Page 1 INSULATION TESTER IT365 Instruction Manual...
Page 2: Table Of Contents
Contents 1. Safety Information ............2 - 4 2. Description of the Instrument 2.1. Front and Rear ............. 5 2.2. Rotary Switch .............. 6 2.3. Button and Indicators ..........7 - 8 2.4. LCD Display ..............9 3. Specifications ............10 - 13 4.
Page 3: Safety Information
1. Safety Information Read all safety information carefully before attempting to operate or service • the meter. Do not use the Tester around explosive gas, vapor, or in damp or wet • environments. Keep ngers behind the nger guards on the probes. •...
Page 4 1. Safety Information CAUTION! Disconnect the test leads from the test points before changing the position • of the function rotary switch. Never connect a source of voltage with the function rotary switch in , Lo , • 50V, 100V, 250V, 500V, 1000V position. Environment conditions: Installation categories CAT IV 600 V •...
Page 5 1. Safety Information Symbol Description WARNING. Do not use in distribution systems with voltages > 660 V. Conform to European Union directives. Do not discard this product or throw away. Measurement Category IV is applicable to test and measuring circuits connected at the source of the building’s low-voltage MAINS installation.
Page 6: Description Of The Instrument
2. Description of the Instrument 2.1. Front and Rear: LCD display Measurement function selection switch TEST button COM input terminal Warring light Positive input terminal PI / DAR function select button Battery cabinet Blue button Foldable stand Backlight button Holster LOCK button...
Page 7: Rotary Switch
2. Description of the Instrument 2.2. Rotary Switch: Rotary switch selections: Switch Position Measurement Function Measuring low resistance from 0.01 to 60.0 (Open voltage ≥ 4V, short current ≥ 200mA) Measuring resistance or continuity Measuring AC or DC voltage Turn o the tester Perform insulation tests with 50, 100, 250, 500, 1000 V test voltage.
Page 8: Button And Indicators
2. Description of the Instrument 2.3. Button and Indicators: Button / Indicator Description Con g the Tester for a polarization index or dielectric absorption ratio test. Press the blue button to select alternate measurement functions. (1) Initiate an insulation test when the rotary switch is in INSULATION( ) position.
Page 9 2. Description of the Instrument Button / Indicator Description Backlight ON/OFF (1)To turn on Backlight: Press Backlight button once to turn on the Backlight. And it will automatically turn o after 30 seconds. Press and hold Backlight button for 2 seconds and it will sound “beep”...
Page 10: Lcd Display
2. Description of the Instrument 2.4. LCD Display: Symbol Description Battery indication. The “ ” symbol appears when low battery. Auto Power OFF indication. Polarization index or dielectric absorption ratio test is selected. lead zero is active. Alternative or Direct source indication Unsafe voltage warning.
Page 11: Specifications
3. Specifications Approx. 10 minutes. Auto power oﬀ: The 10-minute timer is disabled during any insulation resistance or Low resistance measurement. Low battery indication: The symbol “ ” and message “ ” will be shown when the batteries need to be replaced. Operating temperature and Humidity: 0°C to 40°C (32°F to 104°F), below 80% RH -10°C to 60°C (14°F to 140°F), below 80% RH...
Page 12 3. Specifications AC voltage: Range Resolution Accuracy Protection 60.00V 0.01V ±2%rdg+5dgts(45~500Hz) 600Vrms 600.00V 0.1V DC voltage: Range Resolution Accuracy Protection 60.00V 0.01V ±2%rdg+5dgts 600Vrms 600.00V 0.1V Resistance: Range Resolution Accuracy Protection 600.0 6.000K 0.001K 2%rdg+5dgts 600Vrms 60.00K 0.01K 600.0K 0.1K Continuity: Range Resolution...
Page 13 3. Specifications LoΩ: Range Resolution Accuracy 6.00 0.01 2%rdg+3dgts 60.0 Open circuit test voltage: > 4.0V, < 8V Short circuit current : > 200.0mA Live circuit detection: Inhibit test if terminal voltage > 2V prior to initialization of test. Insulation resistance measurement: Test Voltage Range Accuracy...
Page 14 3. Specifications Test voltage accuracy: 0% to +20% Test voltage vs. Maximum resistance range: 50V/1.00G , 100V/2.00G , 250V/5.0 , 500V/10.0G and 1000V/20.0G . Test voltage vs. Minimum resistance (with test current=1mA): 50V/50K , 100V/100K , 250V/250K , 500V/500K and 1000V/1M . Short circuit test current: 1mA(nominal) Live circuit detection:...
Page 15: Making Measurements
4. Making Measurements 4.1. Measuring Volts: Press the blue button to switch ACV or DCV measurement. Fig.1 4.2. Measuring Ohms / Continuity: Press the blue button to select the measuring function. Fig. 2 P.14...
Page 16: Measuring Low Resistance
4. Making Measurements 4.3. Measuring Low Resistance: The circuit under test must be completely de-energized. Check the fuse before testing. See Testing the fuse section later in this manual. Connecting the tester to an energized circuit while the test is active will blow the fuse.
Page 17: Measuring Insulation Resistance
4. Making Measurements 4.4. Measuring Insulation Resistance: The circuit under test must be completely de-energized before testing. Turn the rotary switch to the desired test voltage. Connect the probes to the circuit to be measured. The Tester automatically detects if the circuit is energized. If the detected voltage is above 30V, " > 30V "...
Page 18: Measuring Pi / Dar
4. Making Measurements 4.5. Measuring PI / DAR: Polarization Index (PI) is the ratio of the 10-minute insulation resistance to the 1 -minute insulation resistance. Dielectric Absorption Ratio (DAR) is the ratio of the 1-minute insulation resistance to the 30 second insulation resistance. Turn the rotary switch to the desired test voltage.
Page 19: Testing Fuse
5. Testing Fuse Warring! To avoid electrical shock or injury, remove the test leads and any input signals before replacing the fuse. Turn the rotary switch to the position. Press and hold . If the display reading is “ ”, the fuse is bad and should be replaced.
Page 20: Replacing Batteries & Fuse
6. Replacing Batteries & Fuse Warring! To avoid shock, injury, or damage to the Tester: To avoid false readings, which could lead to possible electric shock or • personal injury, replace the batteries as soon as the battery indicator “ ”appears.
Page 21: Maintenance & Cleaning
7. Maintenance & Cleaning Only quali ed personnel should perform repairs or servicing not covered in this manual. Periodically wipe the case with a dry cloth. Do not use abrasives or solvents onthese instruments. P.20...
