ESS SABRE ES9028PRO Advance Information

Analog Reinvented
The SABRE ES9028PRO HyperStream
®
Audiophile and Studio equipment applications such as SACD players, Blu-ray players, digital preamplifier, A/V receivers,
studio consoles and digital audio workstations.
Part
Description
Number
SABRE PRO 32-bit 8-ch
®
ES9028PRO
HypersStream II Audio DAC
Using the critically acclaimed ESS' patented HyperStream
ES9028PRO 32-Bit Audio DAC delivers an unprecedented DNR of up to 135dB in mono mode and THD+N of –120dB, the
industry's highest performance level that will satisfy the needs of the most demanding audio applications.
The ES9028PRO handles up to 32-bit 768kHz PCM, DSD256 via DoP and native DSD1024 data in master or slave timing
modes. Custom sound signature is supported via a fully programmable FIR filter with 7 presets. Residual distortion from
suboptimal PCB components and layout can be minimized using ES9028PRO's unique THD compensation circuit, while
chip-to-chip gain variation is minimized via a built-in auto gain calibration circuit.
The SABRE ES9028PRO sets the standard for HD audio performance, SABRE SOUND
®
64-eTQFP package for today's most demanding digital-audio applications.
FEATURES
Patented 32-bit HyperStream
o Up to 135dB DNR (mono mode)
o –120dB THD+N
Patented Time Domain Jitter Eliminator
64-bit accumulator and 32-bit processing
Versatile Digital Input
Integrated DSP functions
Customizable output configuration
User Programmable Oversampling Filter
Clock Gearing
Gain Calibration ADC
THD compensation
Full 8-to-8 channel mapping
APPLICATIONS
Digital-Audio Workstations
Blu-ray / SACD players
ESS TECHNOLOGY, INC. 237 South Hillview Drive, Milpitas, CA 95035, USA. Tel (408) 643-8800 • Fax (408) 643-8801
CONFIDENTIAL ADVANCE INFORMATION
®
II 8-channel audio DAC is a high performance 32-bit solution designed for
Package
64
eTQFP
II DAC o Industry's highest performance 32-bit audio DAC with unprecedented
®
dynamic range and ultra-low distortion
o Supports both synchronous and asynchronous sampling modes
o Unmatched audio clarity free from input clock jitter
o Distortion-free signal processing
o Supports SPDIF, PCM (I
o Supports up to 768kHz PCM, DSD256 via DoP and native DSD1024
o Supports up to 1.536MHz external oversampling filter
o Supports master and slave timing modes
o Click-free, soft mute and output volume changes
o Programmable Zero detection
o De-emphasis for 32kHz, 44.1kHz, and 48kHz sampling
o Mono, stereo, or 8-channel output with either current-mode or voltage-mode
operation (current-mode gives lower THD)
o 7 ready-to-use preset filters with linear/minimum phase and low-delay options
o Supports custom coefficients for unique sound signature
o Supports external oversampling filter
o Reduces operating frequency for lower power consumption
o Enables uniform output level across all chips
o Minimizes distortion from external PCB components and layout
o Allows channels to be remapped for optimized PCB routing
Professional Audio Equipment
A/V Receivers
32-Bit HyperStream
DNR THD+N
(dB) (dB)
135 (mono)
–120
129 (8-Ch)
®
II architecture and Time Domain Jitter Eliminator, the
BENEFITS
S, LJ, RJ 16-32-bit), DoP or DSD input
2
ES9028PRO
8-Channel Audio DAC
2
32-bit I S / DoP / DSD
DAC / SPDIF Input
Yes Yes
®
, in a cost-effective, easy-to-use
II
®
Jitter
Reduction
Yes
