Summary of Contents for Nortrac QHXG
- Page 1 QUICK HITCH QHXG OPERATIONS & PARTS MANUAL FOR MODELS: • QS1SC • QH1N • QH1GI • QH2G • QH2HDG • QH2-3G • QH3NG • QH3G PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
- Page 3 If there is any doubt, do not operate the tool. 14. Maintenance. For your safety, service and maintenance should be performed regularly by a qualified technician. QHXG USER MANUAL...
- Page 4 For this reason, use stabilizer chains, or some other common longer Mounting Pin (not provided) to fasten the Quick Hitch to the tractor. Latch Handle Top Bracket Latch Handle Top Hook Lynch Pin (3) Locking Clip (4) Lynch Pin (3) Lower Hooks QHXG USER MANUAL...
- Page 5 For most implements, the front hole (closest to implement) is recommended for the best vertical alignment. 3. Attach the implement to the Adapter Bracket tab with a Link Pin (not provided) 4. Check that all connections are tight before starting the work task. QHXG USER MANUAL...
- Page 6 Never use the Quick Hitch or attached implement if damaged or worn parts are noted. QUICK HITCH PARTS LIST DESCRIPTION Main Frame Weldment Bolt M12x65 Lynch Pin Hair Pin Hook (QH1G only) Nut M12 Lock Washer 12 Top Link Pin QHXG USER MANUAL...
- Page 7 QHXG USER MANUAL...
- Page 8 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 QHXG USER MANUAL...
