Qualitrol 509ITM Series Manual

Intelligent transformer monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QUALITROL
QUALITROL
QUALITROL
QUALITROL
Intelligent Transformer Monitor
Hardware and Software Instructions
Document ID: IST-099-1 ECN-43847
509ITM Series
509ITM-100
509ITM-200
509ITM-300
www.qualitrolcorp.com

Advertisement

Table of Contents
loading

Related Manuals for Qualitrol 509ITM Series

Summary of Contents for Qualitrol 509ITM Series

  • Page 1 QUALITROL 509ITM Series  QUALITROL 509ITM-100  QUALITROL 509ITM-200  QUALITROL 509ITM-300  Intelligent Transformer Monitor Hardware and Software Instructions Document ID: IST-099-1 ECN-43847 www.qualitrolcorp.com...
  • Page 2 Operation outside of the intended use shall not be the responsibility of Qualitrol. Information in this document is subject to change without notice. This document is provided to purchasers of Qualitrol products for use in the installation, operation and servicing of such products. No other use, nor any reproduction, distribution or the making of any derivatives of this document is authorized, without the express prior written permission of Qualitrol.

  • Page 3: Table Of Contents

    Hardware Instructions ..................8 Overview ........................8 QUALITROL 509 Series Intelligent Transformer Monitor ..........8  About Qualitrol ..............Error! Bookmark not defined. About These Hardware Instructions ................9 Controls, Indicators, and Modules ................ 10 Front Panel ........................10 Modules ........................11 RTD Input Module ....................
  • Page 4 509ITM Hardware and Software Instructions Output Contacts ......................28 Remote Output Signals ....................29 Communications ......................30 Operation ........................ 31 Automatic Operation ..................... 31 Viewing Channels or Viewing Mode Scrolling ............31 MENU Mode ......................31 Program Mode ......................34 Cooling System Monitor (509ITM-200) ..............
  • Page 5 509ITM Hardware and Software Instructions Front USB - Service Port ..................59 Main 485 - Main Port ....................60 Aux 485 - Auxiliary Port................... 61 Ethernet - Port ......................63 Cancel and Load Buttons ..................63 Input Modules ....................... 65 Module ........................
  • Page 6 509ITM Hardware and Software Instructions Event Trigger ......................107 Cooling System Monitor (509ITM-200) ............... 108 Cooling Bank Setup ....................110 Setup ......................111 Running Bank Current ..................113 Starting Motor Current Value ................114 Number of Actuations ..................115 Run Time ......................115 Flow Gauge .....................
  • Page 7 509ITM Hardware and Software Instructions View LTC Values ......................132 509ITM – DW with Direct Winding ..........134 QUALITROL ® System Overview ......................134 Components ....................... 134 System Setup ......................135 Using an optical hot spot module with an analog connection ........ 135 Using an optical hot spot module with a digital connection ........

  • Page 8: Hardware Instructions

    Hardware Instructions Overview QUALITROL 509 Series Intelligent Transformer Monitor  The QUALITROL 509 Series Intelligent Transformer Monitor (509ITM) for Liquid-Filled  Transformers offers microprocessor technology and advanced digital signal processing to accurately assess the health and performance of oil-filled transformers.

  • Page 9: About These Hardware Instructions

    The 509ITM offers: • Advanced thermal modeling of winding temperatures • Superior temperature control for higher loads • Integrated Load Tap Changer (LTC) temperature monitoring • Standalone or networked substation monitoring • Diagnostic tools for condition based maintenance • Eight, Form C programmable relays to operate cooling equipment, signal alarms, and provide trip functions, depending on transformer conditions •...

  • Page 10: Controls, Indicators, And Modules

    SET POINT INDICATORS - A red LED illuminates to indicate that the set point for the relay, indicated on the overlay, has been exceeded. RS-232 / USB PORT - When used with the Qualitrol software, this port allows for the setup of all of the parameters of the monitor. See the...

  • Page 11: Modules

    LTCs, or fan currents. The input to the module is a clamp on the CT, provided by Qualitrol, which has an input range of 0 - 5 A, 0 - 10 A, or 0 - 20 A, other ranges are available, and an output of 0 - 0.333 VAC, can be used as the input to the CT Input Module.

  • Page 12: Tap Position Input Module (509Itm-300)

    The input to the module is a potentiometer that is typically supplied by Qualitrol. The range of the potentiometer input is up to 15,000 ohm. Typically, the 25° mark on a liquid level dial is set to the center of the potentiometer range, and the high and low readings are simply ratios of the angular deflections from the normal setting.

  • Page 13: Powered Contact Closure Module

    a closed contact signifies a shorted connection across the contacts. This can be used, for example, to monitor pumps or fans. The system internally treats closed and opened contacts as either a 0 or 100 numeric value. Therefore, if the module is used to control a relay, the relay set point should be set at midrange, e.g., 50.

  • Page 14: Installation

    Installation Location and Mounting Installing the Hardware 1. Unpack the 509ITM. 2. Check that all of the materials on the packing slip are included. 3. Make four holes on the transformer panel for installation of the monitor. Important: • Note the mounting differences between the enclosure style and the panel-only style. •...
  • Page 15 Installing power outside of the recommended input range will damage the unit. 10. Energize the 509ITM. The monitor briefly displays “Qualitrol” and the version of the board firmware. Important: The following operation can cause the alarm output state to change.
  • Page 16 found on the documentation CD-ROM, to view, change, or modify the settings of the 509ITM to meet your requirements. Warning • Switch off the power supply before performing installation or maintenance. • Hazardous voltage may still be present at the relay area, even if mains power is disconnected.

  • Page 17: Mounting Styles

    Mounting Styles Enclosure (Fiberglass) Style The 509ITM is a 3R fiberglass enclosure, designed to be back-mounted on any smooth surface. Four 0.31 × 0.50 in. oval slots are provided for use with fasteners. The monitor requires an approximate area that is 13 inches in width, 16 inches in height, and 8.5 inches in depth.
  • Page 18 Fiberglass Enclosure and Panel Mount 509ITM 16.00 [406] (4X) Ø.41 [Ø10] 14.50 [368] MOUNTING HOLES .86 [22] TYP. 21.56 20.00 23.06 [548] [508] [586] 11.06 [281] Steel Enclosure 509ITM www.qualitrolcorp.com...

  • Page 19: Power Supply

    Power Supply Supply power is applied to Terminal Block TB1 terminals 14 and 15. For DC input, positive voltage is applied to terminal 14, and ground or negative voltage is applied to terminal 15. Chassis ground is applied to terminal 16, as shown in the Power Supply Connection figure. This non-metallic enclosure does not automatically provide a common grounding lug.
  • Page 20 The power supply has an internal removable fuse of GMA 250V/T3.15A (the 5 kV Impulse Unit has no internal fusing) if it becomes necessary to replace this fuse. The fusing must be replaced with the same type and rating that was originally installed. Failure to do so may impact warranty issues.

