Summary of Contents for Papenmeier RehaTechnik VISULEX Maki
- Page 1 USER MANUAL VISULEX Maki Version: 1.1.1 | Status: 07.2023...
-
Page 2: Table Of Contents
Table of contents General notes ........................... 6 Copyright ............................6 Other authors/sources ........................6 Abbreviations ..........................6 Purpose ............................6 Safety instructions ......................... 7 General precautions ........................8 Cleaning ............................8 Packing and transport ........................9 Introduction ............................. 10 Structure of the VISULEX Maki ....................... 10 Structure of the device ........................ - Page 3 Key 6 - Set 1 ..........................16 Key 7 - Set 2 ..........................17 Key 8 - Image parameters ......................17 True colors ..........................17 False colors ..........................17 Key 8 - Toggle (optional) ......................17 Standby modes ..........................17 Start parameter ..........................
- Page 4 Warranty (only valid within Germany) ..................28 Disposal ............................28 Repair and maintenance ......................29...
- Page 5 This user manual applies to the VISULEX Maki document reading camera. Manufacturer: F.H. Papenmeier GmbH & Co. KG Talweg 2 D-58239 Schwerte / Germany www.papenmeier-rehatechnik.de All technical data, information and properties of the product described in this work have been compiled to the best of our knowledge and correspond to the status at the time of publication.
-
Page 6: General Notes
All contents of these operating instructions, in particular texts, photographs and graphics, are protected by copyright. The copyright is owned by the company F.H. Papenmeier GmbH & Co. KG, unless expressly indicated otherwise. Please contact us if you wish to use the contents of this work. -
Page 7: Safety Instructions
The expected lifetime of the medical device is 7 years. In order to achieve the expected service life of the product, complete professional cleaning by Papenmeier Technical Service is recommended at intervals of no more than 2 years. This service is subject to a charge. -
Page 8: General Precautions
The ambient temperature should be between +10°C and +40°C and the humidity between • 20% and 80%. • Avoid locations where rapid or extreme changes in temperature or humidity may occur. Do not use the device near liquids or corrosive chemicals. •... -
Page 9: Packing And Transport
Never use harsh cleaners or soap. Packing and transport To avoid damage, remove all cables from the product before transporting it. Use the device bag to transport mobile devices. The original packaging must be used to ship the product. -
Page 10: Introduction
Introduction Congratulations on the purchase of your VISULEX Maki. The VISULEX Maki offers a razor-sharp and smooth image. This is achieved by the Full HD resolution with 60 frames per second. Smallest fonts can be easily displayed legibly with the optical 30x zoom. -
Page 11: Camera Movement
Now your VISULEX Maki is ready for use and can be switched on. Camera movement The camera arm is fixed to the stand and cannot be rotated. The camera head can be rotated 110 degrees to the right, left, front and back. Each direction has a stop. -
Page 12: Operation
Operation Operating unit The operating unit consists of a rotary control with pushbutton and eight keys. The keys are described clockwise in this manual. Operating concept Pressing a key briefly performs a direct function. Long pressing of a key enables in most cases the setting of a value with the help of the rotary control. -
Page 13: Zoom
The process is aborted if no further change or confirmation is made within 15 seconds. Furthermore, the process is canceled by pressing any key. This restores the old values. Optional signal tones can be heard. However, these are deactivated by default. Zoom In the basic function, you can control the zoom (magnification) with the rotary control. -
Page 14: False Colors / False Colors Inverse
False colors / false colors inverse: If false colors are selected and you press the 1 key for a long time, the false color combination can be selected. You can use the rotary control to set the optimum false color combination to suit your needs. -
Page 15: Step Four
Pressing the rotary control confirms the position and takes you to the next step. Step four: In the final step, the color of the lines or curtains can be selected. To do this, turn the knob to the right or to the left. Press the control knob to confirm the selected color of the lines or curtains and finish the setting procedure. -
