HOWARD MARSHALL ENGINEERING LTD.
OPERATOR'S MANUAL
HM-W0067
Bucket Grab
P000909
for use on the following John Deere Front Loader models:
H120, H130, H160, H165, H180, 200CX, 300CX, 400CX, 410, 420, 430, 460, 120R NSL,
120R MSL, 220R NSL, 220R MSL, 300E NSL, 300E MSL, 300R, 320R, 400E, 400R NSL,
440R MSL.
Howard Marshall Engineering Ltd.
"Solutions providers to the agricultural and groundcare industry"
Barracks Farm, Papplewick, Nottingham, NG15 8FG
Tel: +44 (0) 115 963 0011 Fax: +44 (0) 115 963 0022
sales@hme.co.uk
VAT No. GB59869153
Origional Language
HME reserve the right to change specification and design of products without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HM-W0067 and is the answer not in the manual?

Questions and answers

Related Manuals for HME HM-W0067

Summary of Contents for HME HM-W0067

  • Page 1 “Solutions providers to the agricultural and groundcare industry” Barracks Farm, Papplewick, Nottingham, NG15 8FG Tel: +44 (0) 115 963 0011 Fax: +44 (0) 115 963 0022 sales@hme.co.uk VAT No. GB59869153 Origional Language HME reserve the right to change specification and design of products without notice.

  • Page 2: Table Of Contents

    CONTENTS Notice Page 3 Safety Page 3 Overview Page 5 Safety Labels Page 5 Operating Instructions Page 6 Storage Page 7 Maintenance Page 8 Trouble-Shooting guide Page 9 Warranty Terms Page 10 EC Declaration of Conformity Page 11 UKCA Declaration of Conformity Page 12 APPENDIX A.

  • Page 3: Notice

    Please read through and understand the entire contents of the operator’s manual prior to using the implement. The information in this manual was correct at the date of print. Howard Marshall Engineering Ltd (HME) re- serve the right to change the specification of products as required without prior notice. Please contact HME if there are any aspects of the manual that you do not understand.
  • Page 4 Only use the attachment with the correct loader/attachment it was designed for. HME do not accept any dam- ages to bracket as a result of incorrect fitting or from the use of adapters or any home-made conversions.

  • Page 5: Overview

    Warning decals are fitted in different locations on the attachment. For decal locations, see general assembly. Do not cover or remove any of the decals. If a decal is missing or illegible replace it with a new decal. New warning decals are available from HME. Decals used on this unit are shown below. Page 5...

  • Page 6: Operating Instructions

    OPERATING INSTRUCTIONS Mounting of attachment Mounting of the equipment shall only be carried out a single operator. 1. Lower the loader frame to align mounting bars with the receivers; 2. Drive forward until the mounting bars are in the receivers; 3.

  • Page 7: Storage

    Handling of materials Handling of materials 1. Please refer to the loader and power unit user manuals on the operation of equipment controlling the attach- ment and to identify suitable Personal Protective Equipment (PPE); 2. Before commencing handling, ensure the load will fall centre of the attachment and overhang on both sides is minimised, where possible.

  • Page 8: Maintenance

    Dependent on size and location, it may be suitable to protect the steel with a steel zinc oxide primer as this will extend the service life of the equipment. If the paintwork has become degraded over years of use, HME offer a refurbishment service to repaint older products.

  • Page 9: Trouble-Shooting Guide

    3. Connect all hoses. Damaged components Improper operation. Spare parts are available for purchas from HME, please see appendix A for parts list. Attachment won’t tilt back 1. Load carried is too heavy; 1. Reduce the weight of the load;...

  • Page 10: Warranty Terms

    WARRANTY HME offer a 12 (twelve) month warranty on all products effective from the date of despatch from HME which covers against faulty materials and workmanship. The warranty is exclusively to the supplying agent. The warranty is on condition that the fault is reported immediately to the agent, and that the faulty component/ part is made available to the HME via the agent.

  • Page 11: Ec Declaration Of Conformity

    EC DECLERATION OF CONFORMITY In accordance with BS EN ISO/IEC 17050-1:2010 Howard Marshall Engineering Ltd. Barracks Farm, Papplewick Nottingham, NG15 8FG United Kingdom Tel + 44 (0) 115 963 0011 In accordance with the following directive(s): 1. of May 17, “relating to machinery” 2006/42/EC Hereby certifies that;...

  • Page 12: Ukca Declaration Of Conformity

    UKCA DECLERATION OF CONFORMITY In accordance with BS EN ISO/IEC 17050-1:2010 Howard Marshall Engineering Ltd. Barracks Farm, Papplewick Nottingham, NG15 8FG United Kingdom Tel + 44 (0) 115 963 0011 In accordance with the following directive(s): 1. Supply of Machinery (Safety) Regulations 2008; 2.
  • Page 13 This page is deliberately left blank. Page 13...
  • Page 14 Howard Marshall Engineering Ltd. Barracks Farm, Papplewick, Nottingham, NG15 8FG Tel: +44 (0) 115 963 0011 Fax: +44 (0) 115 963 0022 sales@hme.co.uk HME reserve the right to change specification and design of products without notice.