  • Page 21: Heater Option

    The fuse is the responsibility of the installer. The rating of the heater is 120 VAC and 100 W. A 240 VAC heater uses two of these heaters in a series, for a total of 200 W. Qualitrol recommends installing an external slow-blow fuse rated at 1.25 or 1.5 A, at 600 V. CAUTION: Do not use DC voltage for powering the heater.

  • Page 22: Ct Input Module

    RTD Input Wiring Connections If you are upgrading an existing Qualitrol device, or if the RTD you have installed is a four- wire RTD, DO NOT connect the fourth wire in parallel with the third wire, this will adversely affect the compensation scheme.

  • Page 23: Tap Position Input Module (509Itm-300)

    50/60 Hz, as specified at the factory. Connect the voltage to be measured to the sensor input Terminal Block TB1 of the voltage sensor. Then connect the sensor output to the terminal block of the AC Voltage Input Module, as shown in the AC Voltage Input Connections figure.

  • Page 24: Potentiometer Input Module

    For each Potentiometer Input Module, one standard potentiometer in the range of 1500 - 15000 ohm, as supplied by various Qualitrol case assemblies, is required to measure liquid level, flow, or gas accumulation. The module must be calibrated on site. See the...

  • Page 25: Current Input Module

    DC Voltage Input Wiring Current Input Module The Current Input Module is configurable to accept either a 0 - 1 mA DC or a 4 - 20 mA DC (SCADA type) signal. Either of these options can be a transducer that is: •...
  • Page 26 Current Input Wiring www.qualitrolcorp.com...

  • Page 27: Dry Contact Closure Input Module

    Dry Contact Closure Input Module The Dry Contact (Switch) Closure Input Module is designed to detect the actuation or de- actuation of one dry, non-powered switch contact. The system internally treats closed and open contacts as either a 0 or 100 numeric value. Therefore, if the module is used to control a relay, the relay set point should be set at midrange, e.g., 50.

  • Page 28: Output Contacts

    Output Contacts Nine isolated sets of normally open/normally closed output contacts, for Output Relays 1 - 8 and the System State Output Relay, are provided for controlling cooling equipment, sounding an alarm, or operating remote breaker coils. Each set is capable of switching 115/230 VAC, 30 VDC @ 10 A, and the sets are accessed on Terminal Block TB1, see the Relay Wiring figure for the Enclosure and Panel Mount monitors.

  • Page 29: Remote Output Signals

    Remote Output Signals The monitor is configured to supply four milliamp (mA) current outputs for remote indication or use with SCADA devices. This output is proportional to the full scale of the parameter selected in the configuration. Refer to Functional Specifications section, for maximum load.

  • Page 30: Communications

    #ME540A-ST and the Dymec line/repeater #5846-F-ST. See the Optional Fiber Optic Connection figure for the connection to this option. The RS-485 connection may be used with the Qualitrol Remote Software Package and other available protocols. Refer to the Software Instructions and the 509 Communications Manual, IST-100-X, for a complete description of these features.

  • Page 31: Operation

    60 seconds, the monitor automatically reverts to Auto Scroll, or press MENU again to revert the system back to Viewing Mode Scrolling. Note: To avoid any erroneous readings caused by the installation, Qualitrol recommends resetting the maximum values immediately after setting up the monitor. Viewing Min Readings...
  • Page 32 60 seconds, the monitor automatically reverts to Auto Scroll, or press MENU again to revert the system back to Viewing Mode Scrolling. Note: To avoid any erroneous readings caused by the installation, Qualitrol recommends resetting the minimum values immediately after setting up the monitor. Viewing TransLife...
  • Page 33 Viewing Load Tap Changer Readings (509ITM-300) MENU, View Mode Scrolling, Right Arrows From Viewing Mode, keep pressing the Right Arrow until you reach at the Load Tap Changer column. The display will read “LTC Monitor Active (or Inactive).” Press the Up or Down Arrows (or ENTER to move through the LTC Monitor values for all active systems.

  • Page 34: Program Mode

    Program Mode MENU, View Mode Scrolling, Right Arrows From Viewing Mode, keep pressing the Right Arrow until you reach the Change Settings column. Press ENTER to go to Change Settings Mode. This is the location where you can change some of the settings of the monitor. This mode is protected. Before you are allowed to change any parameters, you must first enter the user ID #.

  • Page 35: Cooling System Monitor (509Itm-200)

    Cooling System Monitor (509ITM-200) There are two parts to the Cooling System Monitor. The first is the setup described in the Software Instructions under Cooling Monitor Initialization. Make sure you have familiarized yourself with these sections before using the Cooling Monitor feature. The second part of the Cooling System Monitor is the normal operations of the Cooling System.

  • Page 36: Load Tap Changer Monitor (509Itm-300)

    Load Tap Changer Monitor (509ITM-300) There are two parts to the Load Tap Changer Monitor. The first is the setup, which is described in the Software Instructions, under the Load Tap Changer section of the Customer Setup. Make sure you familiarize yourself with these sections before using the Load Tap Changer feature.

  • Page 37: Testing The System

    Testing the System To perform a system confidence test, press and hold TEST. Press TEST to actuate all non- Test Lockout relays (see the Output Relays section in the Software Instructions) in one- second intervals. Functional Specifications Power Rated: 100-240VAC, 50/60Hz; 45-260VDC Supply (Allowable range: 90 - 264 VAC, 47 - 63 Hz and 40 - 290 VDC);...
  • Page 38 Eight Form C relay contacts for cooling control, Outputs Control/Alarm Contacts: alarms, trip, etc. One Form C relay for power, sensors and internal Diagnostics Alarm: circuitry diagnostics Heater Control: One relay Relay Contact Ratings: 10A @ 115/230 V AC, 10A @ 30 V DC Four loops;...

  • Page 39: Software Instructions

    Installing/Running the Software The software runs on Microsoft Windows NT, 98, 2000, XP, and Vista operating systems. You can run the software directly from the CD provided by Qualitrol or from files installed on your PC. To run the software from the CD: 1.

  • Page 40: File Menu

    The software automatically loads a default communications data file named default509ITM.qco when it opens the Desktop Communications window. File Menu The File pull-down menu provides several options for selecting a communications file. Open Opens an existing communications file (*.qco). Save Saves the communications data under the current communications file name.

  • Page 41: Establishing Communications With The 509Itm

    Establishing Communications with the 509ITM From the Desktop Communications window, select, set, or observe the following items as required: Address Each 509ITM has an assigned address that allows multiple 509ITMs to be used with a common communication link. The factory default configuration has an address of 00.
  • Page 42 Closes all open 509ITM applications, terminates communications, and Close closes the Desktop Communications window. The Save Communication Setup window displays if any communications parameters have been changed and not saved before clicking [Close All]. A successful communications link is indicated when: •...

