25500860 Rev A1 0923
Introduction
This instruction sheet describes how to assemble the OMNI-B Series Antenna Kit. For more information,
see the Yagi and Omni Antennas Installation manual at http://www.fedsig.com (part number 25500445).
INSTALLATION PRECAUTIONS: Installation should be performed by an experienced electrician
or qualified radio technician. Keep antenna away from metal objects and power lines.
BURN HAZARD: Antennas may cause severe burns. Do not touch the antenna while the radio is
transmitting.
INSTALLATION PRECAUTIONS: Radio and antenna installation must conform to the system's
FCC (or equivalent) license, which specifies the RF frequency, modulation, RF power, antenna
location, and mounting height. Do not operate the radio system until the installation has been
confirmed to comply with the license.
The following table list the common components included in the kit.
Not Shown
Not Shown
Not Shown
Not Shown
Not Shown
Tools Required
The following tools are required for assembly:
•
3/4 inch or 19 mm deep well socket and wrench
Item
Qty
Description
1
1
Antenna Base with Gasket
2
1
NMO Mount/Adapter
3
1
O-ring
4
1
Die-cast Antenna Bracket
5
4
8-32 Stainless Steel Socket Self-lock Set Screw
6
4
Radial, GND Plane
7
1
Lockwasher, Internal Tooth
8
1
5/8" Flat Washer
9
1
Lockwasher, Internal Tooth, Thin
10
1
5/8"-24 Hex Nut
11
1
5/16"-18 Stainless Steel Self-lock Set Screw
12
4
Protective Rubber Cap
13
1
Radiator Whip
2
15/16" Heat Shrink Tubing
1
Dielectric Grease Tube
1
5/64" Hex Key
1
5/32" Hex Key
1
3/32" Hex Key
Assembling the OMNI-B Series
Antenna Kit
Table 1 Contents
Advertisement
Table of Contents
Related Manuals for Federal Signal Corporation OMNI-B Series
Summary of Contents for Federal Signal Corporation OMNI-B Series
- Page 1 25500860 Rev A1 0923 Introduction This instruction sheet describes how to assemble the OMNI-B Series Antenna Kit. For more information, see the Yagi and Omni Antennas Installation manual at http://www.fedsig.com (part number 25500445). INSTALLATION PRECAUTIONS: Installation should be performed by an experienced electrician or qualified radio technician.
- Page 2 Assembling the OMNI-B Series Antenna Kit • Flat file or rotary cut-off wheel. (Only needed for shortening the whip on the OMNI-BVH when using frequencies > 168-174 MHz). Assembling the Antenna To assemble the antenna: 1. Open the parts bag and locate the five set screws (Items 5 and 11). Using the supplied hex keys, thread the set screws into the die-cast bracket with just a couple of turns.
- Page 3 Assembling the OMNI-B Series Antenna Kit Figure 1 Exploded View Assembling the OMNI-B Series Antenna Kit Federal Signal www.fedsig.com...
- Page 4 This product is subject to and covered by a limited warranty, a copy of which can be found at www.fedsig.com/SSG-Warranty. A copy of this limited warranty can also be obtained by written request to Federal Signal Corporation, 2645 Federal Signal Drive, University Park, IL 60484, email to info@fedsig.com or call +1 708-534-3400.
