INSTALLATION AND OPERATION MANUAL

WARNING: If the information in this

manual is not followed exactly, a

fire or explosion may result causing

property damage, personal injury,

or loss of life.

FOR YOUR SAFETY: Do not store

or use gasoline or other flammable

vapors and liquids in the vicinity of

this or any other appliance.

INSTALLER: Leave this manual with appliance. CONSUMER: Retain this manual for future reference.

Certified to the Canadian and American National Standards: CSA 2.26 and ANSI Z21.60 for decorative gas appliances for installation in solid-Fuel burning fireplaces.

3515 East Atlanta Avenue, Phoenix, Arizona 85040 | 602-344-4217 | grandcanyongaslogs.com

2 burner / 3 burner

2 Burner w/ Millivolt

WHAT TO DO IF YOU SMELL GAS

– Installation and service must be performed by a

Report # F23-191

FOR INDOOR OR OUTDOOR PATIO USE

Grand Canyon Gas Logs

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any

phone in your building.

• Immediately call your gas supplier from a neighbor's

phone. Follow the gas supplier's instructions.

• If you cannot reach your gas supplier,

call the fire department.

qualified installer, service agency, or the gas suppli

3 Burner w/ Battery Electronic

er.

082023_V1
