- Page 1 CubuSynth Engine – User Manual PCB V1.1 Jul 2022 Expander Module for the CubuSynth Engine User Manual PCB V1.1 May 2022 Written and Illustrated by Ruben Sponar Page 0...
- Page 2 Installation ………………..... Page 4 Limited Warranty: CubuSynth guarantees this product to be without defects in materials and workmanship for a period of one year from the date of purchase (proof of purchase/invoice needed). Malfunctions due to improper supply voltages, incorrect or reversed Eurorack power cable connection, misuse of the product, removal of knobs, changing faceplates, or other causes determined by CubuSynth are the user's responsability and are not covered by this warranty.
- Page 3 PCB V1.1 Jul 2022 1. Introduction The Exhaust adds many features to your Engine VCO module like Sub-octaves, Mixing and a Gate generated by the Chaos signal. You can select one of the two VCO cores of the engine to Produce Square Waves one and two octaves below the Oscillators frequency.
- Page 4 CubuSynth Engine – User Manual PCB V1.1 Jul 2022 2. Specifications • Size: 8HP / 40mm • Depth: 35mm (measured from the front panel) • Current Draw: +12V: +6mA -12V: -5mA 3. Key features − Two Sub-Ocatve generator with selection switch −...
- Page 5 PCB V1.1 Jul 2022 4. Installation To connect the module, plug in the 10pin Ribbon cable correctly to your CubuSynth Engine and the Exhaust while your rack is powered OFF! Make sure orientation is correct. (Red stripe down). https://cubusynth.com/ https://www.facebook.com/cubusynth https://www.instagram.com/cubusynth_modular/...