  • Page 43: Troubleshooting The Communications Link

    Troubleshooting the Communications Link If a problem occurs in establishing a communications link between the PC and the 509ITM, check the following: • Is the cable a straight-through cable (not a null) and is it securely connected to the PC and the 509ITM? •...
  • Page 44 If required, call Qualitrol Application Engineering at 585-586-1515 x 33317. Customer 111111 Setup The Factory Setup tool can only be entered by Qualitrol factory personnel. This section is reserved for the factory except in the Demo mode (offline). Remember Me...

  • Page 45: Opening A Tool

    Opening a Tool To open any of the 509ITM software tools, do the following: 1. Establish communications with the 509ITM. 2. From the Desktop Menu window, enter the correct password for the tool you wish to start. Note: If the Remember Me feature is enabled, you do not have to enter a password.

  • Page 46: Using The Simulator Tool

    Using the Simulator Tool The Simulator tool allows you to simulate values regardless of the actual inputs that the sensors register. The 509ITM responds to the input signal changes from the Simulator window as if the signals originated in the field. This mode is useful for testing items such as relay connections and wiring.

  • Page 47: Using The Factory Calibrator Tool (Advanced Users Only)

    All channels, except for the Potentiometer and Tap Position Input modules, are calibrated at the factory. Under normal operation, they will not need to be calibrated again. Qualitrol recommends having a separate password for this tool to prevent accidental loss of calibration.
  • Page 48 Calibrating the Input Channels 1. Open the Factory Calibrator tool. 2. Select the input channel to calibrate. 3. Click [Calibrate]. The Input Channel Calibration window displays. 4. In the terminal block that corresponds to the input module being calibrated, enter the signal value displayed in the Set input signal to field.
  • Page 49 Calibrating the Output Channels The analog outputs can be adjusted in a four-point calibration; see the Output Calibration section of the manual for more details. However, this calibration should not be necessary because it is done at the factory. Saving Calibrations in Files You can save calibration values in files using the File pull-down menu.

  • Page 50: Using The Setup Tools

    Using the Setup Tools The Customer Setup tool allows you to set all the adjustable parameters of the 509ITM. The Factory Setup tool is used to set the hardware configurations of the monitor. The Customer Setup limits access to some of the 509ITM parameters, such as serial number, manufacturing date, configuration date and hardware configurations.
  • Page 51 When you open the Customer Setup tool, the Customer - Setup window displays. When you open the Factory Setup tool, the Factory - Setup window appears. The windows for both tools are the same and allow for a specific subsystem to be configured. The Setup windows have three main sections: Model Displays the fields for Serial number, Manufacturing date, and the last...

  • Page 52: System Settings

    System Settings The System Settings window opens when you click [System Settings] from the Setup window. This window allows you to set the configuration for the items displayed in the different sections of the window. More Information • Password Setup •...

  • Page 53: Password Setup

    Password Setup This section of the System Settings window allows you to configure the passwords that provide access for the different software tools. The passwords are stored in the 509ITM and have the following characteristics and requirements: • Passwords consist of one to six alphanumeric characters, and they are case-sensitive. •...

  • Page 54: Installed Features

    Installed Features This section of the System Settings window displays the installed features available in the 509ITM. If a feature is installed, there will be a check mark in the check box next to the legend. Time and Date Setup This section of the System Settings window allows you to configure the time and date values...
  • Page 55 3. Continue with the setup procedure. www.qualitrolcorp.com...

  • Page 56: Display Setup

    Time Zone Allows you to adjust for a difference in time zones between the location of Difference setup and the location of the installed 509ITM. If the two locations are the same, set the value to 0. Otherwise, select the appropriate number of hours, positively or negatively, to provide for a correct time at the installation location.

  • Page 57: Heater Setup

    Heater Setup This section of the System Settings window allows you to configure the 509ITM Heater option. The Heater is not a standard feature and has to be ordered. It is used in extremely cold or moist environments. The Heater is controlled by a 509ITM internal temperature measurement.

  • Page 58: Communications

    Communications The Communications Setup window opens when you click [Communications] from the Setup window. This window allows you to configure the 509 ITM communications ports displayed in the different tabs of the window. More Information • Front USB - Service Port •...

  • Page 59: Front Usb - Service Port

    Front USB - Service Port This section of the Communications Setup window includes the fields described below. Indicates the type of signaling hardware used for the Service Port. This Type field is for informational purposes only. Baud Rate Configures the baud rate that is used to communicate over the RS-232 Service Port at the front panel.

  • Page 60: Main 485 - Main Port

    Hardware section under Communications. Protocol Selects between the available communications protocols to be used by the Main Port communications. The Remote (Qualitrol) protocol comes standard but other protocols: DNP 3.0, Modbus, ASCII, IEC 60870 are available. Indicates the communication address of the 509ITM used by the Address specified protocol.

  • Page 61: Aux 485 - Auxiliary Port

    Number of Selects the desired number of data bits for the Main Port Data Bits communications protocol. The default value is 8. Selects the desired type of parity for the Main Port communications Parity protocol. The default is none. Number of Selects the desired number of stop bits for the Main Port Stop Bits communications protocol.
  • Page 62 Indicates the type of signaling hardware used for the Auxiliary Port. This Type field is for informational purposes only. Checking the install boxes will enable communications to the DGA sensor(s). The 509ITM can support up to three hydrogen sensors. DGA 1 will have an address of 16, DGA 2 will have an address of 17, DGA will have an address of 18.

  • Page 63: Ethernet - Port

    Ethernet - Port IP Address Indicates the IP Address used to communicate to the 509ITM device. Subnet Mask The Subnet Mask used for Ethernet communications with the 509ITM. Gateway The Gateway Address used for communicating with the 509ITM. Address MAC Address Individual MAC Address for this particular 509ITM unit.
  • Page 64 Loads all communications parameters from the PC into the 509ITM. All Load Button new communications parameters take effect only after the 509ITM hardware has been reset. www.qualitrolcorp.com...

  • Page 65: Input Modules

    Input Modules The Input Module Setup window opens when you click [Input Modules] from the Setup window. The 509ITM has up to eight input modules. The types of available modules are described in the Modules section of the Hardware Instructions. To begin, click the tab of the input module that you want to configure.

  • Page 66: Module

    Module This section of the Input Module Setup window includes the fields described below. Input Module Indicates the input module number that is being configured. This field is Number for informational purposes only. Input Module Indicates what module type was installed in this corresponding site of the Type 509ITM.

  • Page 67: Custom Scaling

    Custom Scaling The configuration parameters in this section of the Input Module Setup window allow you to change the scaling of the process input signal. Custom Scaling is not available if the Input is set to a "Logic Switch" or "AC/DC Input". For “Temperature” input Module Type field modules, for example, “RTDs”, “Ambient”, and “CT, Temperature”...

  • Page 68: Ct Current Parameters

    CT Current Parameters is set to "CT, Current" or ”CT, Temperature,” this section of If the Input Module Type field Input Module Setup window provides linear scaling between the 509ITM output and the actual current sensed by the Power Transformer CT. The fields in this section are described below.

