SPF12-200
LITHIUM BATTERY
USER MANUAL
���AH
12.8V 50AH
Thank you very much for choosing ACDC lithium ion battery! In order to help you use, store and maintain the lithium battery of our
company, please read and understand this user manual carefully before use
1. BASIC INTRODUCTION
BATTERY SPECIFICATION
Code
Nominal voltage ( V)
Nominal capacity ( Ah)
Charging mode
Charging voltage ( V)
Maximum charging current (A)
Maximum discharge current (A)
Size(mm)
Recommended discharge
cut off voltage
National Sales Centre - 010 202 3400 | Technical - 010 202 3500
Red(+)
SPF12-200
12.8V
200Ah
CC/CV (Lithium ion battery specialized charger)
14.4V
100A
100A
522*240*218mm
11.2V
www.acdc.co.za
Black(-)
Environmental conditions
1.Charging temperature range : 0˚C~45˚C
2.Discharge temperature range : -20˚C~50˚C
3.Storage temperature range : -10˚C~45˚C
4.Relative humidity : 5%-90%
T H I N K
www.acdc.co.za
E L E C T R I C A L

Advertisement

loading
Need help?

Need help?

Do you have a question about the SPF12-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for ACDC Dynamics SPF12-200

  • Page 1 SPF12-200 LITHIUM BATTERY USER MANUAL ���AH www.acdc.co.za 12.8V 50AH Thank you very much for choosing ACDC lithium ion battery! In order to help you use, store and maintain the lithium battery of our company, please read and understand this user manual carefully before use...
  • Page 2 SPF12-200 CHARGE 1. The battery pack must be charged with a specialized charger for lithium battery. When charging the battery, make sure that the power supply voltage is consistent with the input voltage of the charger, and the output voltage of the charger is consistent with the battery’s charging voltage.
  • Page 3 SPF12-200 3. TRANSPORTATION AND STORAGE Transportation: 1. Battery transportation temperature: 20 ~ 30˚C. 2. Batteries shall be packed in boxes for transportation, and vehicles such as cars, trains and cabins can be used. 3. During transportation, the battery shall not be subject to severe vibration, impact, exposure to moisture, inversion and heavy pressures;...
  • Page 4 SPF12-200 6. MAINTENANCE AND AFTER SALES 1.According to the relevant laws and regulations of the state, the company carries out warranty for the products normally sold. 2.When your battery needs to be repaired, please bring the purchase battery invoice and this warranty card to our company or the dealer's designated after-sales service station for repair.
