram  ...
  • Page 38 Operating manual TELIS 9000 38/ 86 Lexicon of screens Configuration Screen Value Description FUNCT MODE   Mode selection   1Chan 1 input   2Chan 2 inputs   Calc Calculation INPUT CONFG   Input configuration   Scale Access to the choice of input gauges  ...
  • Page 39 Operating manual TELIS 9000 39/ 86 Settings Screen Value Description Screen Value Description CALCL CALCL   Calculation selection FUNCT   Setting of the B coefficient FUNCT COEFB   Oper. Access to the choice of operation   from -1.000 to 1.000...

  • Page 40: Current Input Configuration 1 Input

    Operating manual TELIS 9000 40/ 86 Current input configuration 1 input Diagram...
  • Page 41 Operating manual TELIS 9000 41/ 86 Lexicon of screens Configuration Screen Value Description   Value Description INPUT   Input configuration CONFG   Scale Access to the choice of input gauges Funct Access to the function configuration   Point Access to the comma position setting...
  • Page 42 Operating manual TELIS 9000 42/ 86 Settings Screen Value Description Screen Value Description MINI DISPL Setting of the minimum value of the INPUT SCALE   Mode selection Setting   SCALE display scale   manu Manual Setting   from -19999 to 99999...
  • Page 43 Operating manual TELIS 9000 43/ 86 Definition of functions Square root The output(s) are function of the square root of the input   Segment Function Linearization in 99 points (free choice for each point), allows to create an output function by segmentation of the signal of each input channel.

  • Page 44: Current Input Configuration 2 Inputs

    Operating manual TELIS 9000 44/ 86 Current input configuration 2 inputs Diagram In 2-input mode, the entries have the same configuration.  ...
  • Page 45 Operating manual TELIS 9000 45/ 86 Lexicon of screens Configuration Screen Value Description   Value Description INPXT   Input configuration CONFG   Scale Access to the choice of input gauges Funct Access to the function configuration   Point Access to the comma position setting...
  • Page 46 Operating manual TELIS 9000 46/ 86 Settings Screen Value Description Screen Value Description INPUT MINI DISPL Setting of the minimum value of the   CUTOF   Setting of the cut-off value SCALE display scale VALUE     from -19999 to 99999  ...

  • Page 47: Voltage Input Configuration

    Operating manual TELIS 9000 47/ 86 Voltage input configuration Diagram...
  • Page 48 Operating manual TELIS 9000 48/ 86 Lexicon of screens Configuration Screen Value Description   Value Description INPXT   Input configuration CONFG   Scale Access to the choice of input gauges Funct Access to the function configuration   Point Access to the comma position setting...
  • Page 49 Operating manual TELIS 9000 49/ 86 Settings Screen Value Description Screen Value Description MINI DISPL Setting of the minimum value of the INPUT SCALE   Mode selection Setting   SCALE display scale   manu Manual Setting   from -19999 to 99999...
  • Page 50 Operating manual TELIS 9000 50/ 86 Definition of functions Square root The output(s) are function of the square root of the input   Segment Function Linearization in 99 points (free choice for each point), allows to create an output function by segmentation of the signal of each input channel.

  • Page 51: Potentiometer Input Configuration

    Operating manual TELIS 9000 51/ 86 Potentiometer input configuration Diagram...
  • Page 52 Operating manual TELIS 9000 52/ 86 Lexicon of screens Configuration Screen Value Description   Value Description INPUT   Input configuration CONFG   Scale Access to the choice of input gauges Funct Access to the function configuration   Point Access to the comma position setting...
  • Page 53 Operating manual TELIS 9000 53/ 86 Settings Screen Value Description Screen Value Description MINI DISPL Setting of the minimum value of the INPUT SCALE   Mode selection Setting   SCALE display scale   manu Manual Setting   from -19999 to 99999...
  • Page 54 Operating manual TELIS 9000 54/ 86 Definition of functions Square root The output(s) are function of the square root of the input   Segment Function Linearization in 99 points (free choice for each point), allows to create an output function by segmentation of the signal of each input channel.