  • Page 69: Winding Temperature Setup (Calculated)

    Winding Temperature Setup (Calculated) This section of the Input Module Setup window allows you to configure the "CT, Temperature" input module type. The checked box indicates which winding calculation method is active. Click either method to open the corresponding setup window. •...
  • Page 70 More Information • Input Module Number and Input Signal Name Fields • Winding Rise Parameters • Oil Rise Parameters www.qualitrolcorp.com...
  • Page 71 Input Module Number and Input Signal Name Fields This section of the Simple CT Temperature Scaling Setup window includes the fields described below. Displays the input module number for which the simple “CT, Input module Temperature” scaling parameters are being configured. number Displays the user-assigned name of the signal for which the simple “CT, Input signal...
  • Page 72 If the time constant is unknown, the IEEE Std C57.91-1995 Annex G recommends a value between 3 and 7 minutes. Qualitrol uses a default value of 6 minutes. Oil Rise Parameters...

  • Page 73: Advanced Calculation Setup Method

    Advanced Calculation Setup Method This method allows you to configure the advanced scaling parameters for input module types that are set to “CT, Temperature.” The advanced calculation method is capable of adapting the winding temperature model for all the different stages of cooling, thereby giving a more accurate response than the Simple Calculation Method.
  • Page 74 The Importance of Winding Temperature and Cooling Paper insulation used in transformers contains organic materials that deteriorate over time at elevated temperatures. Cooling that is activated too slowly allows elevated temperatures to degrade this insulation. Cooling systems that are activated too early or too often will lead to reduced fan and/or oil pump life.
  • Page 75 Advanced Winding Rise Parameters This section of the Advanced CT Temperature Scaling Setup window includes the fields described below. Cooling Relay Allows you to input the relay number that controls the cooling system for (3 fields) each cooling stage. Example: Relay 2 controls fan bank 1, Relay 3 controls fan bank 2, and Relay 4 energizes the oil pump.
  • Page 76 Cooling Modes. The exponent describes the “rise” curve of the winding temperature above the oil temperature. When installing a 509ITM on older transformers, this information might be difficult to obtain. In those cases, Qualitrol recommends: • For ONAN (natural convection): 1.6 •...
  • Page 77 Oil Time Allows you to set the time constant for the temperature rise of this Constant winding. The time constant is defined as the time it takes the winding (4 fields) temperature to reach 63.2% of its final value for a given current input. Note: It takes approximately five time constants to elapse for the temperature to reach full value for a given load.

  • Page 78: Output Relays

    Output Relays The Output Relay Setup window opens when you click [Output Relays] from the Setup window. This window displays the tab array of the eight relays with the Relay 1 tab being selected. By selecting the different tabs, you can index through the relay array. To begin, click the tab of the output relay that you want to configure.

  • Page 79: Relay Tabs

    Relay Tabs This section of the Output Relay Setup window includes the fields described below. Relay 1 - The tabs at the top of the window allow you to select which relay to Relay 8 display for setup. System Status The system relay is actuated by: Relay •...
  • Page 80 If the setpoints are exceeded or if the monitor loses power, the normally closed and common contacts are shorted together. Important: Qualitrol recommends setting any trip contacts for a transformer to Non-failsafe. See the following table for further clarification of Failsafe/Non-failsafe operation.
  • Page 81 • Manual / Manual: The relay actuates regardless of the setpoint values. Automatic • Automatic: The relay actuates according to the Control Signal Matrix table and other function settings. This feature can be toggled through the communication channels, which allows you to actuate a relay remotely.

  • Page 82: Seasonal Setpoint

    Seasonal Setpoint This section of the Output Relay Setup window includes the fields described below. Seasonal A check mark indicates that the Seasonal Setpoint feature is installed. setpoint This feature only affects the setpoint for the Control Signal 1 column in installed the Controlled by Matrix section.

  • Page 83: Ambient Temperature Forecast

    To set the Seasonal Setpoint: 1. Enter the appropriate information in the following fields: • Start Date: Select the Month and Day when the Seasonal Setpoint becomes active. • End Date: Select the Month and Day when the Seasonal Setpoint is discontinued. Normal setpoint operation resumes the day after this date.
  • Page 84 Configure Opens the window that allows you to configure the Ambient Temperature Button Forecast feature. This window provides a common path for setting the values of the Ambient Temperature Forecast feature for all eight relays. This function measures the ambient temperature for a specified amount of time and allows you to adjust the setpoint for relay operation during forecasted periods of high temperatures.
  • Page 85 To set the Ambient Temperature Forecast: 1. Enter the appropriate information in the following fields: • Controlled By: Select a temperature signal source to use in forecasting the temperature. This should be an ambient temperature probe. Note: If the 509ITM does not have an ambient temperature probe installed as one of its input modules, this feature cannot be used.

  • Page 86: Cooling Equipment Exerciser

    • Forecast Override Setpoint: Enter a setpoint for the first column of the relay matrix when the Threshold Value is exceeded for the specified number of hours. 2. Click [Load]. Example: If the ambient temperature exceeds 30C for at least 12 hours over the previous 120 hours, the effective setpoint for the first column is 50C.
  • Page 87 If a Low temperature module # is entered then the cooling equipment temperature exerciser will not actuate the relay as long as the measured temperature setpoint is below the low temperature setpoint. www.qualitrolcorp.com...

  • Page 88: Matrix Controlled

    Matrix Controlled This section of the Output Relay Setup window provides a variety of input signal configurations and logic to control the relay actuation. For example, using the math function “or”, you can actuate the relay with a maximum of four different input signals. Conversely, by using the “or”...
  • Page 89 Math Allows you to enter a math function in each of the three available fields. The first and third fields allow the math functions “or”, “and”, and “minus”. Expression The second field allows only “or” and “and”. The “minus” function(s) are (3 fields) first evaluated in the matrix math expression.

  • Page 90: Cancel And Load Buttons

    Rate of The Rate of Change feature only affects column one of the matrix. This feature, enabled using the Rate of Change Time Period, allows the user to set a dynamic change setpoint that will actuate due to a rate of change. For example: If the control signal is set to a Hydrogen gas input, the setpoint is set to 100 PPM, (hysteresis is not used with the rate of change feature), the direction is set to ‘up’...

  • Page 91: Output Loops

    Output Loops The Output Loops Setup window opens when you click [Output Loops] from the Setup window. This window allows you to configure the four current loop output channels. The 509ITM is equipped with four software selectable 0 - 1 mA or 4 - 20 mA (0 - 10 mA on request) outputs to provide information to Supervisory Control &...

  • Page 92: Loop Parameters

    Loop Parameters This section of the Output Loops Setup window includes the fields described below. Output Loop Displays the number of the analog current loop that is to be configured. Loop function Allows you to enable or disable the output loop operation. Loop type Allows you to select between current loop ranges of 0 - 1 mA and 4 - 20 Note:...

