Part #s
GWS- MOB1 (Mobile Stand)
GWS-FL1 (Floor Model)
GWS-B1 (Base Only)
Always use the recommended equipment to prevent damage or failure.
Do not allow children under the age of 18 years of age to use the stand.
Do not use the stand for any other purposes than what is described in our manuals and
web site.
Do not use substitute parts. Contact the manufacturer or Goliath Carts for replacement
parts.
1 |
P a g e
GWS-WELD STAND ASSEMBLY INSTRUCTIONS
GOLIATH GWS-WELD STAND SAFETY INSTRUCTIONS
Please read completely before using the Stand.
This product is manufactured by Goliath Carts, LLC.
P.O. Box 891210
Temecula, CA 92589-1210
Toll Free: 866.694.2278
www.goliathcarts.com
V e r s i o n 1 . 1 – 1 0 / 2 6 / 2 0 2 3
Advertisement
Table of Contents
Related Manuals for goliath GWS-MOB1
Summary of Contents for goliath GWS-MOB1
- Page 1 Do not use the stand for any other purposes than what is described in our manuals and web site. Do not use substitute parts. Contact the manufacturer or Goliath Carts for replacement parts. This product is manufactured by Goliath Carts, LLC.
- Page 2 GOLIATH GWS-WELD STAND ASSEMBLY INSTRUCTIONS with Base Stand (optional) Part # Description Weld Stand Base Donuts Optional Weld Stand Base (with Casters) 18” X 24” Vertical 2” inch Poles (47” and 36”) 1/4” - 20 X 1.25” Flat Screw 1/4"- 20 X 3/4” Hex Bolt Telescoping Arm 1/4:-20 X 1/4”...
- Page 3 Shelf with Tool Holder White Board Wet/Dry Coupon Holder STEP 2: Install Shelf Between 2 Donuts, Install Wet/Dry Coupon Holder, and attach Whiteboard 1. Attach a Weld Stand Donut (Part A) to the top of the 36” Weld Stand Pole (Part C) and tighten the (3) 1/4'-20 X 1/4" Set Screws (Part G).
- Page 4 (Part I) Tighten using the included T-Handle Tool (Part K) GWS-WELD STAND with w/ STAND INSTALLATION IS COMPLETE. You can now start using the Goliath Carts Weld Stand. Coupons can be inserted and secured using the Wing Head Screws. Please make sure to tighten with the included T-Handle Tool.