  • Page 55: Resistance Input Configuration

    Operating manual TELIS 9000 55/ 86 Resistance input configuration Diagram...
  • Page 56 Operating manual TELIS 9000 56/ 86 Lexicon of screens Configuration Screen Value Description   Value Description INPUT   Input configuration CONFG   Senso Access to the choice of input gauges Offst Access to the offset configuration   Unit Access to unit configuration  ...

  • Page 57: Rtd Input Configuration

    Operating manual TELIS 9000 57/ 86 RTD input configuration Diagram...
  • Page 58 Operating manual TELIS 9000 58/ 86 Lexicon of screens Configuration Screen Value Description   Value Description INPUT   Input configuration CONFG   Senso Access to the choice of input gauges Offst Access to the offset configuration   Unit Access to unit configuration  ...
  • Page 59 Operating manual TELIS 9000 59/ 86 Settings Screen Value Description Screen Value Description INPUT SCALE INPUT SCALE   Mode selection Setting   Automatic Setting for special gauges AUTO   manu Manual Setting   Mini Access to the min value setting  ...

  • Page 60: Thermocouple Input Configuration

    Operating manual TELIS 9000 60/ 86 Thermocouple input configuration Diagram...
  • Page 61 Operating manual TELIS 9000 61/ 86 Lexicon of screens Configuration Screen Value Description   Value Description INPUT   Input configuration CONFG   Senso Access to the choice of input gauges Offst Access to the offset configuration   Unit Access to unit configuration...
  • Page 62 Operating manual TELIS 9000 62/ 86 Settings Screen Value Description Screen Value Description INPUT SCALE INPUT SCALE   Mode selection Setting   Automatic Setting for special gauges AUTO   manu Manual Setting   Mini Access to the min value setting  ...

  • Page 63: Output Menu

    Operating manual TELIS 9000 63/ 86 Output menu Diagram *Menus available according to product reference...
  • Page 64 Operating manual TELIS 9000 64/ 86 Lexicon of screens Configuration Screen Value Description ANALG OUTPT   Output Selection   Outx Output n°x OUTx CONFG   Output Configuration   Scale Access to the choice of output gauges   Displ Access to the display scales  ...
  • Page 65 Operating manual TELIS 9000 65/ 86 Settings Screen Value Description Screen Value Description CALIB SPEC. OUTx MAXI   Setting of Special gauge   Maximum display value Configuration OUTx VALUE   Mini Access to the min value setting   from -19999 to 99999  ...

  • Page 66: Alarm Menu

    Operating manual TELIS 9000 66/ 86 Alarm menu Diagram *Menu available according to product reference...
  • Page 67 Operating manual TELIS 9000 67/ 86 Lexicon of screens Configuration Screen Value Description ALARM   Alarm selection   Alarx Alarm n°x (the number of relays available depends on the product reference)   Submenu Screen Value Description   Value Description ALARx  ...
  • Page 68 Operating manual TELIS 9000 68/ 86 Settings Screen Value Description Screen Value Description ALARx ALARx DISPL   Choice of the alarm display   Choice of use of the sensor break-up RUPTR USE   On/Off     Yes/No   ALARx RELAY ALARx  ...
  • Page 69 Operating manual TELIS 9000 69/ 86 Definition of hysteresis Hysteresis makes it possible to define, near a certain threshold, an area in which the alarm is insensitive to variations of the input and does not change state.   This makes it possible to limit changes of the alarm state when the input undergoes variations in value is close to the alarm threshold.
  • Page 70 Operating manual TELIS 9000 70/ 86 • Low band alarm • High band alarm      ...

  • Page 71: Modbus Protocol

    • The LINE product is a communication hub. It retrieves all the information of the JM Concept devices present on the MODBUS RTU line and makes them available to PLC via the Profinet, Ethernet IP, Modbus TCP, Profibus or MODBUS RTU protocols.
  • Page 72 • Slave number: The slave number of the JM Concept device queried (1 to 247) • Function code: Action requested from the slave, read, or write. JM Concept products support 4 codes depending on the MODBUS protocol: Function codes Description...
  • Page 73 The data is stored in the product's memory in big-endian format, the most significant bytes are placed in the lead and therefore occupy memory locations with smaller addresses. Depending on the devices interfaced with JM Concept products, it may be necessary to reverse the 2 words of 16 bits when reading a float.
  • Page 74 Operating manual TELIS 9000 74/ 86 Some use cases Reading n bits - Positive response Writing n words - Positive response   Function code error - Negative response      ...

