Summary of Contents for Antronix CAG ONE
- Page 1 USER MANUAL Accuracy. Consistency. Performance SINCE 1987...
- Page 2 DIMENSION, WEIGHT AND ELECTRICAL Weight: 25 kg / 55 lbs Length: 720 mm / 28.5” Height: 220 mm / 8” Dept: 260 mm / 10.5” Power: 110 V, 60 Hz, 300W - 3A CONSUMABLE 250 Pairs / Grinding Wheel 1000 Pairs / Spinner Dresser 250 Pairs / Honing Stone...
-
Page 3: Technical Description
TECHNICAL DESCRIPTION 1. Front dust panel 6. Power cord 2. Skate holder 7. Vacuum cleaner Servocommander plug 3. Touch keyboard and Safety switch 8. Grinding wheel pressure adjuster 4. Grinding wheel height adjuster 9. Grinding wheel 5. Dressing arm 10. Spinner Diamond Dresser... - Page 4 INCLUDED ACCESSORIES AND SUPPLIES 1 x Servocommander 6 x Grinding wheels 6 x Honing stones 3 x Diamond Spinners 1 x Power cord 1 x CAG ONE Transport case SKATE SHARPENING CHART...
-
Page 5: Installation
INSTALLATION 1. PULL OUT THE MACHINE FROM THE TRANSPORT TAKE OFF BOTH TRANSPORT SCREWS 2. INSTALL THE DRESSING HANDLE AND THE VACCUM CLEANER HOSSE (OPTIONAL) INSTALL THE DRESSING HANDLE INSTALL THE VACCUM CLEANER HOSSE (OPTIONAL) - Page 6 INSTALLATION (Suite) 3. GENTLY MOVE THE SKATE HOLDER DEVICE TO THE LEFT 4. PLUG THE POWER CORD, SERVOCOMMANDER AND VACCUM CLEANER (OPTIONAL) PLUG THE SERVOCOMMANDER PLUG THE VACCUM CLEANER CORD IN THE "VACUUM" SLOT, AND TURN IT ON (OPTIONAL)
- Page 7 INSTALLATION (Suite) 5. INSTALL THE GRINDING WHEEL AND THE SPINNER DRESSER INSTALL THE GRINDING WHEEL INSTALL THE SPINNER DRESSER 6. ADJUST THE SHARPENING GRINDING WHEEL HEIGHT TURN THE POWER ON...
- Page 8 INSTALLATION (Suite) 1. START SHARPENING 3. 1 SHARPENING CYCLE 5. REGULAR SHARPENING 6. FINISHING 2. CANCEL SHARPENING 4. 5 SHARPENING CYCLES & DRESSING 7. ADJUST GRINDING WHEEL PRESSURE...
- Page 9 INSTALLATION (Suite) 8. SOFTLY SHAPE THE GRINDING WHEEL OVER THE SPINNER DRESSER TO REACH A REALLY SMOOTH FEELING SHAPE THE GRINDING WHEEL FOR SHAPE THE GRINDING WHEEL FOR 2-3 SECONDS EVERY 3 PAIRS OF 2-3 SECONDS EVERY 3 PAIRS OF SKATES SKATES 9A.
- Page 10 THE HONING STONE *10. ADJUST THE GRINDING WHEEL HEIGHT TO SHARPEN FIGURE SKATES *If your Cag One machine is equiped with the Self-Centering Blade holder #9B, forget about the step # 10 RESURFACE THE WHEEL WHEN THE NEW DIAMOND IS INSTALLED...
- Page 11 *10. ADJUST THE GRINDING WHEEL HEIGHT TO SHARPEN FIGURE SKATES *If your Cag One machine is equiped with the Self-Centering Blade holder #9B, forget about the step # 10 MOVE THE WHEEL DOWN WITH THE HEIGHT AJUSTER TONE "SAVE THE SPIKES"...
- Page 12 antronixsharpeners.com sales@antronixsharpeners.com 1-800-577-2198 facebook.com/antronixsharpeners instagram.com/antronix_sharpeners...
