Specification
IS-639LMCM30
Model
Pick up Element
1/3" SONY Super HAD CCD II
Effective Picture Elements
NTSC:768(H)×494(V) PAL:752(H)x582(V)
(H×V)
Horizontal Resolution
650 TV Line
Minimum Illumination
0.001 Lux/F1.2
S/N Ratio
More than 52dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic
0.45
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
Power/Current
DC12V(+/-10%)/150mA
3.7mm Taper Pinhole
Lens
Size: 30(W) x 19(H) x 30(D)mm
Dimension (mm)
Weight (g)
150
Storage Temperature
-30~+60℃ RH95% MAX
Operating Temperature
-10~+50℃ RH95% MAX
Packing List
No
Name
Model
1.
Miniature Color Camera
2.
User Guide
Franchiser：
Number
1
1
IS-639LMCM30
Color Camera
Miniature Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
