User Manual
Telescopic column tables 6000E series and 6800E series
Dear customer,
Congratulations on purchasing a product of outstanding quality.
Use of the best materials from renowned suppliers guarantees years of trouble-free operation, provided the
device is handled correctly and as intended in accordance with the conditions described in the user manual.
In the unlikely event you need to make a claim, please contact us.
We welcome suggestions from the users of our products.
Contents
1.1 Applied symbols
1.2 Applied standards
1.3 Safety regulations
1.5 Information on setup and use
1.6 Commissioning
1.7 Safety instructions
1.8 Entrance area
1.9 Model designation and type labelling
1.10 Meaning of the serial number
2. Operation
2.1 Table design
2.2 Height adjustment
2.3 Head part adjustment
2.4 Adjustment of other sections
2.6 Additional equipment
2.7 Special features of model 6100
4.1 Individual models
4.2 Technical data for motor
11. Checklist for maintenance/technical inspection
K.H. DEWERT GmbH
Vollmestr. 7
33649 Bielefeld
Germany
Tel. +49 / 521 400 27-0
Fax +49 / 521 400 27-27
info@khdewert.de
www.khdewert.de
Subject to changes in materials and construction as a result of technical progress.
Dewert User Manual 6000E and 6800E - Updated 03.2023/4 MDR
Page 1 of 13
Advertisement
Table of Contents
Summary of Contents for K.H. DEWERT 6000E Series
-
Page 1: Table Of Contents
User Manual Telescopic column tables 6000E series and 6800E series Dear customer, Congratulations on purchasing a product of outstanding quality. Use of the best materials from renowned suppliers guarantees years of trouble-free operation, provided the device is handled correctly and as intended in accordance with the conditions described in the user manual. -
Page 2: Safety Information
This product is not approved for the American market. Distribution and use of the product in these markets, including through third parties, is prohibited by the manufacturer. 1. Safety information 1.1 Applied symbols Safety instructions and key sections in these operating instructions are marked with the exclamation mark symbol on the left. - Page 3 1.4 Intended purpose The table is used for the ideal positioning of patients for the purpose of curative and disease treatment, examination, massage and health therapy. Table operation and patient positioning on the table may only be performed by professionally trained persons who have been instructed in its use or who, through experience with other similar medical devices, have knowledge of its proper use, taking into account possible hazards.
- Page 4 When adjusting the upholstery parts, make sure that no persons or objects are in the adjustment range. Make sure that no persons reach under the upholstery part or lean on the underframe. Important for the user: When adjusting the upholstery parts, do not reach under the spacers located beneath the upholstery parts.
- Page 5 1.9 Model designation and type labelling The exact model designation depends on the choice of frame colour: -03 white aluminium powder coated (RAL 9006); -04 grey aluminium powder coated (RAL 9007) The type plate is attached to the underframe on one long side of the table. It provides information about key table data.
-
Page 6: Movability
Note on operation The electric motor is to be operated in intermittent duty mode. This means that a maximum duty cycle of 25 s must not be exceeded. Before switching the motor back on, an interruption time of at least 400 s must be observed. - Page 7 Stage 1: The castors of the table are locked and can neither be moved nor rotated. Stage 2: = centre position: The castors are released and can be moved and rotated, the table can be moved in all directions. Stage 3: Three castors are released (= can be moved and rotated). The fourth castor is locked and cannot be rotated (directionally locked castor), i.e.
-
Page 8: Additional Accessories
Side guard, lowerable, for side rail (model dependent optional equipment) This side guard can be placed and fixed on any side rail using a clamp. By loosening the toggle screw of the clamp, the position and height of the inserted side guard can be shifted and adjusted respectively. Complete lowering below the upholstery level can only be achieved if the guide points in the direction of the upholstery when the side guard is inserted into the clamp. - Page 9 Models 6080E 6085E 6100E 6880E 6885E Max. length (mm) 1950 1950 2000 Width (mm) Min. – max. height (mm) 620 - 1020 620 - 1020 620 - 1020 Adjustment time (motor) (s) Adjustment time, inclined position (motor) (s) Weight (approx., depending on equipment) kg Head part adjustment range +35°...
-
Page 10: Cleaning Instructions
5. Cleaning instructions Upholstery covering There are two different collections of upholstery covering to choose from: • Skai Pandoria Plus (manufactured by Hornschuch/Continental in Germany) • Skai Toronto EN (manufactured by Hornschuch/Continental in Germany) For cleaning and disinfection, a selection of agents from various manufacturers has been tested for compatibility. -
Page 11: Safety Devices
• Thorough visual inspection of all components, especially motor and switch with mains supply line • Function check • Check all swivel joints for completeness. • Check proper fit of the screw connections, especially the screw connection of the optional roller system. •... -
Page 12: Reporting Obligation
8. Reporting obligation All serious incidents occurring in connection with the product shall be reported to the manufacturer (K.H. Dewert GmbH) and to the competent authority of the Member State in which the user and/or the patient resides. Member State Competent authority Estonia Health Board Terviseamet... -
Page 13: Declaration Of Conformity
10. Declaration of Conformity EU Declaration of Conformity for medical devices Manufacturer: K.H. DEWERT GmbH Vollmestr. 7 D-33649 Bielefeld SRN: DE-MF-000005967 Product: Electromotive height adjustable table Model designation*: 6000E, 6001E, 6805E, 6050E, 6051E, 6810E, 6870E, 6070E, 6075E, 6875E, 6080E, 6880E, 6085E, 6885E, 6100E... - Page 14 Checklist for maintenance/technical inspection to IEC 62353 and DGUV Regulation 3 Device Model designation Manufacturer K.H. Dewert GmbH Serial no. Location Responsible person Date, inspector Actuator designation Inspections FAIL Description of defects Visual inspection Overall impression of the table OK? Labels, CE mark, type plate present? Manufacturer’s operating manual available and accessible?
- Page 15 FAIL Description of defects Height retained? Hydraulic pump leaking? Smooth lowering possible? Check by operating the pedals to lower the table Strong noise development? Wipe the piston rod with a cloth Lying surface adjustment functions: Metal ratchets - arrester - gas spring Metal ratchet inspection: Lifting the lying surface segment: Do the two metal ratchets engage properly and securely? Do they engage evenly?
