Y-cam YPARE01 Manual

1.Brief
YPARE01 is mini wireless remote controller with 4 keys;
it is one of important accession of our company and has
the function of controlling the wireless products.With special
outlook,it can be decoration and convenient for taking.It
is easy for using,has high sensibility in 120 meters.After
coding with wireless products,it controls wireless products.
Emergency bottom key for you to send out emergency
immediately.For better protection of your security,it is good
choice for your smart home system.
2.Specification
Model number: YPARE01
Using range: 120m( in the open place)
Frequency: 433MHz
Working voltage: 3V (1*CR2450 button battery)
Quiescent current: ≤1μA
Working current: ≤15mA
Prompt: The LED light is red when transmitting.
Working environment: -10℃-60℃(14℉-140℉)
4.Using
Away
1.For away arm,press the key
AWAY for 2 seconds.
5.Coding
A. Make YPARE01 enter the working mode,press any button on the remote control to send wireless signal,at the
moment the panel will automatically learn the code of the remote control,then click save.
B. The user can also manually enter the address code directly,so the probability of error will be smaller.For example,
you set the panel on manually adding mode of remote control,then enter the 9-digit address code on the remote control
label.
P/N:20170427A01
YPARE01

3. Main function

A.4 independent function keys
B.For fast arm/disarm,easy and convenient,emergency
C.Scientific address code with millions of combination,
E.Low consumption for transmitting,indication for signal
F.Compatible with all our 433MHz wireless products.
Home
2.For at home arm,press the key
HOME for 2 seconds.
— 1 —
Away
call,safe and covert.
which enable all the remote controller to be exclusive
one,without permitting,it is impossible to copy our
wireless products.
output visible.
3.For disarm, press the key
DISARM for 2 seconds.
LED indicator
Disarm
Home
Disarm
