Summary of Contents for Dyness Junior Box
- Page 1 Junior Box USER MANUAL Balcony Solar System File version-20231108-V1-EN Information might be subject to change without notice during product improving.
-
Page 2: What's In The Box
What's in the Box Dyness Junior Box MC4 DC Output Cable(3m) ×2 User Manual Overview Product Overview LEFT FRONT RIGHT BOTTOM ©Dyness reserves the copyright of this document... -
Page 3: Button Controls
Press for 3 seconds Turn Junior Box on Press for 3 seconds Turn Junior Box off Getting Started Install Your Junior Box Option A: Position your Junior Box on a hard, level floor. ©Dyness reserves the copyright of this document... -
Page 4: Connect Cables
Option B: Mount your Junior Box onto a solid concrete wall using additional mount brackets*. *Mount brackets need to be purchased separately Connect Cables Single Junior Box 1. Connect Junior Box to the micro inverter using the included MC4 output cables. - Page 5 MC4 DC Output Cable Solar Panel Extension Cable 4. Press the power button for 3 seconds to turn on your Junior Box. When powered on, the BMS status LED will display blue . Blue light ©Dyness reserves the copyright of this document...
- Page 6 Extended Junior Box Junior Box supports up to 3 stack expansions (Extended Battery)* with a capacity of 6.4KWh 1. Install the stack connector* on the battery expansion port on the top of the bottomExtended Battery , and stack the Junior Box on the bottom module.
- Page 7 MC4 DC Output Cable (3m) Solar Panel Extension Cable No need to install MPPT module 5. Press the power button for 3 seconds to turn on your Junior Box. When powered on, the BMS status LED will display blue . Blue light *Note: 1.
-
Page 8: Storage And Maintenance
Dyness Smart ESS App for Smart Control Download the Dyness Smart ESS App to get full functionality of your Junior Box from the App Store (iOS devices) or Scan QR Code(Android devices). WIFI distribution network, use Dyness smart ESS app to scan the QR code in the Wi-Fi Logger label... - Page 9 For long-term storage, charge and discharge Junior Box once every 3 months (discharge Junior Box to 20%, then recharge it to 80%). If the BMS fails, it can be removed and replaced with a new BMS, as shown in the following ...
-
Page 10: Specifications
≥8000 Cycles Warranty 10 Years BASIC Charging Temp. Range 0 °C to 55 °C Discharging Temp. Range -20 °C to 55 °C Communication RS485 Max.PV Input Power（W） 1200W Max. Input Voltage（V） MPPT Range(V) 18-60V ©Dyness reserves the copyright of this document... -
Page 11: Safety Information
12. Before you pull out the AC (or battery) connector from the microinverter, disconnect the cable from the AC socket (or battery's) end. 13. Do not clean the product with harmful chemicals or detergents. ©Dyness reserves the copyright of this document... -
Page 12: Environment Requirements
3. Do not expose the equipment to strong electromagnetic fields to avoid radio interference. Customer Service Email：sales@dyness-tech.com Tel：+86 400 666 0655 Web：www.dyness.com For more details, please scan the QR code or visit: https://www.dyness.com/qa Or scan the QR code below: ©Dyness reserves the copyright of this document... - Page 13 Address: No. 511 Chenzhuang West Road, Sanshui Street, Jiangyan District, Taizhou City Email: service@dyness-tech.com Tel: +86 400 666 0655 Web: www.dyness.com Official Website Digital version access...
