Summary of Contents for Gowei G1pro
- Page 1 TWO-WAY RADIO Dustproof Drop proof Waterproof G1pro/G2pro Operation instructions If you have any questions, please feel free to contact us. Web： www.goweipro.com Email： support@goweipro.com WIRELESS...
- Page 2 Do not attempt to service the radio yourself. Removing the cover will void the warranty. Changes or modifications not expressly approved by Gowei may void the user's authority granted by the FCC to operate this device and should not be made.
- Page 3 WARNING: Important Safety Instructions for Battery Read All Instructions Do not incinerate the battery even if it is severely damaged or is completely worn out. Do not discard battery in a fire. The battery pack can explode in a fire. Do not replace battery in any area labeled “Hazardous Atmosphere".
-
Page 4: Customer Assistance
Product Service & Support Assistance For any questions about operating this new Gowei branded product, PLEASE CONTACT US FIRST... do not return this product to the retail store. The contact information for support will vary depending on the country in which you purchased and utilize the product. -
Page 5: Electromagnetic Interference
Customer Operational Cautions Assistance Exposure to high volume sound levels may cause temporary or permanent damage to your hearing. Although there is no single volume setting that is appropriate for everyone, you should always use your radio with the volume set at low level and avoid prolonged exposure to high volume sound levels. -
Page 6: Introduction Product Features
Introduction Product Features G1Pro Antenna External Speaker Jack Microphone Backlit LCD Display Power On/Off Menu Call Scan channel Lock Monitor Volume - Volume + Select Select Microphone Speaker Type-C Charge Jack Desktop Holster Charger... - Page 7 G2Pro Antenna External Speaker Jack Microphone Backlit LCD Display Power On/Off Menu Call Scan channel Monitor Lock Volume - Volume + Select Select Speaker Microphone Type-C Charge Jack Desktop Holster Charger...
-
Page 8: Backlit Lcd Display
Backlit LCD Display Introduction Features 22 Channels 99 Privacy Codes (38 CTCSS codes/61 DCS codes) 1. Transmit/Receive status IP67 Water Proof and Dust Proof Rating 2. Channel Numbers Hands-Free Operation (VOX) 3. Battery Level Indicator Backlit LCD Dispiay 4. DCS /CTCSS Privacy Code Button Lock Numbers Speaker/ Microphone/Charge Jack... -
Page 9: Installing Batteries
2. Insert the cable into the charge jack located on the Bottom of the radio. 3. Plug the cable into USB-compatible power port. Only use the supplied rechargeable batteries and desktop charger for recharging your Gowei radio. Gowei recommends your radio is turned off while being charged. -
Page 10: Quick Start
The radio will display flashing battery icon while charging. Note: Gowei recommends your radio be turned off while charging. Quick Start Press MENU button for 3 seconds to start the machine and press and hold the button again to turn it off. -
Page 11: Turning On Your Radio
Turning on Your Radio Press MENU button for 3 seconds to start the machine and press and hold the button again to turn it off. The display briefly displays all available feature ICONS on the radio. The display screen then shows the current channel, code and all features that are enabled. -
Page 12: Selecting A Channel
This radio is equipped with default Privacy Code on each channel for minimizing unwanted signals from others. See page 15 for procedures changing your radio from default Privacy Code to a different Privacy Code or disabling Privacy Code. Selecting a Channel Press MENU button once, then press button. -
Page 13: Call Button
Call Button Call Button Press and release the CALL button. The other person will hear a three second call tone. This tone is used only to establish voice communications. Lock Function Lock Button The Lock function locks the , MENU and MON buttons to prevent accidental operation. -
Page 14: Operation
Operation Mode Functions Scrolling Through the Mode Function By scrolling through the MENU function, you will be able to select or turn on preferred features of your radio. When scrolling through the MENU function, your radio features will be displayed in the same predetermined order: MENU Button Channel 22 channels... -
Page 15: Privacy Codes
Privacy Codes Your radio incorporates two advanced coded squelch systems that can help to reduce interference from other users on any given channel. CTCSS (Continuous Tone Coded Squelch System) provides 38 privacy codes and DCS (Digitally Coded Squelch) provides 61 privacy codes. This provides a total of 99 Privacy Codes. -
Page 16: Call Ringtone
Seting the Privacy Codes To select a privacy code: MENU Button After selecting a channel, press the MENU button until the small numbers or “OF ” of next to the channel number flash on the display. Privacy Code Press the button to select a privacy code. - Page 17 Voice Activated Transmit （VOX) In VOX mode, your radio can be used “hands-free," automatically transmitting when you speak. You can set the VOX sensitivity level to fit the volume of your voice and avoid transmissions triggered by background noise. To turn VOX mode on or off: VOX Icon Press the MENU button until the VOX icon shown on the display.
-
Page 18: Roger Beep Confirmation Tone
Roger Beep Confirmation Tone Your listener will hear an audible tone when you release the PTT button. This alerts the other party that you have finished talking and it is OK for them to speak. Roger Beep Confirmation Tone on or off: Confirmation Tone OFF Press the MENU button until the icon shown on... -
Page 19: High/Low Power Selection
High/Low Power Selection You can choose between high power and low power based on your specific needs. In high power mode, communication distance will be greater but it will consume more battery. In low power mode, communication distance will be shorter, but it will be more power-efficient. -
Page 20: Monitoring Mode
Monitoring Mode MON Button Enable the monitoring mode: Hold MON button and after 3 seconds to enter the monitoring mode. Release this button to exit the mode. This mode is generally used when the signal of the other party is weak and it is not clear or intermittent. -
Page 21: Important Notice
Operation General Specifications IMPORTANT NOTICE WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received. - Page 22 Important FCC RF Exposure Requirements: For body-worn operation, this radio has been tested and meets the FCC RF exposure guidelines when used with Gowei accessories supplied or designated for this product. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. Use only the supplied antenna.
-
Page 23: Radiation Exposure Statement
FCC Warnings: Replacement or substitution of transistors, regular diodes or other parts of a unique nature. with parts other than those recommended by Gowei may cause a violation of the technical regulations of part 95 of the FCC rules, or violation of type... - Page 24 If you have any questions, please feel free to contact us. Web： www.goweipro.com Email： support@goweipro.com...