  • Page 93: Loop Controlled

    Loop Controlled This section of the Output Loops Setup window allows up to three different input measurements and two math functions to correspond to the analog output loop. You can set up the current output loops to be controlled by one of these three options: •...
  • Page 94 You can bank switch more than two relays in a loop, but this can only be accomplished if the bank switching loop is closed or completed after the setup. This means that the last relay of the bank switching loop must select the first relay of the loop. Example: If Relay 2 selects “Relay 4”, and Relay 4 selects “Relay 6”, you must set up Relay 6 to select “Relay 2”.

  • Page 95: Translife

    TransLife™ The TransLife Setup window opens when you click [TransLife ] from the Setup window. The TransLife feature provides detailed information for up to three winding temperatures of the transformer. To begin, click the TransLife tab that you want to configure. The TransLife Setup window displays for that tab.

  • Page 96: Translife Tm Control

    TransLife Control This section of the TransLife Setup window allows you to configure the TransLife settings for the individual winding temperatures. It includes the fields described below. TransLife Displays which of the three TransLife tabs you have selected. Enable / Allows you to enable or disable the TransLife feature.

  • Page 97: Consumed Life

    Consumed Life The 509ITM calculates relative “life consumption” according to IEEE standards. These standards are based on the Arrhenius formulas for deterioration of organic insulation material with time and temperature. Each 6 - 8 degree increase in temperature approximately doubles the rate of life decay. Based on the cumulative exponential affects of temperature over time, the life consumption metering helps to prioritize maintenance activities between transformers.

  • Page 98: Critical Forecast

    -14.133 6972.15 Present Loss Displays the consumed life rate of the winding at this instant in time. of Life Rate Example: If the Unity Hot Spot Temperature is 110° C and the winding is reading exactly 110° C, the present loss of life rate is 1.00. Loss of Life in Displays the consumed life lost in the past hour.
  • Page 99 The Critical Forecast section includes the fields described below. Critical Allows you to enter three temperature values for monitoring the time it Temperature takes for the winding temperature to reach the present load conditions. (3 Range fields) Time to Displays the time calculated for the winding temperature to reach the Critical critical setpoint values, given the present loading, oil/winding Temperature...

  • Page 100: Temperature Profiler

    Temperature Profiler This section of the TransLife Setup window allows you to configure the Temperature Profiler. The Temperature Profiler has 12 ranges of temperature values - six ranges each above and below the value in the Unity Temperature field. The Temperature Profiler monitors how many hours the measured winding temperature remains in each temperature range.
  • Page 101 www.qualitrolcorp.com...

  • Page 102: Data Logger

    Data Logger The Data Logger Setup window opens when you click [Data Logger] from the Setup window. The Data Logger can store the data of up to 20 signals. These signals can be any of the following types: • input module measurements •...
  • Page 103 Chan # Displays the point number of the 20 data logging points. Enabled Allows you to enable or disable the data logging point. Allows you to select the signal to be monitored for data logging. For input Signal Name modules and fiber optic probes, this is the present measurement value. For relays, this is the actuation status.
  • Page 104 Save to PC Selecting Save to PC will download all valid data logging memory to the connected PC in a *.csv file format. Save to Selecting Save to tmbdrv will download all valid data logging memory to tmbdrv the flash drive inserted in the side USB-A port on the 509ITM in a *.csv file format.

  • Page 105: Event Recorder

    Event Recorder The Event Recorder Setup window opens when you click [Event Recorder] from the Setup window. The Event Recorder can log up to eight user-selectable events. Once an event has occurred, or if conditions have cleared an event, the event recorder automatically provides a time stamp and stores the specific event.

  • Page 106: Module

    Module This section of the Event Recorder Setup window includes the fields described below. Event Allows you to enable (Yes) or disable (No) the Event Recorder feature. Recorder Enabled Event Name Allows you to enter a user-selectable name associated with event. The maximum name size is 24 alpha-numeric characters.

  • Page 107: Event Trigger

    Event Trigger This section of the Event Recorder Setup window allows you to configure the event trigger matrix to allow a variety of input signal configurations to control the event actuation. Example: By setting the Math expression field to the “or” function, you can have the system trigger the event with the maximum of four different input signals.

  • Page 108: Cooling System Monitor (509Itm-200)

    Math Allows you to enter a math function in each of the three available fields. The first and third fields allow the math functions “or”, “and”, and “minus”. expression The second field allows only “or” and “and”. The “minus” function has the highest calculation priority, and the matrix reads from left to right for the remaining operators.
  • Page 109 All of these functions allow you to maximize the use of the cooling function and help extend transformer life. www.qualitrolcorp.com...

  • Page 110: Cooling Bank Setup

    Important: You must configure and initialize the Cooling System Monitor before it can operate correctly. Cooling bank Allows you to select a cooling bank for setup. “X” Setup Button Opens the Cooling Bank Setup window for the selected cooling bank. More Information •...

  • Page 111: Setup

    For more information about the learning mode and the initialization process, see Cooling Monitor Initialization. When you have completed the initialization process and have all of the parameter information necessary, you can finish completing the Cooling Bank Setup window. More Information •...
  • Page 112 Current input Allows you to select the input module number that measures the motor module current from the fans or pumps that start when the bank actuating relay is actuated. Important: This variable must be set correctly before using the Cooling Monitor Initialization feature.

  • Page 113: Running Bank Current

    Running Bank Current This section of the Cooling Bank Setup window includes the fields described below. Average Displays the average steady-state (running) current of the controlling current value cooling bank, a value the monitor obtained during the initialization process (learning mode). This field is for informational purposes only. Maximum Displays one of the following items: current value...

  • Page 114: Starting Motor Current Value

    Starting Motor Current Value This section of the Cooling Bank Setup window includes the fields described below. Average peak Displays the average inrush current, over time, for the controlling cooling value motor, a value the monitor obtained during the initialization process (learning mode).

  • Page 115: Number Of Actuations

    Number of Actuations This section of the Cooling Bank Setup window includes the fields described below. Present Displays the number of times the bank-actuating relay, which controls the actuations cooling system, has actuated. You can view the number and leave it as is, or you can reset or preset the count by entering a new number.

  • Page 116: Flow Gauge

    Flow Gauge This section of the Cooling Bank Setup window includes the fields described below. Sensor input Allows you to select an input module for sensing the flow of oil in the module cooling system. Allows you to enter the setpoint value that actuates the alarm relay if the Alarm if flow gauge is on or off.

  • Page 117: Cooling Monitor Initialization

    This section of the Cooling Bank Setup window includes the fields described below. Cancel Button Erases any changes you have made to this window and returns all variables to the previous values. Load Button Enters all variables displayed in the window into the system. Cooling Monitor Initialization For many of the values required for the Cooling Bank setup, you will not know the appropriate numbers to enter.
  • Page 118 509ITM is learning the system parameters. Allows you to enter the number of times for the cooling system to Test cycles cycle while the system is being evaluated. Qualitrol recommends a minimum of 10 cycles to get a good system average. 6. Click [Initialize].