Page 16: Focus
At minimum zoom, the crosshairs point to the area that was last magnified. This will make it easier for you to find your way around the document. You have two options for this: 1. Realign your document using the crosshairs. Press the 4 key again or optionally the control knob. -
Page 17: Key 7 - Set 2
Key 7 - Set 2 Press the 7 key briefly to load the saved settings of set 2. If you press the 7 key for a long time, the current settings are saved in Set 2. Key 8 - Image parameters If you press the 8 key for a long time, various image parameters can be changed depending on the selected color display. -
Page 18: Start Parameter
The second standby mode is independent of the first and can also not be configured. If there is no operation on the device for 30 minutes, this standby mode becomes active. You can exit this standby mode by pressing a key or turning the rotary control. Start parameter The VISULEX Maki loads the parameters stored in Set 1 at startup, but not all parameters are activated. -
Page 19: The On-Screen Menu
The on-screen menu You can set system parameters using the on-screen menu. To activate the on-screen menu, press keys 3, 4, 5 and 6 simultaneously for three seconds. The following menu appears: The color of the menu depends on the selected false color combination. You move up and down in the menu as follows, using the rotary control: •... -
Page 20: Factory Settings
Factory settings The following line can be seen on the on-screen menu: Use the rotary control to select <YES> and confirm by pressing the rotary control. All values are reset to factory settings. Note: The saved sets will also be lost. You will return to the previous menu. -
Page 21: Signal Tones
Signal tones The following line can be seen on the on-screen menu: You can use the rotary control to switch the signal tones on or off. If you have deactivated the signal tones, you will no longer receive any acoustic feedback. Confirm your selection by pressing the rotary control. -
Page 22: Info
Info This menu provides you with information about your VISULEX Maki. Among other things, you will find the version number, which you should have ready in case of a service case. -
Page 23: Pc Software
PC Software Installation Install the program on your Windows system following the instructions of the installation wizard. Connect the mini-USB port on the camera arm of the VISULEX Maki to your computer. Use a free USB interface and start the program. To use the PC software, the control unit must be connected to the camera Please note: arm! -
Page 24: Lines And Curtains
True colors • Grayscale • False colors • • False colors inverse After false colors are inverted, the process starts again with true colors. Alternatively, you can control the color modes using the hotkeys. If you right-click on the button, a context menu opens in which you can explicitly select a color mode. -
Page 25: Mirror
Mirror Press the button to flip the image horizontally. This is necessary in panel camera mode when you pan the camera head away from the arm, i.e. towards you. Alternatively, you can also control mirroring using the hotkeys. Set 1 and Set 2 Press one of the buttons to load the saved settings of the respective set. - Page 26 Error: The combination could not be activated, regardless of whether it is a custom • combination or the default combination. You can change the combinations of hotkeys at any time to suit your needs. Select the corresponding hotkey from the list and simply assign a new key to it or change the combination of the Shift, Ctrl, Alt or Windows keys.
-
Page 27: Appendix
Appendix Scope of delivery Camera arm RS#0174.004.00 • Stand, base plate RS#1426.001.00 • Operating device RS#1701.006.00 • Netzgerät (90-264VAC/12VDC/40W) R#1706.000003 • Connecting cable, black R3403.039.00 • Cable, HDMI male to DVI male, 2m R#3490.000064 • • 2x Housing foot, self-adhesive, H=5,1mm R#1422.000025 2x Housing foot, self-adhesive, H=7,6mm R#1422.000029... -
Page 28: Weight
Any warranty shall become void in the event of improper use or improper handling. Warranty (only valid within Germany) Papenmeier warrants for a period of 36 months from the date of receipt that all components will operate substantially as described in the accompanying user manual. - Page 29 Stiftung Elektro-Altgeräte Register, Benno-Strauß-Str. 1, 90763 Fürth as a manufacturer of electrical and/or electronic equipment. Repair and maintenance Repairs and maintenance may only be carried out by F.H. Papenmeier GmbH & Co. KG or by authorized companies.
