Product Name:
White Wood 8-Pair Shoe Storage Bench
SKU #:
WHIF898
Thank you for purchasing this Luxen Home product. This product has been manufactured with the highest
standards of safety and quality.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Unpack all parts from Styrofoam and bubble wrap inside the carton to ensure there are no missing or damaged
parts. If any parts are missing or damaged, do not attempt to assemble or use the product.
Tools required for assembly: Screwdriver, flat head screwdriver, hammer, and measuring tape.
CARTON CONTENTS:
Ø6x35 mm
Ø15x12 mm
Ø4x30 mm
Ø3x12 mm
Contact: cs@winsomehouse.com
Please save this manual for future reference.
Ø4x12 mm
Instruction Manual
Advertisement
Related Manuals for LuxenHome WHIF898
Summary of Contents for LuxenHome WHIF898
- Page 1 Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Thank you for purchasing this Luxen Home product. This product has been manufactured with the highest standards of safety and quality. PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
- Page 2 Instruction Manual Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 PANEL CONTENTS: Contact: cs@winsomehouse.com...
- Page 3 Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Assembly Instructions: Step 1 Make sure the pins are installed correctly as shown with the “check mark” below: Below shows how the pins are used to assemble the panels together.
- Page 4 Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Step 2 With panels (1, 5, 6, 7), insert and screw in A. Insert C to inner top hole of panels. Ø6x30 mm Step 3 Align panels 7 and 1.
- Page 5 Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Step 4 With panel 4, align and insert panel 1. Screw in B to lock in place. Step 5 Insert panels 6 and 5 to panel 4. Screw in B to lock in place.
- Page 6 Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Step 6 Slide in panels 8 in each slot. Step 7 Insert panel 3 to panels (1, 5, 6). Screw in B to lock in place.
- Page 7 Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Step 8 Insert panel 2 to panels (1, 5, 6). Screw in B to lock in place. Step 9 Align I and J each to panel 9 and panel 12. Secure I and J to each panel by screwing in K.
- Page 8 Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Step 10 Align panels (10 and 11) to I and J for each assembly (9 and 12) and screw in L. L x8 Ø3x12 mm...
- Page 9 Instruction Manual Please save this manual for future reference. Product Name: White Wood 8-Pair Shoe Storage Bench SKU #: WHIF898 Step 12 Align panels (11) to I and J and screw in L. L x4 Ø3x12 mm Step 13 Place cushion on cabinet.