  • Page 119: Load Tap Changer Monitor (509Itm-300)

    Load Tap Changer Monitor (509ITM-300) The Load Tap Changer (LTC) Monitor tracks all of the parameters of a load tap system. Once installed, the monitor performs the following functions to help alert you to immediate or potential system problems: • Measures the present tap position, tap counts, make and break currents, motor actuations, and motor currents.

  • Page 120: Ltc Monitor Setup

    For detecting unwanted multiple movements of the tap position indicator: • Required: A CT, Current Input Module to monitor the tap changer motor. More Information • Load Tap Changer Monitor (509ITM-300) • LTC Monitor Setup LTC Monitor Setup The LTC Monitor Setup window opens when you click [Load Tap Changer] from the Setup window.

  • Page 121: Tap Position

    More Information • • Tap Position Alarm Setup • • Tap Count LTC Alarm Setup - High Priority • • Tap Motor Sensing LTC Alarm Setup - Low Priority • Load Current Tap Position This section of the LTC Monitor Setup window includes the fields described below.

  • Page 122: Tap Count

    Tap Count This section of the LTC Monitor Setup window includes the fields described below. Tap count Allows you to select the number of hours within which you want to count period the total number of taps. This is a good indication of how much activity the tap changer detects within a limited period of time.

  • Page 123: Load Current

    Load Current This section of the LTC Monitor Setup window includes the field described below. Load current Allows you to select the installed position of the current input module, if you are measuring make and break currents of the different tap positions. Alarm Setup This section of the LTC Monitor Setup window...

  • Page 124: High Priority - Ltc Alarm Setup

    High Priority - LTC Alarm Setup The High Priority LTC Alarm Setup window opens when you click [Setup] from the Alarm Relay − High Priority field of the LTC Monitor Setup window. This window allows you to set the configuration for the items displayed in the different sections. More Information •...

  • Page 125: Alarm Relay Setup

    Alarm Relay Setup This section of the High Priority LTC Alarm Setup window includes the fields described below. Alarm relay Allows you to select the relay number that you want to actuate if any of the selected parameters exceed the setpoint values. Important: This alarm relay is configured in this window and not in the Output Relay Setup...

  • Page 126: Total Tap Counts

    Allows you to select whether or not to have the relay function latch if the Latching relay setpoint is exceeded. Example: If the motor current exceeds the setpoint, the latched relay actuates and remains actuated, even when the motor current returns to a normal operating value.

  • Page 127: Tap Run Time

    Tap Run Time This section of the High Priority LTC Alarm Setup window includes the fields described below. Tap run time Allows you to enter the setpoint value that actuates the alarm relay if the setpoint total run time of any individual tap position equals or exceeds the value. Actuate Alarm Enables (Yes) / Disables (No) the actuation of the alarm relay if the value (Yes / No)

  • Page 128: Running Motor Current

    Running Motor Current This section of the High Priority LTC Alarm Setup window includes the fields described below. Last current Displays the last measured steady-state current value of the tap position value motor. This field is for informational purposes, but it can be used as a guide for determining the setpoint values in the Upper Setpoint and Lower Setpoint fields.

  • Page 129: Motor Actuations

    Actuate alarm Enables (Yes) / Disables (No) the actuation of the alarm relay if the (Yes / No) inrush current exceeds the setpoint threshold limits. Motor Actuations This section of the High Priority LTC Alarm Setup window includes the fields described below.

  • Page 130: Differential Temperatures

    Differential Temperatures This section of the High Priority LTC Alarm Setup window includes the fields described below. Temperature Allows you to enter a temperature value to actuate the alarm relay if the setpoint differential measurement equals or exceeds the value. Allows you to select a switching differential of the temperature that is Hysteresis required to de-actuate the alarm relay.

  • Page 131: Difference Calculation

    Difference Calculation The Difference Calculation window opens when you click [Configure] in the Difference Calculation Setup field of any of the following three windows: • Cooling Bank Setup • High Priority LTC Alarm Setup • Low Priority LTC Alarm Setup The 509ITM can manage up to four difference calculations.

  • Page 132: View Ltc Values

    Allows you to select which difference calculation is assigned to control Difference A the output current loop or the output relay currently being configured. Difference B Difference C Difference D Allows you to select the signals to be used in each of the difference Input A calculations.
  • Page 133 Displays the specific tap position for each horizontal row. This field is for Tap Column informational purposes only. Total tap Displays the total tap count detected for each tap position. counts You have the option of resetting to zero or preloading this value. This is normally done after replacing taps during system maintenance.

  • Page 134: Qualitrol

    509ITM – DW with Direct Winding QUALITROL ® System Overview The QUALITROL 509ITM - DW (509 DW) incorporates all the features of the 509ITM, along ® with the ability to measure direct winding temperatures using fiber optic probes and to compare these measurements to calculated winding temperatures.

  • Page 135: System Setup

    Both styles are capable of having up to 12 optical feedthroughs installed in them. Custom plates are available. Junction Box To protect the optical feedthroughs and extension cables, Qualitrol provides a junction box, COV-121-1, which covers the outside of the tank wall plate and allows access to the optical connections cabling.

  • Page 136: Using An Optical Hot Spot Module With A Digital Connection

    Using an optical hot spot module with a digital connection For 509 DW units using a digital interface between the 509 DW and the optical hot spot module, no additional input modules are needed. Instead, a digital connection is used for the 509 DW.
  • Page 137 The relay delay timer may require a value that would be derived through experience with the transformer because: • the direct winding measurement will react at a faster rate than the calculated winding temperature, and • the calculated value is based on data from the original heat run and is heavily dependent upon the accuracy of this data.

  • Page 138: Importing And Exporting Configuration Files

    Importing and Exporting Configuration Files Configurations can be saved as files. This is convenient if: • you want to restore the 509ITM to its original settings • you want to configure a 509ITM offline and import this configuration at the site You can save calibration values in files using the File pull-down menu.

  • Page 139: Expansion Module Option

    Expansion Module Option For those applications requiring more than eight input modules Qualitrol offers an Expansion Module that will accept an additional eight input modules doubling the input capability of the 509ITM unit. The Expansion Module uses the same input modules described in the hardware section of this manual and all the software features of the standard input modules apply to these additional inputs (e.g.

  • Page 140: Location And Mounting

    Location and Mounting TB13 IN PUT MODULE 9 TB14 IN PUT MODULE 10 INPUT POWE R : TB15 ( UNIVE R S AL) 90-264 VAC, 47-63 HZ. IN PUT MODULE 11 40-290 VDC WATTAGE : < 17.0 WATTS AC IN <...
  • Page 141 TB13 IN PUT MODULE 9 TB14 IN PUT MODULE 10 INPUT POWE R : TB15 ( UNIVE R S AL) 90-264 VAC, 47-63 HZ. IN PUT MODULE 11 40-290 VDC WATTAGE : < 17.0 WATTS AC IN < 5.0 WATTS DC IN LINE F US E : 2.0 AMPS TB16 IN PUT MODULE 12...

