Summary of Contents for TEHMA PP700-E
- Page 1 SAFETY MANUAL USE AND MAINTENANCE PP700-E/S HIGH PRESSURE HYDRAULIC POWER PACK IMPORTANT READ THIS MANUAL BEFORE USING THE TOOL TRANSLATION OF THE ORIGINAL VERSION KEEP ALWAYS FOR FUTURE REFERENCES Rev. 3 3/2020...
-
Page 2: Table Of Contents
CONTENTS OF THE MANUAL Page • INTRODUCTION • SAFETY SYMBOLS • PRODUCT DESCRIPTION Description Typical applications Accessories Sound power level • TECHNICAL CHARACTERISTICS General view – main components and their functions View of the control block Weight and dimension Hydraulic oil Flexible hose Quick couplers and use •... -
Page 3: Introduction
THE POWER PACK ARE COMPATIBLE WITH THOSE ONE OF THE POWER PACK ITSELF. NOTE – THE TEXT AND THE ILLUSTRATIONS IN THIS MANUAL ARE AN EXCLUSIVE PROPERTY OF TEHMA SA. THE PERSON WHO USES THE TEXT OR REPRODUCES, EVEN PARTIALLY, ILLUSTRATIONS OR PARAGRAPHS FOR NON- AUTHORISED PURPOSES CAN BE LEGALLY LIABLE. -
Page 4: Safety Symbols
This symbol indicates important information WHEN THE EFFECTS OF A CERTAIN ACTION ARE NOT EXACTLY KNOWN, REMIND THAT EVEN THE SIMPLEST OPERATION MAY HIDE DANGERS. IN CASE OF DOUBTS DO NOT RISK – DO NOT MAKE EXPERIMENTS! ASK YOUR TEHMA DEALER OR YOUR FOREMAN. -
Page 5: Product Description
PRODUCT DESCRIPTION PP700 is a high-pressure hydraulic power pack that can be powered by a 2,2-kW electric motor 230V/110V (PP700-E) or by a 3,6-kW petrol engine (PP700-S). The machine has been engineered to power high pressure tools or hydraulic cylinders, the hydraulic pressure can reach 700 bar and can be easily reduced or adjusted by using the relief valve integrated with the machine. -
Page 6: Technical Characteristics
NOTE: The regulation screws of both valves 4-5 must be secured by the locknut to prevent from get lost due to vibration and consequently change the pressure regulations. The "MAX PRESSURE" and "CUT-OFF" valves have been adjusted by TEHMA to the maximum working pressure that can be accepted by its tools. -
Page 7: View Of The Control Block
VIEW OF THE CONTROL VALVE BLOCK Fig. 2 THE VALVE PLATE is the group that includes all hydraulic control components, the part is obtained working two laminated aluminium blocks. 1 - OIL FILTER for hydraulic circuit 2 - PRESSURE GAUGE is positioned in the center for reading the pressure. 3 - ON/OFF FLOW LEVER is the lever that controls the distribution valve that delivers oil to tools , the central position in the illustration is the OFF position where the tools are still , the lever must be put in this position before start and put off motor. -
Page 8: Weight And Dimension
PP700-E/S HIGH PRESSURE POWER PACK TECHNICAL CHARACTERISTICS WEIGHT AND DIMENSION WEIGHT ( dry ) Kg 59 (E) / 57.5 (S) HEIGHT 49.5 LENGTH WIDTH 42.5 HYDRAULIC CHARACTERISTICS PRESSURE min max 210 - 700 bar TEHMA PRESSURE IS REGULATED BY FOR ITS HYDRAULIC TOOLS... -
Page 9: Hydraulic Oil
( cSt = centistokes ° E = Engler degrees ) HYDRAULIC OILS CORRESPONDENCE CHART TEHMA The following chart indicates the most common hydraulic oils recommended for hydraulic tools and power packs. The oils in the chart are suggested for standard temperatures; the left column indicates oils for Winter operations;... -
Page 10: Flexible Hose
TO ALLWAYS PUT THE PROTECTION ON THE COUPLERS AFTER USE. FEMALE QUICK COUPLER MALE QUICK COUPLER CEJN code 101151404 CEJN Code 101156404 TEHMA TEHMA code A161103 code A161104 TEHMA high pressure power packs and hydraulic tools are equipped with quick couplers made by CEJN... - Page 11 USE OF THE QUICK COUPLERS CONNECTION • Make sure that the contact surfaces of the couplers are clean and if necessary with a rag. • Position the male coupler towards the female one, centring them. • While pulling back the female knurled external bush press the male coupler against the female one. Release the female bush and a “click”...
