Summary of Contents for MotionGrey MotionStride
- Page 1 MotionStride - User Manual CAUTION Please read the User Manual carefully before use of this product. Keep the manual properly.
-
Page 2: Table Of Contents
Contents Product Brief ..................Installation Instruction ................. Product Introduction ................Technical Parameters ................Product Features ................. Operation Instruction ................I. Brief Introduction ..............II. Parameter Description ............III. Button Function Description ..........IV. Button Function and Operation Instructions ......V. Description of Sports Mode ........... VI. -
Page 3: Product Brief
Product Brief Part Name Quantity Treadmill Digital watch Remote control Installation Instruction 1. Open the package, take out the assembly materials from the box, and place the host on the ground; 2. Turn on the power and operate the remote control to operate the machine. -
Page 4: Product Introduction
Product Introduction Packing List Name Quantity Remarks Complete machine (running platform) Kits As attached Manual, Certificate 1 each Attached List Name Quantity Remarks 6mm Allen wrench Remote control Dual purpose screwdriver Silicone oil 30ml... -
Page 5: Technical Parameters
Technical Parameters Item Number A5B mini Operating 120V 50/60Hz Maximum Load 120kg Fold: 1161 *514*118.5mm Dimensions Expand:1161 *514*118.5mm Effective Running Area 895*390mm N.W/G.W 22KG/26KG Motor Peak 0.75-2.5HP peak Speed 1.0−8.0Km/h Function Walking, Jogging, Running Product Features 1. It has the function of walking. 2. -
Page 6: Operation Instruction
Operation Instruction The new machine needs to be adapted to the remote control after receiving it. The method is: first press and hold the start button of the remote control, and then turn on the power of the treadmill. Switching between unmanned stop and normal mode: Press and hold the acceleration and deceleration keys at the same time, and then turn on the power of the treadmill. -
Page 7: Button Function And Operation Instructions
IV. Button Function and Operation Instructions • Start key 1. Function description: start the motor to run 2. Operation instructions: When the electronic watch is in full manual operation mode, press this button to start the motor • Stop key 1. -
Page 8: Sleep Function Description
VI. Sleep Function Description When the walking machine stops running, if there is no operation for more than 10 minutes, it will enter the sleep state, and the electronic watch will automatically turn off the display. Press any key to wake up the electronic watch, and then enter the initial standby state again after full display. - Page 9 E03: Indicates that the lower control detection speed abnormal phenomenon prompts. The photo sensor is not Reassemble properly assembled on the motor (light sensor mode) Solutions Defective photoelectric sensor Replace photoelectric (photosensitive mode) sensor Common The detection circuit of the Replace lower control or Problems lower control board fails or...
- Page 10 E05 ： Indicates the information prompt of the over-current protection of the down-control motor. The load of the walking machine It is recommended to be exceeds the rated operating within the rated operating current of the motor current range of the motor There is a problem with the Check whether the Solutions...
-
Page 11: Safety Instruction
Safety Instructions Thank you for purchasing our products. Correct use of the walking machine is your guarantee of safety and convenience. Please read the following carefully before using the walking machine: 1. After confirming that the walking machine is installed in accordance with the installation instructions, the power can be turned on. -
Page 12: Exercise Recommendations And Guidelines
8. If you are using the walking machine for the first time, please remember to hold the handrail with your hands, and you can not release the handrail until you feel comfortable. 9. If the electric walking machine suddenly accelerates or the speed of the walking machine increases automatically due to a problem with the electronic watch system, please unplug the safety lock on the electronic watch immediately, and the electric walking machine will stop immediately. - Page 13 as much as possible: then stand on the running belt and exercise with it. After feeling adapted, slowly increase the speed to 3-5km/h. Keep this speed for about 10 minutes, and then slowly stop the machine. Do not run at high speed for the first time to prevent falling.
- Page 14 Stretching Exercises No matter how fast you're walking, it's a good idea to stretch first. Warm muscles are easier to stretch, so warm up by walking for 5-10 minutes first. Then stop and stretch as follows -- 5 times for 10 seconds or more on each leg: Do it again after the workout.
-
Page 15: Exercise Safety Measures
Exercise Safety Measures Consult a professional before exercising. He can help you recommend exercise frequency, exercise intensity, and exercise time appropriate to your age and physical condition. If you feel chest tightness or pain while exercising, your heart beats irregularity, shortness of breath, dizziness or other discomfort, please stop immediately! Consult a professional before continuing to exercise. -
Page 16: Maintenance Instructions
Maintenance Instructions In order to better maintain your electric treadmill and prolong the life of the machine, it is recommended that you turn off the power after 2 hours of continuous use and let the machine rest for 10 minutes before using it. If the running belt is too loose, it will slip during running;... - Page 17 Belt Tension Adjustment All treadmills require adjustment of the running belt before leaving the factory and after installation, but there may be some slack after a period of use. For example: The user has the phenomenon of pause and slippage when running. When this phenomenon occurs, adjust the adjusting bolts of the running belt synchronously from left to right in a half-turn clockwise direction.
Need help?
Do you have a question about the MotionStride and is the answer not in the manual?
Questions and answers
Hi. I own a MotionStride. The running surface needs to be adjusted. It is now aligned too far to the right. (See photo) I'm trying to use the instructions provided in the user manual but I'm not really sure what I should be doing. Should I be adjusting the running belt? Or should I be adjusting the drive belt? I have tried using the allen key to turn the adjustment bolt starting with the half turns suggested but nothing happened. I tried turning several more times and still nothing is changing. Help!!! What should I do? I eagerly await your answer. Thank you. Tammy
To adjust the running surface alignment on a MotionGrey MotionStride treadmill, follow these steps:
1. Place the treadmill on a flat surface.
2. Set the treadmill to run at a speed of about 3.5 km/h.
3. If the running belt is skewed to the left:
- Turn the left adjustment bolt 1/2 turn clockwise.
- Turn the right adjustment bolt 1/2 turn counterclockwise.
4. If the running belt is skewed to the right:
- Turn the right adjustment bolt 1/2 turn clockwise.
- Turn the left adjustment bolt 1/2 turn counterclockwise.
This answer is automatically generated