  • Page 75: Modbus Exchange Table

    Operating manual TELIS 9000 75/ 86 MODBUS exchange table The “P” column (for Permissions) indicates the type of access that can be performed on each variable. R=read ; W=write ; R/ W=read and write. Measurement values @Jbus word @Jbus bit...
  • Page 76 Operating manual TELIS 9000 76/ 86   Modbus settings @Jbus word @Jbus bit Variable designation Format Modbus network n° slave Byte   Baud rate Byte   Protection Configuration @Jbus word @Jbus bit Variable designation Format Configuration lock Byte   Access to configuration Byte  ...
  • Page 77 Operating manual TELIS 9000 77/ 86   Input 1 configuration @Jbus word @Jbus bit Variable designation Format       Input type Byte Gauge for Current  Byte Gauge for Voltage Byte Sensor for resistance input Byte Sensor for RTD input Byte  ...
  • Page 78 Operating manual TELIS 9000 78/ 86   Current input 2 configuration @Jbus word @Jbus bit Variable designation Format Gauge for Current  Byte Comma position Byte Display resolution Byte Use of the cut-off Byte     Digital filter Byte   Operation for the calculation function Byte  ...
  • Page 79 Operating manual TELIS 9000 79/ 86   Output measurements @Jbus word @Jbus bit Variable designation Format   S.A1 Instant output level Float     S.A2 Instant output level Float           Output S.A1 level memorization Float  ...
  • Page 80 Operating manual TELIS 9000 80/ 86   Output S.A1 configuration @Jbus word @Jbus bit Variable designation Format 1584 Gauge Byte 1592 Output assignment Byte   Minimum gauge value Float     Maximum gauge value Float     Minimum display value Float  ...
  • Page 81 Operating manual TELIS 9000 81/ 86   Relay RL1 configuration @Jbus word @Jbus bit Variable designation Format 2064 Alarm AL1 memorization Byte 2072 Memorization of the state of relay RL1 Byte 2080 Visualization of the alarm AL1 Byte 2088 Relay RL1 status in alarm Byte  ...
  • Page 82 Operating manual TELIS 9000 82/ 86 Relay RL3 configuration @Jbus word @Jbus bit Variable designation Format 2416 Alarm AL3 memorization Byte 2424 Memorization of the state of relay RL3 Byte 2432 Visualization of the alarm AL3 Byte 2440 Relay RL3 status in alarm Byte  ...
  • Page 83 Operating manual TELIS 9000 83/ 86 Segments function for input 1 @Jbus word @Jbus bit Variable designation Format 2768 Number of linearization points Byte           % Input point 1 Float   Display of point 1 Float …...
  • Page 84 Operating manual TELIS 9000 84/ 86 Device comments zone @Jbus word @Jbus bit Variable designation Format   Byte 6 128     Byte      …   …    80 bytes comment   Byte   6 167   Byte  ...

  • Page 85: Guarantee Certificate

    Si un appareil ne peut plus être utilisé dans les conditions de sécurité optimales, il doit être mis hors service et protégé contre toute utilisation par inadvertance, avant d’être retourné chez JM Concept. Les réparations se font uniquement dans les locaux de JM Concept. Toute installation ne correspondant pas aux impératifs de montage entraîne l’annulation de la garantie.

  • Page 86: Ue Declaration Of Conformity

    TELIS Nous, JM Concept, fabricant, confirmons sous notre seule responsabilité, la conformité aux exigences essentielles des directives européennes : As manufacturer JM Concept confirm under our sole responsability, the conformity to the essential requirements of the European directives : DBT/LVD : 2014/35/UE CEM/EMC : 2014/30/UE RoHS : 2011/65/UE &...