-
Page 12: Safety Rules
SAFETY RULES GENERAL SAFETY INSTRUCTIONS MAKE SURE THAT THE TOOL OR CYLINDER YOU ARE ACTIVATING FROM THE PP700 IS RATED TO RESIST TO A PRESSURE OF 700 Bar OR TO THE PRESSURE YOU HAVE REGULATED FROM THE PACK THE FOLLOWING INSTRUCTIONS ARE GENERAL SAFETY RULES AND HAVE TO BE RESPECTED IN EVERY WORKS WITH POWER PACKS AND TOOLS. - Page 13 THE "MAXIMUM PRESSURE" AND "CUT-OFF" VALVES POSITIONED ON THE SIDE OF THE UNIT HAVE BEEN ADJUSTED BY TEHMA TO THE MAXIMUM WORKING PRESSURE THAT CAN BE ACCEPTED BY ITS TOOLS. MODIFYING THE CALIBRATION OF THESE VALVES CAN POSE SERIOUS RISKS FOR THE...
-
Page 14: What Not To Do
USE OF THE POWER PACK WHAT NOT TO DO THE FOLLOWING LIST IS GIVEN FOR DESCRIBING THE MORE COMMON ERRORS OR IMPROPER AND DANGEROUS USE OF THE POWER PACKS. SINCE IT IS IMPOSSIBLE TO FORESEE ANY DANGEROUS SITUATIONS, THE RULES ARE NOT SUFFICIENT TO GUARANTEE THE TOTAL SAFETY. -
Page 15: Before Working
4. CHECK THAT THE TOOL USED AND THE POWER PACK HAVE COMPATIBLE HYDRAULIC CHARACTERISTICS – IN CASE OF DOUBT DO NOT RISK but ask your TEHMA dealer or your foreman. 5. CLEAN THE POWER PACK PROPERLY if it is dirty, in particular clean the cooler eliminating mud or dirt, use compressed air if necessary ( see chapter ”... -
Page 16: Start And Use Or The Power Pack
START AND USE COLD START THE POWER PACK SHOULD BE PROTECTED FROM BAD WEATHER AND TOO HARD CLIMATES. THE ENGINE COULD BE QUICKLY DAMAGED IF THE MACHINE IS LEFT EXPOSED TO RAIN AND LOW TEMPERATURES WITHOUT PROTECTION. WHEN THE MACHINE IS NOT USED, IT SHOULD BE STORED IN A DRY AND WARM PLACE REPAIRED FROM RAIN AND DAMPNESS. -
Page 17: End Of Operations
valve or trigger is free and released in its OFF to avoid unwanted activation; control that the return spring of the tool trigger is operative and efficient for avoiding an accidental starting. 3. Connect the flexible hoses to the power pack ( engine and flow control lever must be OFF)..and to the tool 4. -
Page 18: Maintenance And Care
The pressure gauge located on the valve top always indicates the pressure used or reached by the tool during its use. The "MAX PRESSURE" and "CUT-OFF" valves have been adjusted by TEHMA to the maximum working pressure that can be accepted by its tools. -
Page 19: Power Pack Cleaning
8. Try rotating the central distribution lever in the central position and then again on the previous channel to check the correct adjustment of the "CUT-OFF" valve. NOTE: a correct calibration implies that the pressure rises rapidly from 0 to the previously set pressure and once this limit is reached, it drops again to 50-100 bar. -
Page 20: Periodical Controls And Substitution Of Wear Out Parts
PERIODIC CONTROLS AND SUBSTITUTION OF WORN PARTS • EVERY TIME THE EQUIPMENT IS USED: 1. Control the hydraulic oil level 2. Control the level of the engine oil (or make the proper maintenance as specified in the manual of the engine manufacturer). 3. -
Page 21: Maintenance Of The Flexible Hose
MAINTENANCE OF THE FLEXIBLE HOSE INSPECTION OF THE HOSE • Lay the flexible hoses on the floor and control if there are oil leaks and the hose surfaces are integral without peeled sections showing metallic braid with broken wires. • the presence of little sections of wire braid can be tolerated only if the wires are not broken and still braided. -
Page 22: Repair
At the end of their life, all components of the machine must be separated and disposed of in compliance with the laws in force in your country. Except for the liquids and materials of the previous list, the other components of the products TEHMA manufactured by are fabricated with recyclable materials that can be stored, disposed and scrapped without particular cautions. -
Page 23: Problem / Cause / Solution Chart
Add fuel Low engine oil level Add oil engine Low engine oil level Add oil engine (PP600 – S) If the problem persists, contact the authorized dealer or TEHMA PROBLEM: THE HYDRAULIC TOOL HAS POOR PERFORMANCES CAUSE SOLUTION Damaged tool... - Page 24 Damaged quick couplers Check/substitute the quick couplers Overheated hydraulic oil Check the oil level Substitute with oil suitable to the season If the problem persists, contact the authorized dealer or TEHMA PROBLEM: THE TOOL OVERHEATS QUICKLY CAUSE SOLUTION Hydraulic oil low level...
-
Page 25: Warranty
FOR ANY CONTROVERSY, THE COMPETENT COURT IS IN LUGANO-SWITZERLAND. Manufacturer and European authorised representative (E.A.R.) Manufacturer: European authorized representative (E.A.R.): TEHMA SA Virgilio Tentori Srl Vicolo Concordia 1, 6932 Via Belfiore 31/D, 23900 Lugano - Breganzona, Switzerland Lecco, Italy... -
Page 26: Label
LABEL FAC-SIMILE EU DECLARATION OF CONFORMITY...