  • Page 142: Input Supply Power

    Input Supply Power: INPUT SUPPLY POWER 100-240VAC; 50/60 Hz INPUT VOLTAGE: 45-260VDC TB22 - 1 EARTH GROUND WIRING: TB22 - 3 VACC, NEUTRAL (-) TB22 - 5 VAC, LINE (+) Communications All digital communications from the 509ITM unit to the expansion module and hot spot modules is done through the auxiliary RS485 communications port on the back of the 509ITM unit (TB2 –...

  • Page 143: Input Modules

    Input Modules To set up the input modules installed on the expansion module click on ‘Input Expansion Modules’ in the ‘Customer-Setup’ window. www.qualitrolcorp.com...
  • Page 144 The following window will appear: www.qualitrolcorp.com...
  • Page 145 The input modules installed on the expansion module are configured and set up exactly the way the input modules are configured in the main 509ITM unit. See the input module section of the manual for instructions. All output relays, output current loops, data logging, event recording and communication protocols can be configured to use all active installed input modules be they from the main 509ITM unit or residing on the expansion module.

  • Page 146: Calibrating The 509Itm

    TB13 IN PUT MODULE 9 TB14 IN PUT MODULE 10 INPUT POWE R : TB15 ( UNIVE R S AL) 90-264 VAC, 47-63 HZ. IN PUT MODULE 11 40-290 VDC WATTAGE : < 17.0 WATTS AC IN < 5.0 WATTS DC IN LINE F US E : 2.0 AMPS TB16 IN PUT MODULE 12...
  • Page 147 Popular valve mountings are provided for retrofit: 1.5 NPT, 2.5 NPT and 4 inch bolt circle flange versions are available. When mounted in place of a Qualitrol Rapid Pressure Rise Relay the hydrogen monitor includes a remote pressure output option.
  • Page 148 DGA Hydrogen Sensor wiring. The 509ITM communicates to the DGA Hydrogen Sensor thru a 2-wire RS485 connection. Jumper TB1-7 (RS485 – TxD+) with TB1-9 (RS485 – RxD+). Then jumperTB1-8 (RS485 – TxD-) with TB1-10 (RS485 – RxD-). Run a four wire, shielded, twisted pair cable from the 509ITM to the DGA Hydrogen Sensor and run the connections as follows: COMMUNICATIONS WIRING 509ITM...
  • Page 149 In the Customer – Setup window screen if a DGA sensor is installed it will display the DGA button which will allow the user access to the DGA setup screens. www.qualitrolcorp.com...
  • Page 150 Sensor X Displays the tabs for configuring the DGA sensor; Up to 3 tabs displayed DGA input The number of the sensor being configured. module number Input module These radio buttons select whether the hydrogen DGA sensor is enabled function or disabled.
  • Page 151 History Graph The history graph displays the minimum, average and maximum hydrogen values measured over the last twelve days, giving a quick visual representation of the hydrogen levels in the transformer. Sensor Information Clicking on Sensor Information will display the DGA sensor information window allowing the user to view all the pertinent information about the DGA hydrogen sensor.
  • Page 152 Sensor The number of the particular sensor that is being viewed. Sensor Displays the location of the sensor, in the oil or gas space. NOTE: location Sensors are calibrated to be located in either the oil or gas space and can not be interchanged.
  • Page 153 Enters all variables that are displayed in the window into the system. Lab Correlation of the DGA Hydrogen Monitor Qualitrol recommends verifying the correlation of the of the DGA hydrogen sensor at least once each year using an approved laboratory. This is important in that the readings from one laboratory to another may vary as much as +/-15%.
  • Page 154 The first step is to remove a valid oil sample using the procedure specified by ASTM D 3612. After obtaining the oil sample enter the date in the DGA Lab Correlation window screen in the Oil Sample section and then click on ‘Load Sample Date’. This locks in the date and the present hydrogen reading.
  • Page 155 Removal of This is the date when the oil was drawn from the transformer to send to a lab sample laboratory for validation. date Load sample This locks in the hydrogen reading and the date it was taken of the oil sample.
  • Page 156 Condition 3: Hydrogen exceeding specified levels should prompt additional investigation. Immediate action should be taken to establish a trend. Fault(s) are probably present. For hydrogen levels of 701 – 1800 PPM. Condition 4: Continued operation could result in failure of the transformer. Proceed immediately and with caution.

  • Page 157: Calibrating Remote Outputs For Alternate Values

    Connect the computer to the 509ITM start the Remote Software. The Desktop Menu window displays. 2. Click [Connect] and enter the password for the Calibrator tool. Note: If you do not know this password, call Qualitrol at 585-586-1515, Ext. 410. 3. Click [Start]. www.qualitrolcorp.com...
  • Page 158 The Calibrator - Signal Selection window displays with the radio button for Input 1 selected. CAUTION: Be extremely careful in the Calibrator tool. Changing calibration values incorrectly might cause the 509ITM to malfunction. 4. Connect the ammeter (or multi-meter set to measure DC milliamps) to TB2 pins 1 and 2 with the positive probe on 1.
  • Page 159 6. Click [Next] until you reach the Output Channel Calibration window. The Adjust output signal to field displays 4.80 mA, which is the value used to calibrate for a 4 - 20 mA current loop output. Output Channel Calibration 7. Adjust the slide bar control until the ammeter displays the correct lower calibration value for the new current loop output range.
  • Page 160 8. Click [Next]. The Output Channel Calibration window displays again. Output Channel Calibration 9. Adjust the slide bar control until the ammeter displays the correct upper calibration value for the new current loop output range. Current Loop Upper Output Range Calibration Value 4 - 20 mA 20.00 mA...

  • Page 161: Calibrating A Level Gauge To The 509Itm

    Calibrating a Level Gauge to the 509ITM Overview All of the input modules on the 509ITM are calibrated at Qualitrol, except for the Potentiometer (Level Gauge) and Tap Position input modules. These modules and sensor inputs are specific to the transformer with which they are associated and must be calibrated on the transformer.
  • Page 162 The Calibrator - Signal Selection window displays with the radio button for Input 1 selected. 4. Click the radio button for the input module that displays “Potentiometer.” In the example above, this is Input 3. CAUTION: Check again that you have selected the correct input module before proceeding.
  • Page 163 The Input Channel Calibration window displays. The Set input signal to field prompts you to set the pointer to minimum (“MIN”). 6. Adjust the case face until the pointer is set at the minimum position. Case face adjusted with the pointer (and potentiometer) moved to minimum www.qualitrolcorp.com...
  • Page 164 7. Click [Next]. The Input Channel Calibration window now prompts you to set the pointer to maximum (“MAX”). 8. Adjust the case face until the pointer is set at the maximum position. Case face adjusted with the pointer (and potentiometer) moved to maximum www.qualitrolcorp.com...

