Power 8570970 Quick Start Manual

V4.0
4 IN. DECAL ERASER WHEEL
SPECIFICATIONS
Wheel Size 4 in.
Shank Size 1/4 in.
Max. Speed 4,000 RPM
Material Rubber
Colour Yellow
INTRODUCTION
The eraser wheel will remove viny decals or graphics, double-
sided tape, pinstripes and trim from acrylic enamel, chrome,
glass and metal surfaces.
SAFETY
WARNING! Read and understand all instructions before
using this tool. The operator must follow basic precautions
to reduce the risk of personal injury and/or damage to the
equipment.
Keep this manual for safety warnings, precautions, operating
or inspection and maintenance instructions.
1. Use the correct tool for the job. This tool was designed
for a specific function. Do not modify or alter this tool or
use it for an unintended purpose.
2. Operate in a safe work environment.
3. Control the tool, personal movement and the work
environment to avoid personal injury or damage to tool.
4. Do not operate any tool when tired or under the influence
of drugs, alcohol or medications.
5. Always wear impact safety goggles that provide front
and side protection for the eyes. Eye protection
equipment should comply with CSA Z94.3-07 or ANSI
Please read and understand all instructions before use. Retain this manual for future reference.
Z87.1 standards based on the type of work performed.
6. Wear protective clothing designed for the work
environment and tool.
7. Avoid wearing clothes or jewelry that can become
entangled with the moving parts of a tool. Keep long hair
covered or bound.
8. Do not overreach when operating a tool. Proper footing
and balance enable better control in unexpected
situations.
ASSEMBLY/INSTALLATION
CAUTION! Do not use with rotary tools that exceed 4,000
RPM, as excess speed can damage the underlying finish or
paint.
1. Screw the eraser wheel into the included mandrel.
2. Insert the mandrel into a drill chuck and tighten.
OPERATION
The eraser wheel will shed rubber as it is used, reducing the
wheel's diameter. There is a stop line incorporated into the wheel.
Replace the eraser wheel when you reach this line, as the internal
hardware may contact the work area if use continues.
1. Clean the decal and surrounding are to remove any
debris that can scratch the paint.
2. Set the drill between 1,500 to 3,000 RPM. Start with the
slower speed and only increase the rotation speed if the
wheel isn't removing the decal.
a. Older decal adhesives may be harder to remove.
3. Hold the drill sideways, so the wheel's curve is facing the
decal. Start the drill. Depending on which direction the
wheel is turning, start at either the top or bottom of the
decal or graphic.
4. Move the wheel against the decal with light pressure.
Heavy pressure can damage or burn the finish.
5. Move the wheel back-and-forth while moving vertically
from the starting position. Only do a few inches across
on larger graphics.
6. Take frequent breaks when working on a large decal or
graphic to allow the wheel to cool down. The wheel heats
up and that can damage the finish.
7. Use denatured alcohol or a similar solvent to remove the
glue residue after the decal is removed.
TROUBLESHOOTING
Visit a Princess Auto Ltd. location for a solution if the tool
does not function properly or parts are missing. If unable to
do so, have a qualified technician service the tool.
8570970