  • Page 165: Calibrating A Tap Position Resistor Bridge To The 509Itm

    Calibrating a Tap Position Resistor Bridge to the 509ITM Overview All of the input modules on the 509ITM are calibrated at Qualitrol, except for the Potentiometer (Level Gauge) and Tap Position Input Modules. These modules and sensor inputs are specific to the transformer with which they are associated and must be calibrated on the transformer.

  • Page 166: Calibration Procedure

    Calibration Procedure Connect the computer to the 509ITM start the Remote Software. The Desktop Menu window displays. − 2. Click [Connect] and enter the password for the Customer Setup tool. • 509 for newer models • 111111 for older models 3.
  • Page 167 The Customer - Setup window displays. 4. Click [Load Tap Changer]. www.qualitrolcorp.com...
  • Page 168 The LTC Monitor Setup window displays. 5. In the Tap position module field, select the “LTC Resistor” input module. 6. In the Total number of taps field, enter the correct tap position number. 7. Click [Load]. 8. Exit from the Configurator − Customer tool. 9.
  • Page 169 The Calibrator - Signal Selection window displays with the radio button for Input 1 selected. 11. Click the radio button for the input module that displays “LTC Resistor.” In the example above, this is Input 4. CAUTION: Check again that you have selected the correct input module before proceeding.
  • Page 170 The Input Channel Calibration window displays. Important: Variations in the individual resistor values require that you calibrate every position of the Tap Position Resistor Bridge, starting with the lowest tap position. For this reason, the transformer should be offline during the calibration.
  • Page 171 The Input Channel Calibration window displays again. 16. Move the tap position up one tap and click [Next]. Repeat for the entire range of taps. Important: Be sure to increment the tap position only once for each increment of the Input Channel Calibration window.
  • Page 172 Verifying the Calibration 1. Re-enter the Customer − Setup tool. 2. Click File > Print Preview. 3. Scroll to page 5 of the Configuration Table. The tap position numbers will be on the left side of the page with the corresponding calibration values in parentheses.
  • Page 173 Installing the USB driver (for use during model setup) Install the latest CP210X Drivers applicable to your operating system. The Microsoft Windows version is available on the CD-ROM sent with the ITM or the very latest can be obtained from the Silicon Laboratories website: http://www.silabs.com/products/mcu/Pages/USBtoUARTBridgeVCPDrivers.aspx.

  • Page 174: Frequently Asked Questions About The 509Itm

    Frequently Asked Questions About the 509ITM In the Simple CT Temperature Scaling Setup window, what is the “Oil Temperature Adder”? And where do I get the values for the other three variables? Simple Calculation Setup Method, which uses the Simple CT Temperature Scaling Setup window, calculates the winding temperature of the transformer by using the oil temperature of the transformer and the load or current running through the windings.
  • Page 175 What is the difference between failsafe and non-failsafe for a relay? In the 509ITM, Qualitrol uses Form C relays. These relays have three contacts: normally open, normally closed, and common. When the monitor has no power applied, the common and normally closed contacts are shorted together, while the common and normally open contacts are open.
  • Page 176 109.73 ohm 146.06 ohm Because of the small resistance values in an RTD sensor, Qualitrol recommends a maximum of 75 feet of cable length. A typical application to measure the resistance (temperature) changes in an RTD is for a monitor to send an excitation current through the RTD and then measure the voltage across the device.
  • Page 177 • contact Qualitrol about updating the 509ITM unit in the field (purchasing a new module and getting an update software disk). 2. The calibration for the RTD Input Module has been altered or overwritten. If the 509ITM was incorrectly recalibrated in the field, reinstall the factory calibration settings.

  • Page 178: Appendix

    Appendix www.qualitrolcorp.com...
  • Page 182 MENU SWITCH right right right right right right 05/24/2001 VIEW/RESET VIEW/RESET VIEW TRANSLIFE RESET RELAYS 08:28:15 MAXIMUM MEMORY MINIMUM MEMORY left left left left left left down/enter down/enter down/enter down/enter down/enter TOP OIL CHAN 1 ACKNOWLEDGE TOP OIL 84.5 C TOP OIL 73.2 C TL1 CRITCAL TIME...
  • Page 183 (IF FEATURE IS (IF FEATURE IS (IF 509ITM-200 MODEL) (IF 509ITM-300 MODEL) ACTIVE) ACTIVE) right right right right right right DATA LOGGER EVENT RECORDER COOLING MONITOR LTC MONITOR CHANGE SETTINGS OPTIONS OPTIONS INACTIVE INACTIVE ID # REQUIRED left left left left left left...
  • Page 184 down/enter down/enter down/enter BOT OIL CHAN 8 BOT OIL 79.8 C CH1-CH6 2.3 C 73.1 C MAX8 1524 051701 MIN 1524 051701 down/enter down/enter down/enter ACTUATION COUNTS CH1-CH7 1.1 C CH7-CH6 3.5 C RELAY 1 00018 MAX 1524 051701 MIN 1524 051701 down/enter down/enter down/enter...
  • Page 185 down/enter down/enter RUN LOWER SETPT TAP COUNT SETPT WIND 1 RELAY 8 18.0 A HI ALM 25000 SETPNT 0120.0 C down/enter down/enter enter RUSH UPPER SETPT CNT/PERIOD SETPT RELAY 1 45.0 AS HI ALM MAN/AUTO AUTO down/enter down/enter enter RUSH LOWER SETPT TAP RUN TIME SP RELAY 2 32.0 AS...
  • Page 186 down/enter enter TAP RUN TIME SP LOAD CT CHAN 3 LO ALM 5000 H down/enter enter RUSH UPPER SETPT MTR SW1 CHAN 4 LO ALM 43.2 AS down/enter enter RUSH LOWER SETPT MTR SW2 CHAN 5 LO ALM 25.4 AS down/enter enter RUN UPPER SETPT...
  • Page 187 Index input wiring, 17 module, 6 about Qualitrol, 2 enclosure style monitor, 10 about the hardware instructions, 2 event recorder, 82 AC voltage event trigger matrix, 84 input connections, 13 module, 83 input module, 4 expansion port, 50...
  • Page 188 seasonal setpoint, 64 service port, 49 setup system, 44 oil rise parameters, 56 simple calculation setup, 54 open an application, 36 simulator application, 38 output software instructions, 29 loops, 70 System Settings, 44 relays, 61 output contacts relay wiring, 18 overview applications, 34 hardware, 1...
  • Page 189 It is the global leader in sales and installations of transformer asset protection equipment, fault recorders and fault locators. Established in 1945, Qualitrol produces thousands of different types of products on demand, each customized to customers' unique requirements.

This manual is also suitable for:

509itm-100509itm-200509itm-300

Table of Contents
